2000 NISSAN MAXIMA jump start

6 In case of emergencyFlat tire ...................................................................... 6-2
Changing a flat tire .................................................... 6-2
Jump starting............................................................. 6-7
Push starting ............................................................. 6-9If your vehicle overheats ......................................... 6-10
Towing your vehicle ................................................ 6-11
Towing recommended by NISSAN ......................... 6-11
Vehicle recovery (Freeing a stuck vehicle) ............. 6-12
Z
00.1.17/A33-D/V5.0
X

Stowing the damaged tire and toolsSecurely store the spare tire and jacking
equipment in the vehicle.
WARNING
IAlways make sure that the spare tire
and jacking equipment are properly
secured after use. Such items can
become dangerous projectiles in an
accident or sudden stop.
IThe T-type spare tire and small sizespare tire are designed for emer-
gency use. See ªTires and wheelsº in
the ª8. Do-it-yourselfº section.To start your engine with a booster battery, the
instructions and precautions below must be
followed.
WARNING
IIf done incorrectly, jump starting can
lead to a battery explosion, resulting
in severe injury or death. It could also
damage your vehicle.
IExplosive hydrogen gas is always
present in the vicinity of the battery.
Keep all sparks and flames away from
the battery.
IDo not allow battery fluid to come
into contact with eyes, skin, cloth or
painted surfaces. Battery fluid is a
corrosive sulphuric acid solution
which can cause severe burns. If the
fluid should come into contact with
anything, immediately flush the con-
tacted area with water.
IKeep battery out of the reach of
children.
SCE0040
JUMP STARTING
In case of emergency
6-7
Z
00.1.17/A33-D/V5.0
X

IThe booster battery must be rated at
12 volts. Use of an improperly rated
battery can damage your vehicle.
IWhenever working on or near a bat-
tery, always wear suitable eye protec-
tors (for example, goggles or indus-
trial safety spectacles) and remove
rings, metal bands, or any other jew-
elry. Do not lean over the battery
when jump starting.
IDo not attempt to jump start a frozen
battery. It could explode and cause
serious injury.
IYour vehicle has an automatic engine
cooling fan. It could come on at any
time. Keep hands and other objects
away from it.
WARNING
Always follow the instructions below.
Failure to do so could result in damage
to the charging system and cause per-
sonal injury.
1. If the booster battery is in another vehicle,
position the two vehicles to bring their bat-
teries into close proximity to each other.
Do not allow the two vehicles to touch.
2. Apply parking brake. Move the shift lever tothe N (Neutral) position (On automatic
transmission models, move the selector
lever to the P (Park) position). Switch off all
unnecessary electrical systems (light,
heater, air conditioner, etc.).
3. Remove vent caps on the battery (if so
equipped). Cover the battery with an old
cloth to reduce explosion hazard.
4. Connect jumper cables in the sequence as
illustrated.
SCE0154A
6-8
In case of emergency
Z
00.1.17/A33-D/V5.0
X

IBattery posts, terminals and related
accessories contain lead and lead
compounds. Wash hands after han-
dling.
IKeep the battery out of the reach of
children.
Check the fluid level in each cell. It should be
between the MAX and MIN lines.
If it is necessary to add fluid, add only distilled
water to bring the level to the indicator in each
filler opening.Do not overfill.
1. Remove the cell plugs.
2. Add distilled water up to the MAX level.
3. Tighten cell plugs.If jump starting is necessary, see ªJump start-
ingº the ª6. In case of emergencyº section. If
the engine does not start by jump starting, the
battery may have to be replaced. Contact your
NISSAN dealer.
DI0137M
8-14
Do-it-yourself
Z
00.1.17/A33-D/V5.0
X

Filler lid ...................................................... 3-10
Filler lid and cap ........................................ 3-10
Filler lid opener lever................................. 3-10
Fuel economy ............................................ 5-16
Fuel octane rating ..................................... 10-3
Fuel recommendation................................ 10-3
Gauge .......................................................... 2-5
Fuses .............................................................. 8-21
Fusible links .................................................... 8-22
G
Garage door opener, Integrated HomeLink
Universal Transceiver ..................................... 2-33
Gas cap .......................................................... 3-10
Gauge ............................................................... 2-3
Engine coolant temperature gauge ............. 2-5
Fuel gauge .................................................. 2-5
Odometer..................................................... 2-4
Speedometer ............................................... 2-4
Tachometer ................................................. 2-4
General maintenance ................................ 9-2, 9-3
Glasses case .................................................. 2-24
Glove box........................................................ 2-25
Glove box lock ................................................ 2-25
H
Hazard warning flasher switch........................ 2-20
Head restraints ................................................. 1-7
Headlamps, (Bulb replacement) ..................... 8-26
Headlights, (Bulb replacement) ...................... 8-26Headlights, Headlight switch........................... 2-17
Heated seats................................................... 2-21
Heater
Engine coolant heater ............................... 5-22
Heater and air conditioner controls ............. 4-3
Heater operation.......................................... 4-3
Operation, Semiautomatic air conditioner ... 4-4
HomeLink
Universal Transceiver .................. 2-33
Hood, release ................................................... 3-8
Horn ................................................................ 2-20
How to stop alarm, Theft warning .................. 2-13
I
Ignition switch ................................................... 5-4
Automatic transmission models .................. 5-4
Key positions ............................................... 5-6
Manual transmission models....................... 5-5
Immobilizer system ......................................... 2-13
Indicator lights and chimes (See warning/indicator
lights and chimes) ............................................. 2-9
Inside mirror .................................................... 3-13
Inspection/maintenance (I/M) test................. 10-20
Instrument panel ............................................... 2-2
Integrated HomeLink
Universal
Transceiver ..................................................... 2-33
Interior and cargo light .................................... 2-30
Interior light ..................................................... 2-30
Interior light replacement ................................ 8-27J
Jump starting .................................................... 6-7
K
Keyless entry, (See multi-remote control
system) ............................................................. 3-4
Keys .................................................................. 3-2
L
Label, Air conditioner specification label ...... 10-12
Label, Emission control information label ..... 10-11
Label, F.M.V.S.S. certification label.............. 10-11
Labels
Air bag warning labels............................... 1-19
Air conditioner specification label................ 4-3
Engine serial number .............................. 10-11
Vehicle identification number (VIN)......... 10-10
License plate, Installing front license plate... 10-13
Light
Air bag warning light ................................. 1-18
Bulb replacement ...................................... 8-25
Fog light switch ......................................... 2-19
Headlamps (Bulb replacement)................. 8-26
Headlight switch ........................................ 2-17
Headlights (Bulb replacement) .................. 8-26
Interior and cargo light .............................. 2-30
Interior light................................................ 2-30
Personal light............................................. 2-31
Z
00.1.17/A33-D/V5.0
X
11-3

Rear door lock, Child safety rear door lock...... 3-4
Rear seat adjustment ....................................... 1-6
Rear window and outside mirror defogger
switch .............................................................. 2-16
Registering your vehicle in another
country .......................................................... 10-10
Remote keyless entry, (See multi-remote control
system) ............................................................. 3-4
Reporting safety defects (USA only) ............ 10-20
Rollover ............................................................. 5-3
S
Safety
Child seat belts.......................................... 1-22
Reporting safety defects (USA only)....... 10-20
Towing safety .......................................... 10-17
Seat adjustment
Front manual seat adjustment .................... 1-2
Front power seat adjustment ...................... 1-4
Rear seat adjustment .................................. 1-6
Seat belt extenders......................................... 1-27
Seat belt maintenance .................................... 1-27
Seat belt warning light .................................... 1-20
Seat belt warning light and chime .................... 2-8
Seat belt(s)
Child safety................................................ 1-22
Infants and small children ......................... 1-23
Injured persons.......................................... 1-24
Larger children .......................................... 1-23
Pre-tensioner seat belt system ................. 1-17
Precautions on seat belt usage ................ 1-20
Pregnant women ....................................... 1-23Seat belt cleaning........................................ 7-5
Seat belts .................................................. 1-20
Three-point type with retractor .................. 1-24
Seat(s), Seats ................................................... 1-2
Seats, Heated seats ....................................... 2-21
Security system (Nissan Vehicle Immobilizer
System), Engine start ..................................... 2-13
Security systems (See theft warning) ............. 2-12
Servicing air conditioner .......................... 4-3, 4-11
Shift lock release ............................................ 5-10
Shifting
Automatic transmission ............................... 5-8
Manual transmission ................................. 5-11
Shoulder belt height adjustment, For front
seats ............................................................... 1-27
Side air bag system (See supplemental side air
bag system) .................................................... 1-16
Spark plugs ..................................................... 8-15
Speedometer .................................................... 2-4
Starting
Before starting the engine ........................... 5-7
Jump starting ............................................... 6-7
Precautions when starting and driving ........ 5-2
Push starting ............................................... 6-9
Starting the engine ...................................... 5-7
Steering
Power steering fluid................................... 8-11
Power steering system .............................. 5-18
Tilting steering wheel ................................ 3-12
Storage ........................................................... 2-23
Sun shade....................................................... 2-29
Sun visors ....................................................... 3-12
Sunroof, Automatic sunroof ............................ 2-29
Supplemental air bag system ......................... 1-14Supplemental air bag warning labels ............. 1-18
Supplemental air bag warning light ......... 1-19, 2-8
Supplemental restraint system ......................... 1-8
Precautions on supplemental restraint
system ......................................................... 1-8
Supplemental side air bag system ................. 1-16
Switch
Fog light switch ......................................... 2-19
Hazard warning flasher switch .................. 2-20
Headlight switch ........................................ 2-17
Ignition switch .............................................. 5-4
Ignition switch automatic transmission
models ......................................................... 5-4
Ignition switch manual transmission
models ......................................................... 5-5
Overdrive switch ........................................ 5-10
Power door lock switch ............................... 3-3
Rear window and outside mirror defogger
switch......................................................... 2-16
Traction control system cancel switch ...... 2-22
Turn signal switch ..................................... 2-19
T
Tachometer ....................................................... 2-4
Temperature gauge, Engine coolant temperature
gauge ................................................................ 2-5
Theft (Nissan Vehicle Immobilizer System),
Engine start..................................................... 2-13
Theft warning .................................................. 2-12
Three way catalyst ............................................ 5-3
Tilting steering wheel ...................................... 3-12
Z
00.1.17/A33-D/V5.0
X
11-5
