2000 CHEVROLET MONTE CARLO remote start

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-6 Remote Keyless Entry (Option)
2
-10 Trunk
2
-11 Theft
2
-12 Content Theft-Deterrent (If Equipped)
2
-13 Vehicle Customization Settings
2
-20 Passlock

2-20 New Vehicle ªBreak-Inº
2
-21 Ignition Positions
2
-22 Starting Your Engine
2
-25 Engine Coolant Heater (If Equipped)
2
-26 Automatic Transaxle Operation
2
-30 Parking Brake
2
-31 Shifting Into PARK (P)
2
-33 Shifting Out of PARK (P)
2
-34 Parking Over Things That Burn
2
-34 Engine Exhaust
2
-35 Running Your Engine While You're Parked2
-36 Windows
2
-37 Tilt Wheel Adjustable Steering Column
2
-37 Turn Signal/Multifunction Lever
2
-43 Exterior Lamps
2
-45 Interior Lamps
2
-48 Mirrors
2
-51 Accessory Power Outlet
2
-52 Auxiliary Power Connection (Power Drop)
2
-52 Cellular Phone Readiness Package
(If Equipped)
2
-53 OnStar
System (If Equipped)
2
-53 Power Sunroof (Option)
2
-54 HomeLink
Transmitter (If Equipped)
2
-58 The Instrument Panel -- Your
Information System
2
-60 Instrument Panel Cluster
2
-63 Warning Lights, Gages and Indicators
2
-75 Message Center
2
-80 Driver Information Center (DIC) (Option)

2-19
ORIG. SET (Return to the Original Settings): This
feature allows you to return all feature customization
settings back to their original factory settings. To reset:
1. Scroll, using the SEEK up or down arrows, until
ORIG. SET appears on the display.
2. Press the PREV or NEXT button to enter the
submenu. SET ALL will appear.
3. With your preference displayed, press the DISP
button to select. A chime will be heard to verify the
new setting. The new selection will be displayed
with an asterisk for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
FOB PROG (Remote Keyless Entry Transmitter
Programming): This feature allows you to match the
remote keyless entry transmitter to your vehicle.
To match the transmitter:
1. Scroll, using the SEEK up or down arrows, until
FOB PROG appears on the display.2. Press the PREV or NEXT button to enter the
submenu. The current selection will have an asterisk
next to it. BEGIN will be displayed.
3. Press the DISP button to start programming. When
the message PUSH FOB flashes, press and hold the
LOCK and UNLOCK buttons on the first transmitter
at the same time for 15 seconds. A chime will be
heard to verify the transmitter is learned.
4. Repeat Step 3 for each additional transmitter.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
EXIT (Exit Feature Customization Mode): This feature
allows you to exit the vehicle customization
programming. To exit:

Scroll until EXIT appears on the display.

Press the DISP button to exit programming. A chime
will be heard to verify the exit.

5-4
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles aren't touching
each other. If they are, it could cause a ground
connection you don't want. You wouldn't be able to
start your car, and the bad grounding could damage
the electrical systems.
Put an automatic transaxle in PARK (P) or a manual
transaxle in NEUTRAL (N).
3. Turn off the ignition on both vehicles. Turn off all
lamps that aren't needed, and radios. This will avoid
sparks and help save both batteries. And it could
save your radio!
NOTICE:
If you leave your radio on, it could be badly
damaged. The repairs wouldn't be covered by
your warranty.
CAUTION:
An electric fan can start up even when the engine
is not running and can injure you. Keep hands,
clothing and tools away from any underhood
electric fan.
4. Find the positive (+) and negative (-) terminals on
each battery. Your car has a remote positive (+) jump
starting terminal. The terminal is on the same side of
the engine compartment as your battery. You should
always use the remote positive (+) terminal instead
of the positive (+) terminal on your battery.

5-7
7. Don't let the other end
touch metal. Connect
it to the positive (+)
terminal of the good
battery. Use a remote
positive (+) terminal
if the vehicle has one.
Now connect the black
negative (
-) cable to
the good battery's
negative (
-) terminal.
Don't let the other end
touch anything until
the next step.
The other end of the negative (
-) cable doesn't go
to the dead battery.
It goes to a heavy, unpainted metal part on the engine
of the vehicle with the dead battery.
8. Attach the cable at least 18 inches (45 cm) away
from the dead battery, but not near engine parts that
move. The electrical connection is just as good there,
but the chance of sparks getting back to the battery is
much less.
9. Now start the vehicle with the good battery and run
the engine for a while.
