2000 BMW X5 4.4I Owners Manual

IndexDataTechnologyRepairsCar careControlsOverview
97n
Roller sun blind
*
Independent ventilation system
*
Roller sun blinds for rear side
windows
*
Use the strap to pull out the blinds, then
hook them in the provided attachment. You can use this system to ventilate the
interior and lower its temperature, using
the blower of the automatic climate
control.
The independent ventilation system is
operated via the multi-information
display (MID) or the onboard monitor.
Refer to the separate Owner's Manual.
You can set two different times for the
system to start; it will remain active for
30 minutes. You can also turn it on and
off directly. Since the system uses a
substantial amount of electrical current,
you should refrain from activating it
twice in succession without allowing
the battery to be recharged in normal
operation between use. When a preselected activation time is
set, the independent ventilation system
is operational at outside temperatures
above 60 7 (16 6), or by direct switch
activation. It cannot be switched on
when the vehicle is moving.
The air emerges via the air outlets for
the upper body. Therefore, the air out-
lets must be open for the system to
operate.

98n
The concept The BMW Universal Transmitter re-
places up to three hand-held transmit-
ters of different devices such as
garage-door openers, alarm systems,
or door locking systems. The BMW
Universal Transmitter recognizes and
"learns" the transmitted signal of each
of the original hand-held transmitters.
The signal of an original hand-held
transmitter can be programmed on one
of the three channel keys. Following
that, each of the devices can be actu-
ated with the appropriately-pro-
grammed channel key. The indicator
lamp flashes to confirm transmission of
the signal.
If the vehicle is sold, the memory of the
channel keys should be cleared as de-
scribed on page 100.
During programming and before
every remote actuation of a
programmed device by the BMW
Universal Transmitter, check to be sure
that there are no persons, animals or
objects within the actuation range of
the device in order to prevent possible
injuries or damage. Also, comply with
the safety precautions of the original
hand-held transmitter.<
To Canadian residents:
During programming, your hand-
held transmitter may automatically stop
transmitting after two seconds. This
may not be long enough to program the
BMW Universal Transmitter. If you are
programming from one of these hand-
held transmitters, the Universal Trans-
mitter's light may begin to flash in a
series of double-blinks. If this occurs,
continue to hold the button of the Uni-
versal Transmitter while you reactivate
your hand-held transmitter. You may
have to repeat this function several
times while programming.<
Before programming, read the
"User information" section on
page 100.<
Original hand-held transmitter
If this symbol is present on the
packaging or in the instructions
of the original hand-held trans-
mitter, it may be assumed that this
hand-held transmitter is compatible
with the BMW Universal Transmitter.
Checking for the conversion code To determine whether the original
hand-held transmitter is provided with a
conversion-code system, you may ei-
ther read the instructions for the origi-
nal hand-held transmitter or program a
channel key as described on the next
page (left-hand column under "Pro-
gramming").
Then press and hold the programmed
channel key of the BMW Universal
Transmitter. If the indicator lamp of the
BMW Universal Transmitter flashes for
two seconds and then comes on
steadily, the original hand-held trans-
mitter is provided with a conversion-
code system. With a conversion-code
system, program the channel keys as
described on the next page (right-hand
column under "Programming a hand-
held transmitter with conversion code").
If you have additional questions,
please consult your BMW center
or call 1-800-355-3515.
You can also visit this website
www.bmwusa.com.<
BMW Universal Transmitter

IndexDataTechnologyRepairsCar careControlsOverview
99n
BMW Universal TransmitterProgramming 1 Channel keys
2 Indicator lamp
3 Receiver for programming
Read and comply with the safety
precautions on the previous
page.<
1 Turn the ignition key to position 2.
2 For initial use: press and hold both
outside keys 1 until the indicator
lamp 2 flashes, and then release
them. The three channel keys are
cleared.530us136
3 Hold the original hand-held transmit-
ter toward the receiver 3 a maximum
of 2 inches (5 cm) away.
4 Press the transmission key of the
original hand-held transmitter
(arrow 2) and the desired channel key
of the Integrated Universal Remote
Control (arrow 1) simultaneously. Re-
lease both keys as soon as the indi-
cator lamp flashes rapidly.
5 To program other original hand-held
transmitters, repeat steps 3 and 4.
The corresponding channel key is now
programmed with the signal of the orig-
inal hand-held transmitter. 530us137
Programming a hand-held
transmitter with conversion code
Read and comply with the safety
precautions on previous page.<
When programming the BMW Universal
Transmitter, consult the instructions for
the specific device. For using the BMW
Universal Transmitter with a conver-
sion-code system, note the following
supplemental programming instruc-
tions:
A second person facilitates
programming of the BMW
Universal Transmitter.<
1 Program the BMW Universal
Transmitter as described previously
under "Programming."
2 Press and hold the programming key
on the receiver of the device for ap-
proximately two seconds until the
programming lamp on the device
comes on.
3 Press the desired channel key of the
BMW Universal Transmitter three
times.
If you have additional questions,
please consult your BMW cen-
ter.<

100n
BMW Universal TransmitterClearing the channel keys
Read and comply with the safety
precautions on page 98.<
The memory of individual channel keys
cannot be deleted. However, the three
channel keys can be cleared together
as follows:
>Press and hold both outside keys of
the BMW Universal Transmitter until
the indicator lamp flashes, and then
release them.
All of the channel keys are cleared.
User informationDo not use this BMW Universal Trans-
mitter with any garage door opener that
lacks safety "stop" and "reverse" fea-
tures as required by federal safety stan-
dards (this includes any garage door
opener model manufactured before
April 1, 1982).
This device complies with Section 15 of
the FCC Rules. Operation is subject to
the following two conditions: as defined
in the regulations, this device must not
emit harmful interference, and must be
shielded against interference from ex-
ternal sources to prevent unauthorized
or inadvertent activation.

IndexDataTechnologyRepairsCar careControlsOverview
101n
Glove compartment Storage compartments To open Pull the handle and the lamp comes on.To close Fold the cover up. To lock Use one of the master keys. A master
key is also required for unlocking.
If you turn over only your door and
ignition key 3 for valet parking
(refer to page 34), for example, access
to the glove compartment is not possi-
ble.< 530us066
To prevent injury in the event of a
crash, close the glove compart-
ment immediately after use.<
Rechargeable flashlight
*
Located on the left-hand side of the
glove compartment.
Features integral overload-protection,
so it can be left in its holder continu-
ously.
Be sure that the flashlight is
switched off when it is inserted
into its holder. Failure to comply with
this precaution could lead to over-
charging and damage.<
You will find two storage compartments
in the armrest between the front seats.
To open the top compartment:
Press the button (arrow 1).
You will find a cellular phone
* in this
compartment.
To move the armrest or open the lower
compartment:
Pull the handle (arrow 2).
In this compartment, you will find a coin
tray and a storage compartment* for
cassettes or CDs.
You will find additional storage com-
partments in all of the doors as well as
on the backrests of the front seats.
530us068

102n
Cellular phone
*
Cup holders Glasses compartment
Handsfree system On vehicles with a telephone hookup
*,
the handsfree speaker is positioned in
the headliner.
For further information on the cellular
phone, refer to the separate Owner's
Manual.
530us070
Front Below the sliding cover (illustration).
Remove the insert which is a compart-
ment for storing pens.Rear A the end of the center console under
the lighter.
Press to open; push back inward to
close. 530us067
Press the button to open; fold upward
to close. 530us069

IndexDataTechnologyRepairsCar careControlsOverview
103n
Ashtray, front Cigarette lighter To open Press briefly in the direction indicated
by the arrow.
To extinguish a cigarette, tap off the
ash and gently press the tip into the
funnel. 530us071
To empty Press the edge of the lid (arrow):
You can now pull the ashtray upwards
for removal. 530us072
Press the lighter in.
Remove the lighter as soon as it
retracts.
Hold or touch the hot cigarette
lighter by the knob only. Holding
or touching it in other areas could result
in burns.
The cigarette lighter remains opera-
tional when the ignition key has been
removed.
For this reason, do not leave unsuper-
vised children in the vehicle.< 530us073

104n
Cigarette lighter Ashtray, rear Lighter, rear Cigarette lighter socket This socket is suitable for attaching
power supplies for flashlights, car vac-
uum cleaners and other appliances up
to a rating of approx. 200 watts at
12 volts. Avoid damage to the socket
caused by inserting plugs of a different
shape or size.
You will find additional power outlets in
the cargo area. Refer to page 110.
To open Rotate the cover upward. To empty Remove the insert tray. 530us074
Press the lighter in.
Remove the lighter as soon as it
retracts.
Hold or touch the hot cigarette
lighter by the knob only. Holding
or touching it in other areas could result
in burns.
The cigarette lighter remains opera-
tional when the ignition key has been
removed.
For this reason, do not leave unsuper-
vised children in the vehicle.< 530us075
