2000 SUBARU IMPREZA dashboard

Seat, seat belt and SRS airbag2-29
–
CONTINUED –
HB0307
Never allow a child to stand up, or to kneel on the front passenger ’s
seat
HB0308
Never hold a child on your lap or in your arms.
WARNING
Do not put any objects over the steering wheel pad and dash-
board. If the SRS airbag deploys, those objects could interfere
with its proper operation and could be propelled inside the vehi-
cle and cause injury. Do not attach accessories to the windshield, or fit an extra-
wide mirror over the rear view mirror. If the SRS airbag deploys,those objects could become projectiles that could seriously in-jure vehicle occupants.
HS0245
HS0244
Do not put any objects over the steering wheel pad and dashboardDo not attach accessories to the windshield, or fit an extra-wide mir-
ror over the rear view mirror.

Seat, seat belt and SRS airbag2-31
–
CONTINUED –

Components
HG0287
Front sub sensor (Left hand side)
SRS airbag module
(Driver’
s side)
Front sub sensor (Right hand side)
SRS airbag module
(Passenger’s side)
SRS airbag control module (including impact sensors)
SRS airbag operation
CAUTION
Do not touch the SRS airbag system components around the steering wheel and dashboard with bare hands right after deploy-ment. Doing so can cause burns because the components can bevery hot as a result of deployment.

Seat, seat belt and SRS airbag2-37
–
CONTINUED –

SRS airbag system servicing
WARNING
When discarding an airbag module or scrapping the entire car
damaged by a collision, consult your SUBARU dealer. The SRS airbag has no user-serviceable parts. Do not use
electrical test equipment on any circuit related to the SRS airbag
system. For required servicing of the SRS airbag, see your near-
est SUBARU dealer. Tampering with or disconnecting the sys-
tem’ s wiring could result in accidental inflation of the SRS airbag
or could make the system inoperative, which may result in seri-
ous injury. The wiring harnesses of the SRS airbag system arecovered with yellow insulation and the system connectors areyellow for easy identification.
CAUTION
If you need service or repair in areas listed below, we recommend
that you have an authorized SUBARU dealer perform the work. The
SRS airbag control module, impact sensors and airbag modules
are stored in these areas.
Under the center console
Inside each front fender
Steering wheel and column and nearby areas
Top of the dashboard on front passenger ’s side and nearby
areas
In the event that the SRS airbag is deployed, replacement of the sys-
tem should be performed only by an authorized SUBARU dealer.When the components of the SRS airbag system are replaced, useonly genuine SUBARU parts.
To ensure their long -term reliab ility, the SRS airb ag s must b e insp ec ted
b y a SUBARU d ealer ten years after the d ate of manu fac ture, whic h is
shown on the c ertific ation lab el attac hed to the d r iver’s d oor.

2-38NOTE In the following cases, contact your SUBARU dealer as soon as pos- sible.
The front part of the vehicle was involved in an accident in
which the SRS airbags did not deploy. The pad section of the steering wheel or front passenger ’s air-
bag cover is scratched, cracked, or otherwise damaged.
Precautions against vehicle modification
WARNING
To avoid accidental activation of the system or rendering the
system inoperative, which may result in serious injury, no modifi-cations should be made to any components or wiring of the SRSairbag system.This includes following modifications: Installation of custom steering wheel
Attachment of additional trim materials to the dashboard
Installation of additional electrical/electronic equipment such
as a mobile two-way radio on or near the SRS airbag system
components and/or wiring is not advisable. This could interferewith proper operation of the SRS airbag system.
CAUTION
Do not perform any of the following modifications. Such modifi-cations can interfere with proper operation of the SRS airbag sys-tem.
Attachment of any equipment (brush bar, winches, snow
plow, skid plate, etc.) other than SUBARU genuine accessoryparts to the front end Modification of the suspension system or front end structure
Installation of a tire of different size and construction from
the original tires listed on the tire placard attached to the doorjamb

6
Interior equipment Sun visors6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vanity mirror (if equipped) 6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage compartment 6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove compartment 6-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center console 6-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dashboard storage compartment 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coin tray 6-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holder 6-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessory power socket 6-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter (if equipped) 6-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtray 6-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coat hook 6-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior light 6-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome/Rear map reading light (if equipped) 6-13 . . . . . . . . . . . . . . . . . . . . . .
Spotlight (if equipped) 6-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gauge pack (if equipped) 6-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage cover (Wagon only) 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shopping bag hook (Wagon only) 6-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo anchorage eyelets (if equipped) 6-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance tools 6-28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Interior equipment
6-5
–
CONTINUED –

Dashboard storage compartment
HS0094
Push
To op en the d ashb oard c omp artment, p ush the b utton and p ull up on the
lid . Be sure to c lose the c omp artment fully b efore d riving .
Coin tray
HS0096
To op en the c oin tray, p ull the up p er ed g e of the l id .
