Page 113 of 429

2-9
Remote Lock Confirmation (If Equipped)
If your vehicle is equipped with the content
theft
-deterrent system, your remote keyless entry
transmitter will have this feature.
When you use the remote keyless entry transmitter to
lock your vehicle, the parking lamps will flash briefly to
let you know the command has been received. If you
press the LOCK button again, within five seconds, the
horn will sound briefly and the parking lamps will flash
to let you know the vehicle is already locked.
If you would like to change the way the parking lamps
and horn operate with remote lock confirmation, see
ªMultifunction Alarm Locks and Lighting Choicesº
in the Index.Remote Unlock Confirmation (If Equipped)
If your vehicle is equipped with the content
theft-deterrent system, your remote keyless entry
transmitter will have this feature.
When you use your remote keyless entry transmitter to
unlock your vehicle or to operate the power sliding door
(if equipped), the parking lamps will flash briefly to let
you know the command was received.
If you would like to change the way the parking lamps
operate with remote unlock confirmation, see
ªMultifunction Alarm Locks and Lighting Choicesº
in the Index.
Remote Alarm (If Equipped)
When you press the horn button on the remote keyless
entry transmitter, the parking lamps will flash and the
horn will sound. This will allow you to attract attention,
if needed.
Page 114 of 429

2-10
Remote Power Sliding Door Operation (If Equipped)
If your vehicle is equipped
with a power sliding door
(see ªPower Sliding Doorº
later in this section),
your remote transmitter
will have a button that has
a van symbol on it.
Press it to open or close
the sliding door.
If the sliding door is locked, first unlock all doors
(see ªRemote Driver's Door and All Door Unlockº
earlier in this section), then press the van symbol to
open the sliding door. Press the van symbol again to
close the sliding door.
You can operate the power sliding door with the remote
transmitter only when the power sliding door override
switch on the overhead console is turned off.
Matching Transmitter(s) To Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have only four transmitters
matched to it.
See your dealer to match transmitters to another vehicle.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about two years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
Page 115 of 429
2-11
Replacing the Battery in the Remote Transmitter
NOTICE:
When replacing the battery, use care not to touch
any of the circuitry. Static from your body
transferred to these surfaces may damage
the transmitter.
1. Insert a flat object like a dime into the slot on the
side of the transmitter and twist to separate
the halves.
2. Gently pry the battery out of the transmitter. Do not
use the metal flanges to ªpop outº the battery.
3. Replace the battery.
4. Reassemble the transmitter. Make sure the halves are
snapped together tightly so water will not get in.
5. Check the transmitter operation. If needed, follow
the instructions on resynchronizing your
remote transmitter.
Page 116 of 429

2-12 Resynchronization
Your remote keyless entry system uses a continually
changing code for increased security. Normally, the
receiver in your vehicle will keep track of this
changing code.
Loss of synchronization will occur if the transmitter
is activated more than 256 times while out of range
of the vehicle.
Loss of synchronization will occur after the battery
replacement if the transmitter is immediately activated
more than 16 times while out of range of the vehicle.
If your remote keyless entry transmitter has stopped
working, you may need to resynchronize the transmitter
to the vehicle receiver. To do this, press the LOCK and
UNLOCK buttons together and hold for at least seven
seconds or until the horn sounds if equipped with the
content theft
-deterrent system. Check the
transmitter operation.
Switchbanks
There are two sets of switchbanks located in the front of
the vehicle. The switches will vary with the options that
are on your vehicle. It is useful to become familiar with
them since they are used frequently while operating
the vehicle.
Overhead Console Switchbank
This switchbank is located in the overhead console.
The switches that you may find in this switchbank are
the interior lights override, power sliding door override,
power sliding door and the power rear quarter windows.
If your vehicle does not have some of the options
controlled by these switches, there will be a blank button
in its place.
For more information, please see each of these features
in the Index.
Page 117 of 429
2-13
Instrument Panel Switchbank
This switchbank is located in the instrument panel below
the comfort controls. The switches and controls that you
may find in this switchbank are the rear fan knob, rear
window wiper/washer and traction control. If your
vehicle does not have some of the options controlled by
these switches, there will be a blank button in its place.For more information, please see each of these features
in the Index.
If your vehicle is not equipped with the optional rear
climate control system, there will be a storage space in
this switchbank. The rubber mat can be removed for
cleaning. Snap the mat into place after cleaning.
Page 118 of 429
2-14
Multifunction Alarm Locks and Lighting Choices
Your vehicle's locks and lighting systems can be programmed with several different features. The features you can
program depend on the options that came with your vehicle. The following chart shows the features that can be
programmed. To determine which features your vehicle is equipped with, follow the steps listed for entering the
programming mode.
Page 119 of 429

2-15
Entering Programming Mode
To program features, your vehicle must be in the
programming mode. Follow these steps:
1. The content theft
-deterrent system (if equipped)
must be disarmed. See ªContent Theft
-Deterrent
Systemº in this section.
2. Remove the BCM PRGRM fuse from the instrument
panel fuse block, located to the right of the glove
box. (See ªFuses and Circuit Breakersº in the Index.)
3. Close the driver's door.
4. Turn the ignition key towards you to ACCESSORY.
5. Count the number of chimes you hear. You will hear
two to four chimes depending on the features your
vehicle is equipped with. Refer to the chart
shown previously.
You can now program your choices.
To exit the programming mode, follow the steps listed
under ªExiting Programming Modeº later in
this section.
Delayed Illumination and Exit Lighting
With delayed illumination, the interior lamps will stay
on for about 25 seconds after all the doors and the
liftgate are closed.
With exit lighting, the interior lamps will come on and
stay on for about 25 seconds whenever you remove the
key from the ignition.
To customize these features to your preference,
see ªProgrammable Modesº following.
Programmable Modes
Your vehicle can be programmed to one of the
following modes.
Mode 1: Both Features Off (The interior lamps will turn
on or off at the same instant that a door is opened
or closed.)
Mode 2: Delayed Illumination Only (The interior lamps
will stay on for about 25 seconds after all the doors and
liftgate are closed, or until you lock the doors.)
Mode 3: Exit Lighting Only (The interior lamps will
come on whenever you remove the key from the ignition
and stay on for about 25 seconds, or until you lock
the doors.)
Page 120 of 429

2-16
Mode 4: Both Features On (This combines Modes 2
and 3.)
Vehicles are delivered programmed in Mode 4.
To change the mode:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Turn the interior lamps control all the way clockwise
and then back slightly counterclockwise.
3. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is in.
You can change the mode by turning the interior
lamps control all the way clockwise and then back
slightly counterclockwise.
4. Repeat Step 2 until you hear the number of chimes
that matches the mode you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.Automatic Door Locks
With automatic door locks, all doors will automatically
lock when you shift out of PARK (P) and automatically
unlock when the ignition is turned to OFF.
To customize these features to your preference,
see ªProgrammable Modesº following.
Programmable Modes
Your vehicle can be programmed to one of the
following modes.
Mode 1: Both Features Off (Automatic door locking
and unlocking is disabled. You will always need to lock
your doors manually before driving to increase
occupant safety.)
Mode 2: Automatic Door Locking Only
The automatic door unlock feature is turned off.
Shift out of PARK (P) with the ignition on and the
driver's door closed; all doors will lock automatically.
Mode 3: Automatic Unlocking with the Ignition Off
Turn off the ignition with the transaxle in PARK (P);
all doors will unlock automatically.
Shift out of PARK (P) with the ignition on and the
driver's door closed; all doors will lock automatically.
