2000 PONTIAC GRAND PRIX Owners Manual

2-93
RANGE: Shows how much farther you can travel with
the fuel you have before refueling. When the range
displays ªLº, for 40 to 50 miles (64.36 to 80.45 km),
the display will flash the word LOW continuously and
the vehicle will chime three times. The range is
calculated from the average econ value times the fuel
remaining in the tank.
LOW: This light will come on when the ignition is on
and the fluid in the washer fluid container is low.
DOOR AJAR: If one of the doors is left ajar, a light
will appear next to that door on the vehicle outline.
BOOST GAGE: If you have the 3800 V6 supercharged
engine, this gage will show the amount of boost the
engine is receiving.
TRUNK AJAR: If the trunk is not fully closed or open,
a light will outline the trunk area on the vehicle outline.LOW TRAC: This light will come on when the traction
control system is limiting wheel spin. See ªTraction
Control Systemº or ªLow Traction Lightº in the Index.
TRAC/TCS OFF: This light lets you know that the
traction control system has been disabled and will not
limit wheel spin. See ªTraction Control System Warning
Lightº or ªLow Traction Lightº in the Index.
TRAC/TCS: If the vehicle has the traction control
system, you will have a disable switch on the far right
side of the trip computer. The traction control system is
automatically activated when you turn the ignition on.
This switch will activate/deactivate the traction control
system. If you need to disable the system, such as when
you are stuck and are rocking the vehicle back and forth,
push this switch. See ªStuck: In Sand, Mud, Ice or
Snowº in the Index.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Air Conditioning with Electronic Controls
3
-4 Air Conditioning with Automatic and
Auxiliary Temperature Control (If Equipped)
3
-8 Rear Window Defogger
3
-9 Ventilation System
3
-10 Audio Systems
3
-10 Setting the Clock
3
-10 AM-FM Stereo with Cassette Tape Player
3
-14 AM-FM Stereo with Compact Disc Player
(If Equipped)
3
-17 AM-FM Stereo with Compact Disc Player and
Equalizer (If Equipped)3
-20 Trunk-Mounted CD Changer (Option)
3
-23 Theft-Deterrent Feature
3
-26 Audio Steering Wheel Controls (If Equipped)
3
-27 Understanding Radio Reception
3
-27 Tips About Your Audio System
3
-28 Care of Your Cassette Tape Player
3
-29 Care of Your Compact Discs
3
-29 Care of Your Compact Disc Player
3
-29 Fixed Mast Antenna
3
-30 Backglass Antenna (If Equipped)

3-2
Comfort Controls
Air Conditioning with Electronic Controls
With this system, you can control the heating, cooling
and ventilation in your vehicle. The system works best if
you keep your windows closed while using it.
Fan Knob
The left knob selects the amount of air you want. To turn
the fan off, turn the knob to OFF. The fan must be on to
run the air conditioning compressor.Temperature Knob
The center knob changes the temperature of the air
coming through the system. Turn this knob toward red
(clockwise) for warmer air. Turn it toward blue
(counterclockwise) for cooler air.
Mode Knob
The right knob has several settings to control the
direction of airflow:
MAX: This setting recirculates much of the air
inside your vehicle and sends it through the instrument
panel outlets. The air conditioning compressor will run
automatically in this setting unless the outside
temperature is below 38
F (3.3
C). (Even when the
compressor is running, you can control the temperature.)
UPPER: This setting brings in outside air and
directs it through the instrument panel outlets.
BI-LEVEL: This setting brings in outside air and
directs it two ways. Half of the air is directed through
the instrument panel outlets. Most of the remaining air is
directed through the floor ducts and a small amount to
the defrost and side window vents.

3-3
FLOOR: This setting sends most of the air
through the ducts near the floor. The remaining airflow
comes out of the defroster and side window vents.
DEFOG: This setting allows half of the air to go
to the floor ducts and half to the defroster and side
window vents.
DEFROST: This setting directs most of the air
through the defroster. Some of the air goes to the floor
ducts and the side window vent. The air conditioning
compressor will run automatically in this setting unless
the outside temperature is below 38
F (3.3
C).
Air Conditioning Compressor Button
Press the A/C button to operate the air conditioning
compressor. The indicator light above the button will
glow when the button is pressed. You don't have to
press the button to run the compressor in MAX or
DEFROST because it will already be running in
these modes.Air Conditioning
On very hot days, open the windows long enough to let
hot, inside air escape. This reduces the time for the
vehicle to cool down.
For quick cool
-down on very hot days, use MAX with
the temperature knob all the way in the blue area. If this
setting is used for long periods of time, the air in your
vehicle may become too dry.
For normal cooling on hot days, use UPPER with the
temperature knob in the blue area and the A/C button
pushed in. The system will bring in outside air and
cool it.
On cool, but sunny days, the sun may warm your upper
body, but your lower body may not be warm enough.
You can use BI
-LEVEL with the temperature knob in
the middle and the A/C button pushed in. The system
will bring in outside air and direct it to your upper body,
while sending slightly warmed air to your lower body.
You may notice this temperature difference more at
some times than others.

3-4
Heating
On cold days use FLOOR with the temperature knob all
the way in the red area. The system will bring in outside
air, heat it and send it to the floor ducts.
If your vehicle has an engine coolant heater, you can use
it to help your system provide warm air faster when it's
cold outside 0
F (
-18
C) or lower. An engine coolant
heater warms the coolant your engine and heating
system use to provide heat. See ªEngine Coolant
Heaterº in the Index.
Ventilation
For mild outside temperatures when little heating or
cooling is needed, use UPPER, with the A/C button off,
to direct outside air through your vehicle. Your vehicle
also has the flow
-through ventilation system described
later in this section.
Defogging and Defrosting
Your system has two settings for clearing the front and
side windows. To defrost the windows quickly, use
DEFROST with the temperature knob all the way in the
red area. To warm passengers while keeping the
windows clear, use DEFOG.
Air Conditioning with Automatic and
Auxiliary Temperature Control
(If Equipped)
With this system, you set a ªdesired cabinº temperature.
You can then either let the system automatically control
airflow direction and amount (to maintain the desired
cabin temperature) or you can manually adjust it. The
system works best if you keep your windows closed
while using it.

3-5 Automatic Control
For the most efficient operation, you should set the
system temperature and press AUTO. The system will
select the best fan speed and airflow settings to keep you
comfortable. The air conditioning compressor will run if
the outside temperature is above 38
F (3.3
C).
You may notice a delay of three to four minutes before
the fan comes on.
Driver's Temperature Knob
The left knob sets the temperature for the entire system
when the light on DUAL button isn't lit. If the light is
lit, the knob sets the temperature for the driver. Turn the
knob toward red (clockwise) to raise the desired cabin
temperature. Turn it toward blue (counterclockwise) to
lower the temperature. The display will show your
selection for a few seconds, then the outside temperature
will be displayed.
Passenger's Temperature Knob
The right knob sets the desired cabin temperature for the
passenger and will automatically force the system into a
dual zone operation, lighting the dual zone button light.
Turn the right knob toward red (clockwise) to raise the
temperature. Turn it toward blue (counterclockwise) to
lower the temperature.Dual Zone Button Light
The dual zone button light indicates whether the system
is in single zone or dual zone operation. When there is
no desire for dual zone operation, push the lit dual zone
button to return to single zone operation. The dual zone
button light will go off.
The system will operate to achieve your comfort set
point as quick as possible. If you set the temperature for
60
F (16
C) or 90
F (32
C), the fan will go to its
highest speed, unless you manually select a lower speed.
The system will maintain full cold or full hot operation
at these settings.
Cold Weather Example: When you start the vehicle in
cold weather, (below freezing) or after being parked
overnight. If your Driver Set Temperature is 73
F (23
C)
and you are in Full Automatic mode, the system will
automatically move the temperature doors to full hot.
The blower will start out at a low speed and the blower
speed will increase as the engine warms up. The air will
be delivered to the floor. As the interior of the vehicle
warms up to your desired comfort point, the blower will
decrease and the temperature door will move to a cooler
position to maintain your desired comfort. As the cabin
warms up or the sun load increases the system could
switch to air delivered to the individual to the windshield
and the floor (DEFOG mode).

3-6
Hot Weather Example: When you start the vehicle in
hot weather, 80
F (27
C) or after being parked during
the day in full sun, if your Driver Set Temperature is
73
F (23
C) and you are in Full Automatic mode, the
system will automatically move the temperature doors to
full cold. The blower will be at low speed momentarily
and then go to the high speed. The air intake will be
recirculated for maximum cooling performance. As the
interior of the vehicle cools down to your desired
comfort point, the blower will decrease and the
temperature door will move to a warmer position to
maintain your desired comfort. As the cabin cools down
or the sun load decreases the system could switch to air
delivered to A/C vents and the floor (BI
-LEVEL mode).
Manual Control
Fan Buttons
The fan buttons select the amount of air you want when
the system is not in AUTO. The display will show the
fan speed by illuminating a maximum of seven fan bars.Mode Button
The center panel has several settings to control the
direction of airflow when the system is not in AUTO.
The indicator light on the button will glow when the
button is pressed. To access the various modes available,
continue to press the MODE button until the desired
mode appears on the display.
If you prefer to manually control the heating, cooling
and ventilation in your vehicle, push UPPER, BI
-LEV,
LOWER, DEFOG or DEF. AUTO will go off the
display. Set the system to the temperature and fan speed
you want. The system will try to maintain the
temperature you set using the mode you select. The
following suggestions will help the system run more
efficiently in manual mode.
RECIRC: This setting recirculates much of the
air inside your vehicle and sends it through the
instrument panel outlets. The air conditioning
compressor will run automatically in this setting unless
the outside temperature is below 38
F (3.3
C).
Please note that operating the system in the
RECIRCULATION mode may cause fogging of the
windows when the weather is cold and damp. To clear
the fog, select either the DEFOG or DEFROST mode
and increase the fan speed. To avoid re
-fogging of the
windows, use the OUTSIDE AIR mode.

3-7
UPPER: This setting brings in the outside air and
directs it through the instrument panel outlets.
BI-LEV: This setting brings in the outside air and
directs it two ways. Half of the air is directed through
the instrument panel outlets. Most of the remaining air is
directed through the floor ducts and a little to the defrost
and side window vents.
LOWER: This setting sends most of the air
through the ducts near the floor. The remaining airflow
comes out of the defroster and side window vents.
Please note that the windows may fog up when using
this setting. See ªRecirculationº in the Index for
more information.
DEFOG: This setting allows half of the air to go
to the floor ducts and half to the defroster and side
window vents.
DEF: This setting directs most of the air through
the defrost vent. Some of the air goes to the floor ducts
and the side window vents. The air conditioning
compressor will run automatically in this setting unless
the outside temperature is below 38
F (3.3
C).Air Conditioning
On very hot days, open the windows long enough to let
hot, inside air escape. This reduces the time for the
vehicle to cool down.
For quick cool
-down on very hot days, use RECIRC.
If this setting is used for long periods of time, the air in
your vehicle may become too dry.
For normal cooling on hot days, use UPPER with the
A/C button pushed in. The system will bring in outside
air and cool it.
On cool, but sunny days, the sun may warm your upper
body, but your lower body may not be warm enough.
You can use BI
-LEV with the A/C button pushed in.
The system will bring in outside air and direct it to your
upper body, while sending slightly warmed air to your
lower body. You may notice this temperature difference
more at some times than others.
