2000 TOYOTA RAV4 Owners Manual

Rav4(U)
252000 RAV4 (OM42479U)
2. Lock the latch handle and hook.3. Fold the soft−top. Make sure to
place the soft−top between the rear
seat backs and tailgate.
CAUTION
With the soft−top opened, when the
rear seat is in the reclined position
or when reclining the rear seat, be
careful not to damage the soft−top
and not to get your head hit or in-
jured by the latch handles.
4. Take the latch handle cover out of
the glove box, put it over the latch
handle and fasten it securely with
Ve l c r o s .
ProCarManuals.com

Rav4(U)
262000 RAV4 (OM42479U)
—Raising the soft−top
RAISING THE SOFT−TOP
1. Remove the latch handle cover.
Store the removed cover in the glove
box.2. Raise the soft−top.
CAUTION
When raising the soft−top, keep
hands clear from any parts of the top
linkage.
3. Separate the latch handle and hook
while pressing the lock release but-
ton.
ProCarManuals.com

Rav4(U)
272000 RAV4 (OM42479U)
4. Set the hook, push up the latch han-
dle to securely lock it.
CAUTION
Try pushing and pulling the latch
handle to make sure it is securely
locked.
Try pushing the soft−top forward
and rearward to make sure it is se-
curely locked.
INSTALLING THE REAR WINDOW
1. Open the tailgate and engage the
zipper approximately 25 mm (1.0 in.).
CAUTION
The rear window must be securely
sealed to prevent exhaust gases from
coming into the occupant compart-
ment and causing serious personal
injury or death.
2. Align the retainer on the bottom of
the window with the groove.
CAUTION
Make sure the retainer on the rear
window is securely inserted into the
groove.
ProCarManuals.com

Rav4(U)
282000 RAV4 (OM42479U)
3. Fasten the zippers securely and
align the Velcros to secure the rear
window.INSTALLING THE QUARTER WINDOWS
1. Engage the zipper approximately 25
mm (1.0 in.).2. Insert the retainer on the side of the
window into the groove on the ve-
hicle side.
ProCarManuals.com

Rav4(U)
292000 RAV4 (OM42479U)
3. Insert the retainer on the bottom of
the window into the groove.
CAUTION
Make sure the retainers on the side
and bottom of the quarter window are
securely inserted into the grooves.
4. Fasten the zipper securely and align
the Velcros to secure the quarter
windows.5. Align the Velcros from the inside of
the vehicles.
ProCarManuals.com

Rav4(U)
302000 RAV4 (OM42479U)
ProCarManuals.com

Rav4(U)
312000 RAV4 (OM42479U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Seats, Seat belts, Steering wheel and Mirrors
Seats32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front seats32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seats34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flattening seatbacks38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head restraints40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat belts41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS driver and front passenger airbags50 . . . . . . . . . . . . . . . . . . . . . . . .
Child restraint57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt steering wheel74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirrors75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti−glare inside rear view mirror76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1− 3
ProCarManuals.com

Rav4(U)
322000 RAV4 (OM42479U)
Seats
While the vehicle is being driven, all ve-
hicle occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belts provided.
CAUTION
Do not drive the vehicle unless the
occupants are properly seated. Do
not allow sitting on top of a
folded−down seatback, or in the
luggage compartment. Persons not
properly seated and/or properly re-
strained by seat belts can be se-
verely injured in the event of emer-
gency braking or a collision.
During driving, do not allow pas-
sengers to stand up or move
around between seats. Severe inju-
ries can occur in the event of emer-
gency braking or a collision.
Adjust the driver’s seat so that the foot
pedals, steering wheel and instrument
panel controls are within easy reach of
the driver.
CAUTION
Adjustments should not be made
while the vehicle is moving, as the
seat may unexpectedly move and
cause the driver to lose control of
the vehicle.
When adjusting the seat, be careful
not to hit the seat against a pas-
senger or luggage.
After adjusting the seat position,
try sliding it forward and backward
to make sure it is locked in posi-
tion.
After adjusting the seatback, exert
body pressure to make sure it is
locked in position.
Do not put objects under the seats.
The objects may interfere with the
seat−lock mechanism or unexpect-
edly push up the seat position ad-
justing lever; the seat may suddenly
move, causing the driver to lose
control of the vehicle.
While adjusting the seat, do not put
your hands under the seat or near
the moving parts. You may catch
and injure your hands or fingers.
Front seats—
—Seat adjustment precautions
