Do not attempt to push start your vehicle. Automatic
transmissions do not have push-start capability.
Preparing your vehicle
1.Use only a 12±volt supply to start your vehicle.
2. Do not disconnect the battery of the disabled vehicle as this could
damage the vehicle's electrical system.
3. Park the booster vehicle close to the hood of the disabled vehicle
making sure the two vehiclesdo nottouch. Set the parking brake on
both vehicles and stay clear of the engine cooling fan and other moving
parts.
4. Check all battery terminals and remove any excessive corrosion before
you attach the battery cables. Ensure that vent caps are tight and level.
5. Turn the heater fan on in both vehicles to protect any electrical
surges. Turn all other accessories off.
Connecting the jumper cables
1. Connect the positive (+) booster cable to the positive (+) terminal of
the discharged battery.
Note:In the illustrations,lightning boltsare used to designate the
assisting (boosting) battery.
+–+–
Roadside emergencies
145
SERVICE RECOMMENDATIONS
To help you service your vehicle:
²We highlight do-it-yourself items in the engine compartment for easy
location.
²We provide a Scheduled Maintenance Guide which makes tracking
routine service easy.
If your vehicle requires professional service, your dealership can provide
necessary parts and service. Check your ªWarranty Guideº to find out
which parts and services are covered.
Use only recommended fuels, lubricants, fluids and service parts
conforming to specifications. Motorcraft parts are designed and built to
provide the best performance in your vehicle.
PRECAUTIONS WHEN SERVICING YOUR VEHICLE
Be especially careful when inspecting or servicing your vehicle.
²Do not work on a hot engine.
²When the engine is running, keep loose clothing, jewelry or long hair
away from moving parts.
²Do not work on a vehicle with the engine running in an enclosed
space, unless you are sure you have enough ventilation.
²Keep all lit cigarettes, open flames and other lit material away from
the battery and all fuel related parts.
If you disconnect the battery, the engine must ªrelearnº its idle
conditions before your vehicle will drive properly, as explained in the
Batterysection in this chapter.
Maintenance and care
150
WINDSHIELD WASHER FLUID
Checking and adding washer fluid
Check the washer fluid whenever
you stop for fuel. The reservoir is
highlighted with a
symbol.
If the level is low, add enough fluid
to fill the reservoir. In very cold
weather, do not fill the reservoir all
the way.
Only use a washer fluid that meets Ford specifications. Refer to
Lubricant specificationsin theCapacities and specificationschapter.
State or local regulations on volatile organic compounds may restrict the
use of methanol, a common windshield washer antifreeze additive.
Washer fluids containing non-methanol antifreeze agents should be used
only if they provide cold weather protection without damaging the
vehicle's paint finish, wiper blades or washer system.
Do not put washer fluid in the engine coolant reservoir. Washer
fluid placed in the cooling system may harm engine and cooling
system components.
ENGINE COOLANT
Checking engine coolant
Your engine's cooling system has been factory-filled with a 50/50 mixture
of distilled water and Ford Premium Engine Coolant E2FZ-19549-AA (in
Canada, Motorcraft CXC-10), or an equivalent premium engine coolant
that meets Ford specification ESE-M97B44-A.
A50/50 mixtureof distilled water and Ford Premium Engine Coolant
provides:
²maximum cooling system efficiency.
²freeze protection down to -36É C (-34É F).
²boiling protection up to 129É C (265É F).
Maintenance and care
157
How fail-safe cooling works
²Standard cluster
²Optional cluster
If the engine begins to overheat:
²the engine coolant temperature gauge will move to the H (hot) area
(if your vehicle is equipped with analog gauges).
²the engine coolant temperature gauge will illuminate all eight bars and
a tone will sound every five seconds for one minute (if your vehicle is
equipped with digital gauges).
²the
symbol will illuminate.
²theCheck Engineindicator light will illuminate.
If the engine reaches a preset over-temperature condition, the engine
will automatically switch to alternating cylinder operation. Each disabled
cylinder acts as an air pump and cools the engine.
When this occurs the vehicle will still operate. However:
²the engine power will be limited.
²the air conditioning system will be disabled.
TEMPH
C
N
O
R
M
H
C
Maintenance and care
162
The scheduled maintenance items listed in the Scheduled Maintenance
Guide are essential to the life and performance of your vehicle and to its
emissions system.
If other than Ford, Motorcraft or Ford-authorized parts are used for
maintenance replacements or for service of components affecting
emission control, such non-Ford parts should be equivalent to genuine
Ford Motor Company parts in performance and durability.
Do not park, idle, or drive your vehicle in dry grass or other dry
ground cover. The emission system heats up the engine
compartment and exhaust system, which can start a fire.
Illumination of the ªCheck Engineº light, charging system warning light
or the temperature warning light, fluid leaks, strange odors, smoke or
loss of engine power, could indicate that the emission control system is
not working properly.
Exhaust leaks may result in entry of harmful and potentially
lethal fumes into the passenger compartment.
Do not make any unauthorized changes to your vehicle or engine. By
law, vehicle owners and anyone who manufactures, repairs, services,
sells, leases, trades vehicles, or supervises a fleet of vehicles are not
permitted to intentionally remove an emission control device or prevent
it from working. Information about your vehicle's emission system is on
the Vehicle Emission Control Information Decal located on or near the
engine. This decal identifies engine displacement and gives some tune up
specifications.
Please consult your ªWarranty Guideº for complete emission warranty
information.
Readiness for Inspection/Maintenance (I/M) testing
In some localities, it may be a legal requirement to pass an I/M test of
the on-board diagnostics system. If your ªCheck Engine/Service Engine
Soonº light is on, refer to the description in theWarning Lights and
Chimessection of theInstrumentationchapter. Your vehicle may not
pass the I/M test with the ªCheck Engine/Service Engine Soonº light on.
Maintenance and care
184
Air bag supplemental
restraint system ........................101
and child safety seats ............103
description ..............................101
disposal ....................................105
driver air bag ..........................103
indicator light ....................10,105
operation .................................103
passenger air bag ...................103
Air cleaner filter ................169,197
Air conditioning ..........................26
automatic temperature
control system ..........................28
Air suspension ...........................122
description ..............................122
warning light .............................12
Antifreeze
(see Engine coolant) ................157
Anti-lock brake system
(see Brakes) .......................118,119
Audio system (see Radio) .........35
Automatic transmission
driving an automatic
overdrive .................................124
fluid, adding ............................164
fluid, checking ........................164
fluid, refill capacities ..............197
fluid, specification ..................200
Axle
lubricant specifications ...198,200
refill capacities ........................197
traction lok ..............................126
Battery .......................................167
acid, treating emergencies .....167
charging system
warning light .............................12
jumping a disabled battery ....144
maintenance-free ....................167
replacement, specifications ...197
servicing ..................................167
voltage gauge ............................19
Belt minder .................................97Brakes ........................................118
anti-lock ............................118,119
anti-lock brake system
(ABS) warning light ..........11,119
brake warning light ..................11
fluid, checking and adding ....156
fluid, refill capacities ..............197
fluid, specifications ..........198,200
lubricant specifications ...198,200
shift interlock ..........................123
Break-in period .............................3
Capacities for refilling fluids ....197
Cassette tape player ...................46
CD changer .................................55
Certification Label ....................202
Child safety restraints ..............106
child safety belts ....................106
Child safety seats ......................107
attaching with tether straps ..111
in front seat ............................108
in rear seat .......................108,111
Cleaning your vehicle ...............190
engine compartment ..............193
exterior ....................................192
exterior lamps .........................192
instrument panel ....................194
instrument panel lens ............194
interior ..............................195,196
mirrors .....................................192
plastic parts ............................192
safety belts ..............................195
washing ....................................191
waxing .....................................191
wheels ......................................192
windows ..................................195
wiper blades ............................193
woodtone trim ........................195
Climate control (see Air
conditioning or Heating) ............26
Clock ............................................34
Compass, electronic ....................69
calibration .................................71
Index
215
set zone adjustment .................70
Controls
power seat ............................89,90
Coolant
checking and adding ..............157
coolant temperature light ........10
refill capacities .................160,197
specifications ...................198,200
Cruise control
(see Speed control) ....................62
Customer Assistance ................133
Ford accessories
for your vehicle ......................210
Ford Extended
Service Plan ............................203
Getting assistance outside
the U.S. and Canada ..............209
Getting roadside assistance ...133
Getting the service
you need .................................203
Ordering additional
owner's literature ...................213
The Dispute
Settlement Board ...................206
Utilizing the Mediation/
Arbitration Program ...............209
Daytime running lamps
(see Lamps) ................................24
Defrost
rear window ..............................25
Dipstick
automatic
transmission fluid ...................164
engine oil .................................153
Doors
lubricant specifications ..........198
Driving under special
conditions
through water .........................132
Emergencies, roadside
jump-starting ..........................144
Emission control system ..........183Engine ........................................200
check engine/
service engine soon light ...........9
cleaning ...................................193
coolant .....................................157
fail-safe coolant ......................161
idle speed control ...................167
lubrication
specifications ...................198,200
refill capacities ........................197
service points ..........................152
starting after a collision .........134
Engine block heater .................116
Engine oil ..................................153
change oil soon warning,
message center .......................153
checking and adding ..............153
dipstick ....................................153
filter, specifications .........155,197
recommendations ...................155
refill capacities ........................197
specifications ...................198,200
Exhaust fumes ..........................116
Fail safe cooling ........................161
Floor mats ...................................74
Fluid capacities .........................197
Fuel ............................................175
calculating fuel economy .......180
cap ...........................................177
capacity ...................................197
choosing the right fuel ...........178
comparisons with EPA fuel
economy estimates .................183
detergent in fuel .....................179
filling your
vehicle with fuel .......175,177,180
filter, specifications .........180,197
fuel pump shut-off switch .....134
gauge .........................................15
improving fuel economy ........180
low fuel warning light ................8
octane rating ....................179,200
Index
216
anti-lock brakes (ABS) .....11,119
brake ..........................................11
charging system ........................12
check engine ...............................9
high beam .................................11
low coolant ................................10
low fuel ........................................8
oil pressure ...............................12
overdrive off ..............................13
safety belt .................................10
speed control ............................65
traction control active ..............13
turn signal indicator .................11
Load limits .................................127
GAWR ......................................127
GVWR ......................................127
trailer towing ..........................127
Locks
autolock .....................................76
childproof ..................................74
doors ..........................................73
Lubricant specifications ....198,200
Lug nuts, anti-theft ...................143
Lumbar support, seats ...............91
Message center ...........................20
reset button ..............................20
select button .............................21
Mirrors
automatic dimming
rearview mirror .........................69
cleaning ...................................192
side view mirrors (power) .......73
Motorcraft parts .................180,197
Octane rating ............................179
Odometer .....................................17
Oil (see Engine oil) ..................153
Overdrive ..............................61,125
Panic alarm feature,
remote entry system ..................78
Parking brake ............................119
Parts (see Motorcraft parts) ....197Power distribution box
(see Fuses) ...............................138
Power door locks ...................73,76
Power steering ..........................122
fluid, checking and adding ....164
fluid, refill capacity ................197
fluid, specifications ..........198,200
Radio ............................................35
Relays .................................135,140
Remote entry system ............75,78
illuminated entry ......................79
locking/unlocking doors ...........75
opening the trunk .....................78
panic alarm ...............................78
replacement/additional
transmitters ...............................80
replacing the batteries .............79
Safety belts (see Safety
restraints) ...........14,91,92,93,94,95
Safety defects, reporting ..........214
Safety restraints ......91,92,93,94,95
belt minder ...............................97
cleaning the
safety belts .......................100,195
extension assembly ..................96
for adults .........................92,93,94
for children ......................105,106
lap belt ......................................95
warning light
and chime ...................10,14,96,97
Safety seats for children ..........107
Seat belts
(see Safety restraints) ...............91
Seats ............................................87
child safety seats ....................107
cleaning ............................195,196
SecuriLock passive
anti-theft system ....................80,81
Servicing your vehicle ..............150
Spark plugs,
specifications ......................197,200
Index
218
