2000 SAAB 9-3 headlight bulb

4Exterior Sunroof _______________ 120
Convertible _____________ 42
Washing the car ________ 201
Waxing and polishing ____ 202
Touching-up of paintwork _ 202
Anticorrosion treatment ___ 203
Service program ________ 215Taillights ______________ 183
Stop lights _____________ 183
Light switches ___________ 71
Changing bulbs _________ 181Towing ________________ 160
Towrope attachment eyes _ 160
Towing a trailer _________ 156Trunk lid lock ___________ 125
Lowering the rear seat ____ 125
Trunk _________________ 128
Spare wheel ___________ 130
Tools _________________ 130
Lighting _______________ 183
Driving with a roof rack load ____ 158
Mounting of roof rack __________ 158
Maximum loads ______________ 220
Hood release handle __________ 168
Engine compartment: washing __ 201
Central locking __________ 30
Interior locking buttons ____ 31
Trunk lock ______________ 33
Child safety lock catch ____ 33
Car alarm (Anti-theft alarm) 35Headlight switches _______ 71
High/low beam control stalk 71
Turn signal & lane change
indicators ______________ 72
Headlamp wipers _______ 180
Changing bulbs ________ 181Fuel filler door __________ 138
Refuelling _____________ 138
Fuel grade ____________ 224
Fuel gauge _____________ 61
Fuel economy __________ 153
Tires & Rims _____________ 192 / 227
Driving in cold weather ________ 154
Brakes and braking ___________ 149
Compact spare wheel _________ 195
Changing a wheel ____________ 196
ProCarManuals.com

181 Car care
Changing bulbs Headlight 1 Unscrew the cover from the back of the light units.
2 Unplug the connector.
3 Unhook the spring clip by pushing it forward and then to the side.
4 Remove the bulb.
5 Insert the new bulb, without touching the glass with your fingers.
Line it up so that the three lugs fit into the corresponding slots in
the reflector and secure it with the spring clip.IMPORTANT! When changing bulbs, use the same type of bulb,
(e.g. Long-life).
Headlight aiming, see page 208.
Parking lights The parking-light bulb is fitted in the same light unit as the headlight
bulb.
1 Remove the bulb holder from the lamp unit.
2 Then take the bulb out of the holder.
WARNING
Before changing a bulb in the engine bay, switch off the engine
to avoid the danger of fingers and hands being injured by
moving parts.
The radiator fan can cut in even when the engine is switched off. NOTESwitch off the ignition before changing a bulb, to avoid possible
short-circuiting. NOTEDo not fit bulbs with a rating above 60/55W, since the headlight
reflector and the wiring of the car are not designed for a higher
wattage.
Do not touch the glass of the bulbs with your fingers. The oil on
your skin can shorten the life of the bulb.
IB903
1 Headlight bulb
2 Parking-light bulb
ProCarManuals.com

182 Car careFront turn signal bulb To change the bulb, the complete lamp unit has to be removed.
1 Loosen the screw (1). There is no need to remove it completely.
2 Carefully remove the complete lamp unit.
3 Grasp the two plastic tabs and turn the bulb holder counterclock-
wise.
4 Pull the bulb holder out of the lamp unit and change the bulb.
5 Check that the new bulb is firmly in place and has good contact.
6 When mounting the lamp unit, see that the two guide lugs on the
rear edge of the unit come inside the edge of the body panel.
7 Insert the lamp unit in towards the headlight and see that the
front bracket comes under the screw. Tighten the screw (1).
Side-mounted turn signal1 Slide the lens forward so that its rear part can be pulled out.
2 Change the bulb.
3 When refitting, make sure that the groove in the spring engages
the edge of the body panel and that the rubber gasket is correctly
positioned.
IB904
1 Retaining screw
2 Turn signal bulb
IB906
ProCarManuals.com

186 Car care
Bulb tableNo. Wattage Cap
1 60/55 P 43t-38 Headlight
2 55 P 14.5s Front fog light
3 1,2 W 2 x 4.6d Ashtray; cigarette lighter; warning
light for safety belts
4 21 BA 15s Rear fog light; reversing light
5 21/5 BAY 15d Stop/taillight
6 PY 21 yel BAU 15s Direction indicator, front/rear
7 5 BA9 Reading lamps, rear (Coupé and
5-door)
8 10 SV 8.5 Dome light; trunk; glove compart-
ment
95 W 2.1 x
9.5d Side indicators; license plate light-
ing; parking lights; reading lamps,
front; reading lamps, rear (Convert-
ible) NOTEDo not change any bulbs with ones of another wattage: only use
what is stated.
IB1330
ProCarManuals.com

233 Index
Index
AA/C system, fault diagnosis
_______ 207
A/C system, maintenance
_________ 207
ACC
__________________________ 80
ACC, useful tips
_________________ 88
Adjustment, steering wheel
________ 118
Air conditioning (A/C),
fault diagnosis and maintenance
__ 207
Airbag
_________________________ 22
Alarm _________________________ 35
Alarm functions
__________________ 38
Alarm signals
___________________ 38
Anticorrosion treatment
___________ 203
Anti-theft safety, alarm ____________ 35
Ashtray
_______________________ 123
Audio System
___________________ 90
Automatic climate control (ACC)
_____ 80
Automatic transmission
___________ 141
BBattery
_______________________ 177
Boost starting from donor battery
___ 162
Brake fluid, check
_______________ 176
Brake fluid, grade _______________ 227
Brake pad wear indicators
________ 176
Brakes
________________________ 149Braking
_______________________ 149
Bulb table _____________________ 186
CCD changer
____________________ 101
CD player
______________________ 99
CHECK messages
____________ 63
, 68
CHECKING
__________________ 63
, 68
Cabin lighting
__________________ 121
Calibration, ACC _________________ 86
Car alarm
______________________ 35
Car phone, installation
___________ 109
Cassette player
__________________ 96
Center console compartment
______ 123
Central locking
__________________ 30
Change of address notification
_____ 214
Changing a wheel
_______________ 196
Changing bulbs
_________________ 181
Changing the coolant
____________ 175
Changing the engine oil __________ 173
Changing wiper blades
___________ 179
Chassis number
________________ 229
Child car seats
__________________ 18
Child safety
_____________________ 18
Child safety locks, rear doors
_______ 33
Child seats
_____________________ 18
Cigar lighter ____________________ 123
Cleaning the soft top
______________ 51
Climate-control system, manual
_____ 76
Clock
__________________________ 69Condensation water, A/C
__________ 78
Condensation water, ACC __________ 81
Convertible
_____________________ 42
Coolant
_______________________ 174
Courtesy Headlight Feature
________ 72
Cruise Control
__________________ 148
Cup holder
_____________________ 122
DDICE/TWICE
___________________ 188
Date code, tires _________________ 195
Dim low beam
___________________ 71
Dimmer
________________________ 74
Direction indicators
_______________ 72
Direction-indicator stalk
____________ 72
Dome lighting
__________________ 121
Door mirrors
___________________ 124
Drive belt
______________________ 179
Driving in deep water
_____________ 166
Driving in hot weather ____________ 156
Driving technique
________________ 153
Driving with a compact spare wheel
_ 165
Driving with a roof load
___________ 158
Driving with the trunk lid open
______ 166
EEconomical motoring
_____________ 153
Electrical system, technical data
____ 225
ProCarManuals.com
