2000 CADILLAC ELDORADO Owners Manual

2-38 Lamps On Reminder
If the manual headlamp control is activated, you will
hear a warning chime if you open either door while
leaving the lamps on. An exception to this is when
you're using Twilight Sentinel.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
The DRL system will make the high
-beam headlamps
come on at reduced brightness when:

The ignition is on,

the headlamp switch is off and

the transaxle is not in PARK (P).
When DRL are on, only your high
-beam headlamps
(at reduced brightness) will be on. No other exterior
lamps such as the parking lamps, taillamps, etc. will be
on when the DRL are being used. Your instrument
panel won't be lit up either.When the Twilight Sentinel switch is on and it's dark
enough outside, the high
-beam headlamps (at reduced
intensity) will turn off and normal low
-beam headlamp
operation will occur. When the Twilight Sentinel switch
is on and it's bright enough outside, the regular lamps
will go off, and the high
-beam headlamps at reduced
brightness will take over for the DRL.
If it's dark enough outside and the Twilight Sentinel
control is off, a HEADLAMPS SUGGESTED message
will display on the Driver Information Center (DIC).
This message informs the driver that turning on the
exterior lamps is recommended even though the DRL
are still illuminated (it's become dark enough outside to
require the headlamps and/or other exterior lamps).
Turning on the Twilight Sentinel, the headlamp switch
or the fog lamp switch will remove the HEADLAMPS
SUGGESTED message.
To idle your vehicle with the DRL off, turn off the
Twilight Sentinel switch and shift the transaxle into
PARK (P). Placing your vehicle in PARK (P) disables
the DRL. The DRL will stay off until you shift out
of PARK (P).
As with any vehicle, you should turn on the regular
headlamp system when you need it.

2-39 Fog Lamps
Use the fog lamps for better
vision in foggy or misty
conditions. When you press
the fog lamp button, a small
indicator light will tell you
that the fog lamps and the
parking lamps are on. Press
the button again to turn
them off.
If you turn on the high
-beam headlamps, the fog lamps
will turn off. They'll turn back on again when you
switch to low
-beam headlamps.
When the Twilight Sentinel is on and the fog lamp
switch is activated, the fog lamps will remain on as well
as the headlamps and parking lamps.
Cornering Lamps
The cornering lamps come on when the headlamps or
parking lamps are on and you signal a turn. They
provide more light for cornering.
Twilight Sentinel

This control is located next
to the exterior lamp control
knob. It automatically
turns the lamps on and
off by sensing how dark
it is outside.
To operate the Twilight Sentinel, leave the exterior lamp
control knob off and move the TWILIGHT control to
any position but OFF.
If you move the control all the way to the right, the
lamps will remain on for approximately three minutes
after the ignition has been turned to OFF or LOCK.
If you move the control so it is just on, the lamps will
go off quickly when you turn the ignition out of RUN.
You can adjust the delay time from only a few seconds
to three minutes.

2-40
If it's dark enough outside and the Twilight Sentinel
control is off, a HEADLAMPS SUGGESTED message
will display on the Driver Information Center (DIC).
This message informs the driver that turning on the
exterior lamps is recommended (it's become dark
enough outside to require the headlamps and/or other
exterior lamps). Turning on the Twilight Sentinel,
the headlamps or the fog lamps will remove the
HEADLAMPS SUGGESTED message.
Light SensorThe light sensor for the Daytime Running Lamps (DRL)
and the Twilight Sentinel is located in the center of the
front defogger grille. If you cover the sensor, it will read
ªdarkº and the lamps will come on.
Exterior Lighting Battery Saver
If the manual parking lamp control has been left on, the
exterior lamps will turn off approximately 10 minutes
after the ignition is turned to LOCK or ACCESSORY.
This protects draining the battery in case you have
accidentally left the headlamps or parking lamps on.
If you need to purposely leave the lamps on for more
than 10 minutes with the ignition in LOCK or
ACCESSORY, turn the exterior lamps control knob
off and then back on. To delay the lamps from turning
off, see ªTwilight Sentinelº in the Index.

2-41
Interior Lamps
Instrument Panel Intensity/
Brightness Control
The digital displays automatically dim when it becomes
dark outside and your lights are on. When it's dark, the
brightness control can be manually adjusted by turning
the exterior lamps control knob counterclockwise to dim
and clockwise to brighten the lighting. The digital
displays automatically brighten when it becomes light
outside, although backlighting will remain active at the
selected brightness as long as the lights are on.
Illuminated Entry
The illuminated entry system turns on the courtesy
lamps and the backlighting to the door controls and to
the exterior lamps control knob when a door is opened
or if you press a remote keyless entry transmitter button.
Since the illuminated entry system has a photocell, this
means that it must be dark outside in order for the
courtesy lamps or backlighting to turn on. The courtesy
lamps turn off approximately 20 seconds after the last
door is closed or after the ignition is turned to RUN.
Parade Dimming
This feature prohibits the dimming of the instrument
panel lights during daylight while the headlamps are on.
This feature operates with the light sensor for the
Twilight Sentinel and is fully automatic. When the light
sensor reads darkness outside, the instrument panel
lights can be adjusted by turning the exterior lamps
control knob counterclockwise to dim and clockwise to
brighten lighting. Backlighting to the instrument panel
will turn on, regardless of light conditions.
Reading Lamps
The reading lamps are either located in the headliner or
above the windows if you have a sunroof. To turn them
on, turn the exterior lamps control knob all the way
clockwise. These lamps and the interior courtesy lamps
automatically come on when either door is opened and it
is dark outside. For manual operation, press the button
to turn them on. Press it again to turn them off.
If the reading lamps are left on, they automatically shut
off 10 minutes after the ignition has been turned off.

2-42 Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's battery
against drainage from the interior lamps, trunk lamp,
glove box lamp, cigarette lighters or the garage door
opener. When the ignition is turned off, the power
to these features will automatically turn off after
10 minutes (three minutes if a new car has 15 miles
(24 km) or less). Power will be restored for an additional
10 minutes if either door is opened, the trunk is opened
or the courtesy lamps are turned on.
Storage Mode Personalization
This feature is for long-term use and must be
programmed through the Driver Information Center
(DIC) while the ignition is in RUN. Storage mode
personalization protects the battery by placing your
vehicle in a storage mode so that the radio, amplifiers,
instrument panel cluster and remote keyless entry
will not drain the battery over a long period of time.
For programming information, see ªMemory and
Personalization Featuresº in the Index.
Mirrors
Electrochromic Day/Night Rearview Mirror
with Compass
Your vehicle has an electrochromic inside rearview
mirror with a compass.
When set in the MIRROR position, this mirror
automatically changes to reduce glare from headlamps
behind you.

2-43
The mirror also includes an eight-point compass display
in the upper right corner of the mirror face. When on,
the compass automatically calibrates as the vehicle
is driven.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause the
liquid cleaner to enter the mirror housing.
Mirror Operation
The right button located at the bottom of the mirror
turns the electrochromic mirror on and off. To turn on
the automatic dimming feature, press MIRROR.
To turn off automatic dimming, press MIRROR again.
The green indicator light will be illuminated when this
feature is active.Compass Operation
Press the COMPASS button once to turn the compass
on or off.
When the ignition and the compass feature are on,
the compass will show two character boxes for
approximately two seconds. After two seconds,
the mirror will display the compass heading.
If, after two seconds, the display does not show a
compass heading (ªNº for North, for example),
there may be a strong magnetic field interfering with
the compass. Such interference may be caused by a
magnetic antenna mount, magnetic note pad holder or
a similar magnetic item.
Compass Calibration
If the letter ªCº appears in the compass display,
the mirror may need calibration.
The mirror can be calibrated in one of two ways:

Drive the vehicle in circles at 5 mph (8 km/h) or less
until the display reads a direction, or

Drive the vehicle on your everyday routine.

2-44
Compass Variance
The mirror is set in zone eight upon leaving the factory.
It will be necessary to adjust the compass to compensate
for compass variance if you live outside zone eight.
Under certain circumstances, as during a long distance
cross
-country trip, it will be necessary to adjust for
compass variance. Compass variance is the difference
between earth's magnetic north and true geographic
north. If not adjusted to account for compass variance,
your compass could give false readings.
To adjust for compass variance:
1. Use the COMPASS side of the button located at the
bottom of the mirror. Press and hold COMPASS
until a zone number appears in the display.
2. Find your current location and variance zone number
on the following zone map.
3. Press COMPASS on the bottom of the mirror until
the new zone number appears in the display. After
you stop pressing the button, the display will show a
ªCº in the direction display within a few seconds.
(This is the automatic calibration mode
-- you'll
need to drive in a circle to calibrate the mirror. See
ªCompass Calibrationº listed previously.)

2-45 Power Remote Control Mirror (Heated)
Your vehicle has an electric
mirror control located on
the driver's door armrest.
Move the R/L switch in the middle of the control to
choose the right (passenger's side) or left (driver's side)
mirror. To adjust the mirror, push the arrow control in
the direction you want the mirror to go. Adjust each
mirror so you can see the side of your vehicle and the
area behind your vehicle.
The mirrors can also be programmed for personalization if
you have the optional memory package. For more
information, see ªMemory Seat and Mirrorsº in the Index.
To activate the heated mirrors, press the rear window
defogger button. See ªRear Window Defoggerº in
the Index.
Driver's Outside Auto-Dimming
Rearview Mirror
Only the driver's side outside mirror will adjust for
the glare of headlamps behind you. This feature is
controlled by the on and off settings on the
electrochromic mirror. See ªElectrochromic Day/Night
Rearview Mirror with Compassº in the Index.
Curb View Assist Mirror (If Equipped)
If your vehicle is equipped with memory mirrors, it will
also be equipped with the curb view assist mirror
feature. This feature will cause the passenger's mirror to
tilt when the vehicle is moving in REVERSE (R). This
feature may be useful in allowing you to view the curb
when you are parallel parking (selected/programmed
through personalization on the DIC).
When the vehicle is shifted out of REVERSE (R) and a
five second delay has occurred, the passenger's mirror
will return to its original position. If further adjustment
is needed after the mirror is tilted, the mirror switch may
be used. The mirror then returns to its original position.
