2000 Lexus ES300 buttons

INTERIOR EQUIPMENT
89
The
HomeLink
 has 3 buttons and can be
programmed to operate 3 separate devices.
Prepare the HomeLink
 for programming by
erasing all codes or the memorized data
programmed by the former owner. Follow the
procedure in ª(c) Erasing the garage door opener
memoryº.
1. Decide which one of the 3 buttons you want to
program. Push and hold down the button for about 20
seconds until the indicator light begins to flash. While
holding this button, follow steps ª2º and ª3º. 2. Bring the hand held garage door opener within about
25 mm (1 in.) of the button being programmed and push
the button on the hand held garage door opener. The
signal from the hand held garage door opener is sent to
the vehicle's opener.
3. When the frequency and code is registered, the
indicator light flashes rapidly. At this point, you can
release both buttons.
4. To program the remaining buttons, repeat steps ª1º
through ª3º.
If you want to replace an existing program with a new
program, select the button you want to
program. Follow
the procedure from step 1.
If the transmitter has a ªrolling code featureº, it is
necessary to program the in±garage receiver after
programming HomeLink
.
1. Locate the ªtrainingº or ªlearningº button on the
in±garage receiver and push and release this
button. Location of the button may vary by the
garage door opener manufacturer.
2. Firmly push and release the trained HomeLink

button 2 times (some garage door manufacturer
may require you to push the HomeLink button up
to 3 times) to complete the process.
The garage door should now operate when the
HomeLink
 button is pushed.

INTERIOR EQUIPMENT
90Do not use the HomeLink
 universal transmitter with
any garage door opener that lacks the safety stop and
reverse feature as required by Federal Safety
Standards. This includes any garage door opener
model manufactured before April 1, 1982.
CAUTION
When programming or operating the garage door
opener, make sure there is no one around the moving
door. It is dangerous if someone is caught.
(b) Operating the garage door opener
Push the appropriate button to activate the garage door
opener. The indicator light comes on. The garage door
opener continues to send the signal for up to 20 seconds
as long as the button is pushed.
(c) Erasing the garage door opener memory
Push and hold down the 2 outside buttons for about 20
seconds until the indicator light flashes. All memorized
data will be erased. FCC ID: CB2V94800
CANADA: 1763 102 264
This device complies with FCC Rules part 15.
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference that may be received,
including interference that may cause undesired
operation. WARNING: This transmitter has
been tested and complies with FCC and
DOC/MDC rules. Changes or modifications
not expressly approved by the party
responsible for compliance could void the
user's authority to operate the device.

COMFORT ADJUSTMENT
141
To connect the extender to the seat belt, insert the
tab into the seat belt buckle so that the ªPRESSº
signs on the buckle release buttons of the extender
and the seat belt are both facing outward as shown.
You will hear a click when the tab locks into the buckle.
When releasing the seat belt, press on the buckle
release button on the ext
ender, not on the seat belt. This
helps prevent damage to the vehicle interior and
extender itself.
When not in use, remove the extender and store in the
vehicle for future use.

AIR CONDITIONING
217
(a) Climate control
SETTING OPERATION ± automatic control
20E094
1. Push the ªAUTOº button.
An indicator light will illuminate to show that the
automatic operation mode has been selected.
Air flow quantity, switching of the diffusers, on±off of the
air conditioning and switching of the air intake between
RECIRCULATED AIR and OUTSIDE AIR are
automatically adjusted. The operation status is shown
by each indicator.
When one of the manual control buttons is depressed
while operating in automatic mode, the operation
corresponding to the button depressed is set. Other
conditions continue to be adjusted automatically.
Push the ªOFFº button to turn the air conditioning system
off.

AUDIO
237
1Turning the system on and adjusting volume
(See page 238 for details.)
2Stopping and ejecting a cassette tape
(See page 247 for details.)
3Function buttons
1 ± 6: Station selector buttons
(See page 244 for details.)
SCAN: Scan tuning
(See page 247 for details.)
P. SCAN: Preset scan tuning (See page 247 for details.)
4Display of functions in TAPE mode

:
Side change
(See page 249 for details.)
: DOLBY NR
(See page 249 for details.)
 :Rewinding
(See page 250 for details.)


:Fast forwarding
(See page 250 for details.)
RPT: Automatic repeat
(See page 251 for details.)
SKIP: Automatic skip of blank portions of tape
(See page 251 for details.)
SCAN: Scan selection
(See page 252 for details.)
4
Display of functions in CD mode
:Disc selection
(See page 258 for details.)
 :Reversing
(See page 262 for details.)


:Fast forwarding
(See page 262 for details.)
RPT: Automatic repeat
(See page 263 for details.)
RAND: Random access
(See page 263 for details.)
SCAN: Scan selection
(See page 260 for details.)
5
Mode selectors
(See page 239 for details.)
6Cassette tape slot
(See page 247 for details.)
7Tone and balance knobs
(See page 240 for details.)
8Radio mode: Frequency tuning
( S e e p a g e 243 o r 245 f o r
details.)
TAPE mode: Direct access to a desired
program (See page 253 for details.)
CD mode: Direct access to a desired

AUDIO
239
Push
ªAMº, ªFM1/2º, ªTAPEº or ªCDº to turn on that
mode. The selected mode turns on directly.
Push these buttons if you want to switch from one mode
to another.
If the tape or disc is not set, the cassette player or
compact disc player does not turn on.
You can turn off the cassette player by ejecting the
cassette tape. If the audio system was previously off,
then the entire audio system will be turned off when you
eject the cassette tape. If another function was
previously playing, it will come on again.
20E014a

AUDIO
243
Radio operation
(a) Listening to the radio
20E104
Push these buttons to choose either an AM or FM
station.
ªAMº, ªFM1º or ªFM2º appears on the display.

AUDIO
245
20E206
1. Tune in the desired station.
2. Push one of the station selector buttons ( 1±6 )
and hold it until a beep is heard. This sets the station
to the button and the button number ( 1±6 ) appears
on the display.
Each button can store one AM station and two FM
stations. To change the preset station to a different one,
follow the same procedure.
The preset station memory is cancelled when the power
source is interrupted by battery disconnection or a blown
fuse. (c) Selecting a station
Your Lexus has an electronic tuning radio (ETR). Tune
in the desired station using one of the following methods.
