2000 Lexus LS400 engine coolant

ENGINE
406± COOLING SYSTEM
Capacity
Coolant type
10.8 L (11.4 qt., 9.5 lmp.qt.)
ºToyota Long Life Coolantº or equivalent
With ethylene±glycol type coolant for a proper
corrosion protection of aluminum components
Do not use alcohol type antifreeze or plain water
alone.
± FUELFuel type
Octane rating
Only UNLEADED
91 (Research octane number 96) or higher
± IGNITION SYSTEMSpark plug ± Make DENSO NGK
± Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
± ELECTRICAL SYSTEM
Battery Open voltage at 20 C (68F):
Charging rates
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the key is
removed with all the lights turned off]
5A max.

ENGINE
417
Oil identification marks
62L006±1

API Service Symbol
ILSAC Certification
Mark
Either or both API registered marks are added to some
oil containers to help you select the oil you should use.
 The API Service Symbol is located anywhere on the
outside of the container.
The top portion of the label shows the oil quality by
API (American Petroleum Institute) designation such
as SJ. The center portion of the label shows the SAE
viscosity grade such as SAE 5W±30.
ºEnergy±Conservingº, shown in the lower portion,
indicates that the oil has fuel±saving capabilities.
 The ILSAC (International Lubricant Standardization
and Approval Committee) Certification Mark is
displayed on the front of the container.
CHECKING THE ENGINE
COOLANT LEVEL

ENGINE
418
62L007-2

1Reservoir cap 2Upper line 3Lower line
Look at the see±through coolant reservoir when the
engine is cold. The coolant level is satisfactory if it
is between theºFULLº and ºLOWº lines on the
reservoir. If the level is low, add ethylene±glycol
type coolant for a proper corrosion protection of
aluminum components.
The coolant level in the reservoir will vary with engine
temperature. However, if the level is on or below the
ºLOWº line, add coolant. Bring the level up to the ºFULLº
line.
Always use ethylene±glycol type coolant for a proper
corrosion protection of aluminum components. See
information in the next column. If the coolant level drops within a short time after
replenishing,
there may be a leak in the system. V isually
check the radiator, hoses, engine coolant filler cap,
radiator cap and drain cock and water pump.
If you can find no leak, have your Lexus dealer test the
cap pressure and check for leaks in the cooling system.

ENGINE
420
Coolant type selection
Use of improper coolants may damage your engine
cooling system. Your coolant must contain
ethylene±glycol type coolant for a proper corrosion
protection of your engine that contains aluminum
components. Use ºToyota Long Life Coolantº or
equivalent.
In addition to preventing freezing and subsequent
damage to the engine, this type of coolant will also
prevent corrosion. Further supplemental inhibitors or
additives are neither needed nor recommended.
Read the coolant container for information on freeze
protection. Follow the manufacturer's directions for how
much to mix with plain water (preferably demineralized
water or distilled water). The total capacity of the cooling
system is given on page 406.
We recommend to use 50% solution for your Lexus, to
provide protection down to about ±35C (±31F). When
it is extremely cold, to provide protection down to about
±50 C (±58F), 60% solution is recommended. Do not
use more than 70% solution for better coolant
performance.
NOTICE
Do not use alcohol type antifreeze or plain water alone.
