2000 BMW Z8 Owners Manual

128n
The onboard tool kit is located under
the luggage compartment's floor panel.
520de059
1 To move the wipers to the fold-out
position:
Turn the ignition on. Set the wiper
lever in position 1 (intermittent set-
ting). Turn the ignition back off during
the wiper-delay pause. The wipers
will then be in a rather vertical position
2 Rotate the wiper arm completely out
from the windshield
3 Position the wiper blade at an angle
and pull the release spring (arrow)
4 Fold the wiper blade down and
unhook it toward the windshield
5 Pull the wiper blade past the wiper
arm toward the top
6 Insert a new wiper blade and press it
in until you hear it click into place. 520de060
Fold the wipers back onto the
windshield before turning the igni-
tion key to position 1 or 2. If you do not,
the wipers could be damaged.<
Use only wiper blades approved
by BMW.<
Onboard tool kit Windshield wiper blades

129n
IndexDataTechnologyRepairsCar careControlsOverview
Lamps and bulbs The lamps and bulbs make essential
contributions to the safety of your vehi-
cle. Therefore, comply fully with the fol-
lowing instructions during bulb replace-
ment. If you are not familiar with any of
the procedures, consult your BMW
center.
Do not touch the glass portion of
a new bulb with your bare hands
since even small amounts of impurities
burn into the surface and reduce the
service life of the bulb. Use a clean
cloth, paper napkin, or a similar material,
or hold the bulb by its metallic base.<
A replacement bulb set is available from
your BMW center.
Whenever working on the electri-
cal system, switch off the electri-
cal accessory you are working on or
disconnect the cable from the negative
terminal of the battery. Failure to do this
could result in short circuits.
To prevent injuries and damage, com-
ply with any instructions provided by
the bulb manufacturer.<
When cleaning the headlamps,
please observe the following:
>Do not clean by wiping with a dry
cloth. Never use abrasives or strong
solvents to clean the covers
>Remove dirt and contamination (such
as insects) by soaking with BMW Car
Shampoo and then rinsing with plenty
of water
>Always use a deicer spray to remove
accumulated ice and snow Ð never
use a scraper.<
Xenon lamps

The main headlamps for your BMW
Z8 roadster have been designed using
xenon-light technology. The service life
of these bulbs is very long and the
probability of a failure is very low, pro-
vided that they are not switched on and
off an unusual number of times.
Should a lamp ever fail, however,
please contact your BMW center for
assistance.
Because of the extremely high
voltages involved, any work on the
lighting system should be performed
only by authorized technicians. Failure
to comply with this creates a risk of
fatal injury.<
Neon lampsThe front turn signal indicators (side
marker lamps), the rear turn signal indi-
cators, the rear and brake lamps, as
well as the high-mount brake lamp, are
of neon-light technology. The service
life for these lamps is very high and the
likelihood of failure very minimal.
Should a lamp ever fail, however,
please contact your BMW center for
assistance.

130n
Lamps and bulbsSide turn signal indicators5 watt bulb
Please contact a BMW center in the
event of a malfunction.Side lamps5 watt bulb
Please contact a BMW center in the
event of a malfunction.
Taillamps 1 Turn signal indicators red
2 Taillamp/Brake lamp red
3 High-mounted brake lamp red
4 Backup lamp red/white
5 Rear foglamp red
6 Reflector red520us010
Side marker lamps rearPlease contact a BMW center in the
event of a malfunction.520us011

131n
IndexDataTechnologyRepairsCar careControlsOverview
Lamps and bulbsReplace the rear foglamp 21 watt bulb
1 Unlock the ventilation grille by giving
it a 1/4 turn (use a screwdriver or
coin) and remove it520de068
2 Reach into the opening, turn the bulb
holder to the left and take it out
3 Replace the bulb.Replace the backup lamp 21 watt bulb
Replacing this bulb is done the same as
it is for the rear foglamp.520de069
Replace the license plate lamp5 watt bulb
1 Turn the lamp to the right and take it
out by pulling downward
2 Turn the lamp socket toward the rear
and take it out
3 Replace the bulb.520us012

132n
Lamps and bulbsReplace the door warning lamp5 watt bulb
1 Pry the lamp out by pressing on the
narrow side with a screwdriver
2 Turn the bulb holder to the left and
remove it
3 Replace the bulb.520de062
Replace the exit lamp5 watt bulb
1 Pry the lamp out by pressing on the
narrow side with a screwdriver
2 Replace the bulb.520de063
Replace the footwell lamp 5 watt bulb
1 Pry the lamp out by pressing on the
narrow side with a screwdriver
2 Replace the bulb.520de064

133n
IndexDataTechnologyRepairsCar careControlsOverview
Lamps and bulbsReplace the interior lampFront
Xenon bulb, 6 watts
Interior lamp/Reading lamp
1 Pry the lens out using a screwdriver
2 Pull the lamp socket out of the lamp
insert
3 Remove and replace the bulb.520de095
Rear
5 watt bulb
1 Use a screwdriver to remove the lens
from the side
2 Replace the bulb.520de066
Replace the bulb in the glove
compartment5 watt bulb
1 Pry the lamp out using a screwdriver
2 Remove the reflector
3 Replace the bulb.520de102

134n
Lamps and bulbsReplace the luggage compartment
lamp 6 watt bulb
1 Pry the lamp out using a screwdriver
2 Remove the reflector
3 Replace the bulb.520de072
Replace the engine compartment
lamp 10 watt bulb
1 Using a screwdriver, press on the
black detent and remove the lamp
lens
2 Replace the bulb.520de101

135n
IndexDataTechnologyRepairsCar careControlsOverview
Changing a wheel Safety tiresYour BMW Z8 roadster is equipped
with safety tires.
The safety tires are made of self-sup-
porting tires and customized wheel
rims. Reinforcing the tires makes sure
that they remain upright and still drive-
able to a limited degree even in the
event of loss of pressure. Your vehicle
is equipped with a tire pressure monitor
that signals you in case of a flat tire.
In the event of tire failure The red indicator lamp on the instru-
ment panel will flash in the event of a
flat tire. In addition, a gong will sound.
Refer to page 65.
Carefully reduce speed to less than
50 mph (80 km/h), avoiding any hard
braking or steering maneuvers while
doing so.
You will still be able to drive about
155 miles (250 km) on your safety tire,
until you can get to a safe place to park,
a gas station, or to your nearest BMW
center. Under minimum vehicle loading,
it could conceivably last more than
155 miles (250 km) sein.
If you cannot immediately determine
which tire is defective just by looking
at it, then check the tire pressure in all
four tires.Have your BMW center replace
your tires. For safety reasons, do
not have safety tires repaired. Your
BMW center has been trained to work
with the safety tires and is equipped
with the necessary special tools.<
If necessary, please have your
BMW center switch the tires on
your vehicle from summer to winter
tires, or the reverse.<
