2000 YAMAHA YZF-R1 torque

6-1
6
EAU00462
6-PERIODIC MAINTENANCE AND MINOR REPAIR
EAU00464
Safety is an obligation of the owner.
Periodic inspection, adjustment and lu-
brication will keep your vehicle in the
safest and most efficient condition pos-
sible. The most important points of in-
spection, adjustment, and lubrication
are explained on the following pages.
The intervals given in the periodic
maintenance and lubrication chart
should be simply considered as a gen-
eral guide under normal riding condi-
tions. However, DEPENDING ON THE
WEATHER, TERRAIN, GEOGRAPHI-
CAL LOCATION, AND INDIVIDUAL
USE, THE MAINTENANCE INTER-
VALS MAY NEED TO BE SHORT-
ENED.
EW000060
WARNING
@ If you are not familiar with motor-
cycle maintenance work, have a
Yamaha dealer do it for you. @
EAU01575
Owner’s tool kitThe tool kit is located inside the storage
compartment under the passenger
seat. (See page 3-14 for passenger
seat removal procedures.)
The service information included in this
manual and the tools provided in the
owner’s tool kit are intended to assist
you in the performance of preventive
maintenance and minor repairs. How-
ever, additional tools such as a torque
wrench may be necessary to perform
certain maintenance work correctly.
NOTE:@ If you do not have the tools or experi-
ence required for a particular job, have
a Yamaha dealer perform it for you. @
EW000063
WARNING
@ Modifications not approved by
Yamaha may cause loss of perfor-
mance and render the vehicle un-
safe for use. Consult a Yamaha
dealer before attempting any
changes. @
1. Owner’s tool kit
E_5jj_Periodic.fm Page 1 Wednesday, February 2, 2000 5:18 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-8
6 Clean the surface of the spark plug
gasket and its mating surface, and then
wipe off any grime from the spark plug
threads.
NOTE:@ If a torque wrench is not available when
installing a spark plug, a good estimate
of the correct torque is 1/4–1/2 turn
past finger tight. However, the spark
plug should be tightened to the speci-
fied torque as soon as possible. @
EAU01765
Engine oil and oil filter
cartridgeThe engine oil level should be checked
before each ride. In addition, the oil
must be changed and the oil filter car-
tridge replaced at the intervals speci-
fied in the periodic maintenance and
lubrication chart.
To check the engine oil level
1. Place the motorcycle on a level
surface and hold it in an upright
position.
NOTE:@ Make sure that the motorcycle is posi-
tioned straight up when checking the oil
level. A slight tilt to the side can result in
a false reading. @2. Start the engine, warm it up for
several minutes, and then turn it
off.
3. Wait a few minutes until the oil set-
tles, and then check the oil level
through the check window located
at the bottom-right side of the
crankcase.NOTE:@ The engine oil should be between the
minimum and maximum level marks. @4. If the engine oil is below the mini-
mum level mark, add sufficient oil
of the recommended type to raise
it to the correct level. Tightening torque:
Spark plug:
12.5 Nm (1.25 m·kg)
1. Oil level check window
2. Maximum level mark
3. Minimum level mark
E_5jj_Periodic.fm Page 8 Wednesday, February 2, 2000 5:18 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-10
6 7. Apply a thin coat of engine oil to
the O-ring of the new oil filter car-
tridge.
NOTE:@ Make sure that the O-ring is properly
seated. @
8. Install the new oil filter cartridge,
and then tighten it to the specified
torque with a torque wrench.
9. Install the engine oil drain bolt, and
then tighten it to the specified
torque.10. Add the specified amount of the
recommended engine oil, and
then install and tighten the oil filler
cap.
1. O-ring
1. Torque wrenchTightening torque:
Oil filter cartridge:
17 Nm (1.7 m·kg)
Tightening torque:
Engine oil drain bolt:
43 Nm (4.3 m·kg)
Recommended engine oil:
See page 8-1.
Oil quantity:
Without oil filter cartridge
replacement:
2.7 L
With oil filter cartridge
replacement:
2.9 L
Total amount (dry engine):
3.6 L
E_5jj_Periodic.fm Page 10 Wednesday, February 2, 2000 5:18 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-14
6 8. Loosen the radiator hose clamp
screw located at the left side of the
engine, and then pull off the hose
to drain the radiator.
9. After the coolant is completely
drained, thoroughly flush the cool-
ing system with clean tap water.
10. Install the coolant drain bolt, and
then tighten it to the specified
torque.
NOTE:@ Check the washer for damage and re-
place it if necessary. @
11. Connect the radiator hose, and
then tighten the clamp screw.
12. Pour the specified amount of rec-
ommended coolant into the radia-
tor and reservoir.
EC000080
CAUTION:@ l
If coolant is not available, use
distilled water or soft tap water
instead. Do not use hard water
or salt water since it is harmful
to the engine.
l
If water has been used instead
of coolant, replace it with cool-
ant as soon as possible, other-
wise the engine may not be
sufficiently cooled and the cool-
ing system will not be protected
against frost and corrosion.
l
If water has been added to the
coolant, have a Yamaha dealer
check the antifreeze content of
the coolant as soon as possible,
otherwise the effectiveness of
the coolant will be reduced.
@13. Install the radiator cap, start the
engine, let it idle for several min-
utes, and then turn it off.
1. Hose clamp
Tightening torque:
Coolant drain bolt:
7 Nm (0.7 m·kg)
Antifreeze/water mixture ratio:
1:1
Recommended antifreeze:
High-quality ethylene glycol
antifreeze containing corrosion
inhibitors for aluminum engines
Coolant quantity:
Total amount:
2.55 L
Coolant reservoir capacity:
0.45 L
E_5jj_Periodic.fm Page 14 Wednesday, February 2, 2000 5:18 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-25
6
EAU01248
Rear brake pads
1. Remove the rear brake caliper by
removing the bolts.2. Check each rear brake pad for
damage and measure the lining
thickness. If a brake pad is dam-
aged or if the lining thickness is
less than 0.5 mm, have a Yamaha
dealer replace the brake pads as a
set.
3. Install the rear brake caliper by in-
stalling the bolts, then tightening
them to the specified torque.
EAU00731
Checking the brake fluid level Insufficient brake fluid may allow air to
enter the brake system, possibly caus-
ing it to become ineffective.
Before riding, check that the brake fluid
is above the minimum level mark and
replenish if necessary. A low brake flu-
id level may indicate worn brake pads
and/or brake system leakage. If the
brake level is low, be sure to check the
brake pads for wear and the brake sys-
tem for leakage.
1. Caliper bolt (´ 2)Rear
a. Lining thickness
Tightening torque:
Brake caliper bolt:
40 Nm (4.0 m·kg)
1. Minimum level markFront
E_5jj_Periodic.fm Page 25 Wednesday, February 2, 2000 5:18 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-28
6
NOTE:@ Using the alignment marks on each
side of the swingarm, make sure that
both chain pullers are in the same posi-
tion for proper wheel alignment. @
EC000096
CAUTION:@ Improper drive chain slack will over-
load the engine as well as other vital
parts of the motorcycle and can lead
to chain slippage or breakage. To
prevent this from occurring, keep
the drive chain slack within the
specified limits. @3. Tighten the locknuts, and then
tighten the axle nut to the specified
torque.
EAU03006
Lubricating the drive chain The drive chain must be cleaned and
lubricated at the intervals specified in
the periodic maintenance and lubrica-
tion chart, otherwise it will quickly wear
out, especially when riding in dusty or
wet areas. Service the drive chain as
follows.
EC000097
CAUTION:@ The drive chain must be lubricated
after washing the motorcycle or
riding in the rain. @1. Clean the drive chain with kero-
sene and a small soft brush.
ECA00053
CAUTION:@ To prevent damaging the O-rings,
do not clean the drive chain with
steam cleaners, high-pressure
washers or inappropriate solvents. @2. Wipe the drive chain dry.
3. Thoroughly lubricate the drive
chain with a special O-ring chain
lubricant.
ECA00052
CAUTION:@ Do not use engine oil or any other
lubricants for the drive chain, as
they may contain substances that
could damage the O-rings. @
Tightening torque:
Axle nut:
150 Nm (15 m·kg)
E_5jj_Periodic.fm Page 28 Wednesday, February 2, 2000 5:18 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-40
6
EAU01249
To install the front wheel
1. Lift the wheel up between the fork
legs.
2. Insert the wheel axle.
3. Lower the front wheel so that it is
on the ground.
4. Push down hard on the handlebar
several times to check for proper
fork operation.
5. Install the brake calipers by install-
ing the bolts.NOTE:@ Make sure that there is enough space
between the brake pads before install-
ing the brake calipers onto the brake
discs. @6. Install the brake hose holders by
installing the bolts.
7. Install the front wheel axle pinch
bolt, and then tighten the wheel
axle, pinch bolt and brake caliper
bolts to the specified torques.8. Install the cowling.Tightening torques:
Wheel axle:
72 Nm (7.2 m·kg)
Front wheel axle pinch bolt:
23 Nm (2.3 m·kg)
Brake caliper bolt:
40 Nm (4.0 m·kg)
E_5jj_Periodic.fm Page 40 Wednesday, February 2, 2000 5:18 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-42
6
EAU01246
To install the rear wheel
1. Install the wheel by inserting the
wheel axle.
2. Install the drive chain onto the rear
sprocket, and then adjust the drive
chain slack. (See page 6-27 for
drive chain slack adjustment pro-
cedures.)
3. Install the axle nut, and then lower
the rear wheel so that it is on the
ground.
4. Install the brake caliper by install-
ing the bolts.NOTE:@ Make sure that there is enough space
between the brake pads before install-
ing the brake caliper onto the brake
disc. @
5. Tighten the axle nut and brake cal-
iper bolts to the specified torques.
EAU03087
TroubleshootingAlthough Yamaha motorcycles receive
a thorough inspection before shipment
from the factory, trouble may occur dur-
ing operation. Any problem in the fuel,
compression, or ignition systems, for
example, can cause poor starting and
loss of power.
The following troubleshooting charts
represent quick and easy procedures
for checking these vital systems your-
self. However, should your motorcycle
require any repair, take it to a Yamaha
dealer, whose skilled technicians have
the necessary tools, experience, and
know-how to service the motorcycle
properly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look
like Yamaha parts, but they are often
inferior, have a shorter service life and
can lead to expensive repair bills. Tightening torques:
Axle nut:
150 Nm (15.0 m·kg)
Brake caliper bolt:
40 Nm (4.0 m·kg)
E_5jj_Periodic.fm Page 42 Wednesday, February 2, 2000 5:18 PM
