Page 111 of 320
Instruments and controls3-17
–
CONTINUED –
CAUTION
Do not operate the washer continuously for more than ten se-
conds, or when the washer fluid tank is empty. This may cause
overheating of the washer motor. Check the washer fluid level fre-
quently, such as at fuel stops. Do not operate the wipers when the windshield or rear window
is dry. This may scratch the glass, damage the wiper blades and
cause the wiper motor to burn out. Before operating the wiper on
a dry windshield or rear window, always use the windshield
washer. In freezing weather, be sure that the wiper blades are not fro-
zen to the windshield or rear window before switching on thewipers. Attempting to operate the wiper with the blades frozen tothe window glass could cause not only the wiper blades to be
damaged but also the wiper motor to burn out. If the wiper bladeis frozen to the window glass, be sure to operate the defroster or
rear window defogger before turning on the wiper. If the wipers stop during operation because of ice or some oth-
er obstruction on the window, the wiper motor could burn outeven if the wiper switch is turned off. If this occurs, promptly stopthe vehicle in a safe place, turn the ignition switch to the “LOCK”
position and clean the window glass to allow proper wiper opera-tion. Use clean water if windshield washer fluid is unavailable. In
areas where water freezes in winter, use SUBARU Windshield
Washer Fluid or the equivalent. (See “Windshield washer fluid ”
section in chapter 10.)Also, when driving the vehicle when there are freezing tempera-tures, use non-freezing type wiper blades. Do not clean the wiper blades with gasoline or a solvent, such
as paint thinner or benzene. This will cause deterioration of thewiper blades.
Page 188 of 320
7-18n
Maximum allowable speeds
WARNING
When shifting down a gear, ensure that the vehicle is not travel- ling at a speed exceeding the Maximum Allowable Speed for thegear which is about to be selected. Failure to observe this pre-caution can lead to engine over-revving and this in turn canresult in engine damage.In addition, sudden application of engine brakes when the vehicleis travelling on a slippery surface can lead to wheel locking; as a
consequence, control of the vehicle may be lost and the risk ofan accident increased.
The following tab le shows the maximum sp eed s that a re p ossib le with
eac h d ifferent g ear.
Never exc eed the sp eed limit b elow for eac h g ear p o sition exc ep t for
b rief ac c eleration in an emerg enc y. The tac hometer ’s need le (if so
eq uip p ed ) will enter the red area if these sp eed s a re exc eed ed . Fail-
ure to ob seve this p rec aution c an lead to exc essive eng ine wear and
p oor fuel ec onomy.
mph (km/h)
Vehicle
type2.2 liter models2 5 litertype
Gear except OUTBACK
SPORTOUTBACKSPORT2.5 liter
RS models
1st29 (46)29 (47)28 (45)
2nd48 (77)49 (79)47 (76)
3rd70 (113)71 (115)68 (110)
Driving tips
Do not d rive with your foot resting on the c lutc h p ed al and d o not use
the c lutc h to hold your vehic le at a stand still on an up g rad e. Either of
those ac tions may c ause c lutc h d amag e.
Do not d rive with your hand resting on the shift le ver. This may c ause
wear on the transmission c omp onents.
Page 244 of 320
9-2
Exterior care
Washing
CAUTION
When washing the vehicle, the brakes may get wet. As a result,
the brake stopping distance will be longer. To dry the brakes, drive the vehicle at a safe speed while lightly pressing the brakepedal to heat up the brakes. Do not wash the engine compartment and areas adjacent to it.
If water enters electrical parts or the power steering fluid reser-
voir, it will cause engine trouble or faulty power steering respec-
tively.
The b est way to p reserve your vehic le ’s b eauty is freq uent washing .
Wash the vehic le at least onc e a month to avoid c on tamination b y road
g rime.
Wash d irt off with a wet sp ong e and p lenty of lukew arm or c old water. Do
not wash the vehic le with hot water and in d irec t s unlig ht.
Salt, c hemic als, insec ts, tar, soot and b ird d rop p i ng s should b e washed
off b y using a lig ht d eterg ent, as req uired . If you use a lig ht d eterg ent,
make c ertain that it is a neutral d eterg ent. Do not use strong soap or
c hemic al d eterg ents. All c leaning ag ents should b e p romp tly flushed
from the surfac e and not allowed to d ry there. Rins e the vehic le thor-
oug hly with p lenty of lukewarm water. Wip e the rema ining water off with a
c hamois or soft c loth. NOTE When having your vehicle washed in an automatic car wash, make
sure beforehand that the car wash is of suitable type. If the vehicle
is equipped with a rear spoiler, it may be damaged by the brush, etc.
Washing the underbody
Chemic als, salts, and g ravel used for d eic ing road surfac es are ex-
tremely c orrosive, ac c elerating the c orrosion of un d erb od y c omp o-
nents, suc h as the exhaust system, fuel and b rake l ines, b rake
