Downloaded from www.Manualslib.com manuals search engine FABIA 2000➤Inspection and Maintenance
BodyEdition 09.04
S00.5301.14.2002-7 page 6 02
–Separate filter element from the frame.
Installing:
Installation is carried out in the reverse order.
Sticking the vehicle data sticker
–Stick the vehicle data sticker to the floor of the luggage
compartment inside the vehicle next to the spare
wheel -arrow-.
Inspect trailer coupling
Inspect condition of trailer coupling support
–Inspect condition of cavity of tensioning sleeve.
–Clean cavity of tensioning sleeve and treat with G 052
778 A2.
–Check cap of tensioning sleeve.
If the cap of the tensioning sleeve is missing or damaged,
replace with a new one.
Inspect condition of trailer arm
–Check whether the control lever turns.
If the control lever turns with difficulty or does not turn, the
seized eccentric in the trailer arm housing must be
cleaned and treated with G 052 778 A2. If it is does not
improve, then the trailer arm must be sent back to the
manufacturer for repair or replaced with a new one (repair
measure).
–Check the turning of the key in the lock.
If the securing bolt moves with difficulty or does not move
at all; the reasons for this may be:
♦Lock is defective ⇒ replace bolt with lock (repair
measure)
♦Bent control lever ⇒ must be repaired by the manu-
facturer or replace trailer arm (repair measure)
♦Clean seized bolt ⇒, treat with G 052 778 A2 and
bring into motion. If it is does not improve, then the
trailer arm must be sent back to the manufacturer for
repair or replaced with a new one (repair measure).
S02-0310
S02-0322

Downloaded from www.Manualslib.com manuals search engine FABIA 2000➤Inspection and Maintenance
BodyEdition 09.04
S00.5301.14.2002-7 page 7 02
When applying G 052 778 A2 make sure that the product
does not penetrate into the gap between the lock bolt,
control lever, eccentric and trailer arm housing.
Trailer coupling: Check for proper operation
–Tighten trailer arm in the tensioning sleeve.
–Close lock and remove key.
–Check for correct closing by turning the control lever
downwards.
Note
WARNING!
If one of the measures cannot be carried out or if
the closed lever can be turned to an angle greater
than 5 , the trailer coupling is damaged and must
not be operated. The fault must be identified and
the damaged components must be replaced (repair
measure).

Downloaded from www.Manualslib.com manuals search engine FABIA 2000➤Inspection and Maintenance
Exhaust-emission AnalysisEdition 09.04
S00.5301.14.2002-8 page 5 02
All tubes and plug connections, which had been removed
or disconnected for the test and adjustment, must be re-
inserted or connected.
Technical data of the spark plugs Chapter 02-3.
Exhaust-Emission Analysis on Models
with Diesel Engines
♦When possible the test should be carried out immedi-
ately after the road test and also outdoors. If specific
reasons prevent this (weather conditions, excessive
noise in residential areas) the test may also be per-
formed in the workshop.
♦Secure the engine bonnet in the first stop while meas-
uring to reduce the noise.
Visual inspection
♦Hose for crankcase ventilation is connected
♦Fuel system and injection pump must be tight
♦The exhaust system must be undamaged and tight
♦All vacuum hoses are connected
Test and setting conditions
•Engine oil temperature at least 80 °C
•All electrical components disconnected
•No fault stored in the fault memory ⇒Chapter 02-6,
connect vehicle system tester and interrogate fault
memory
Correct detected faults before measuring (repair meas-
ure).
Connect the test equipment
–Connect the tester in compliance with the operating
instructions.
–Start engine, warm up to normal temperature and run
in idle.
–Perform the exhaust-emission analysis.
♦Activate and inspect auxiliary equipment such as e.g.
power steering, automatic gearbox or air conditioning
system. Check whether the engine continues to run
perfectly under this load.
♦All tubes and plug connections, which had been re-
moved or disconnected for the test and adjustment,
must be re-inserted or connected.
