NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle’s paint.
Replacing light bulbs—
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the ignition switch and
light switch are off. Use bulbs with the
wattage ratings given in the table.
CAUTION
Halogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if scratched
or dropped. Hold a bulb only by its
plastic or metal case. Do not touch
the glass part of a bulb with bare
hands.
NOTICE
Only use a bulb of the listed type.
Light bulbsBulbNo.WTy p e
Headlights (low beam)—55A
Headlights (high beam)900565B
Front fog light—55C
Parking lights—5D
Light bulbsBulb
No.WTy p e
Front turn signal
lights—21E
Front side marker
lights—5D
Rear turn signal
lights—21D
Stop and tail lights—21/5D
Back −up lights—18D
License plate lights—5D
Interior light
(with moon roof)—10E
Interior lights
(without moon roof)—8F
Glove box light—1.2D
Luggage
compartment light—5F
A: H7 halogen bulbs
B: HB3 halogen bulbs
C: H3 halogen bulbs
D: Wedge base bulbs
E: Single end bulbs
F: Double end bulbs
ProCarManuals.com

Celica_U
2342000 CELICA (OM20735U)
—Headlights (low beam)
1. Open the hood.
RIGHT SIDE HEADLIGHT: Remove the
clips and take out the cover. In doing
so, remove the washer hose from the
notch on the cover.
Remove and install the cover clips as
shown in the following illustrations.
Removing clip
Installing clip
ProCarManuals.com

Celica_U
2362000 CELICA (OM20735U)
5. RIGHT SIDE HEADLIGHT: Install thecover.
NOTICE
Always notch the washer hose before
fastening it when installing the cover.
This prevents washer hose damage.
—Headlights (high beam)
1. Open the hood.
RIGHT SIDE HEADLIGHT: Remove the
clips and take out the cover. In doing
so, remove the washer hose from the
notch on the cover.
Remove and install the cover clips as
shown in the following illustrations.
