2000 BMW 540I SEDAN width

136n
Tire replacement Tire rotation Uniform Tire Quality GradingQuality grades can be found where ap-
plicable on the tire sidewall between
tread shoulder and maximum section
width. For example:
Treadwear 200 Traction AA
Temperature A
Do not use retreaded tires, since
driving safety may be impaired by
their use. This is due to the possible
variations in casing structures and, in
some cases, to their extreme age,
which can lead to a decrease in their
durability.<
Tire ageThe date on which the tire was manu-
factured is indicated by the code on the
sidewall:
DOT ... 129 indicates that the tire was
manufactured in Week 12 of 1999.
BMW recommends the replacement of
all tires when the tires are no more than
6 years old, even if a tire life of 10 years
is possible.
Spare tires over 6 years old should be
used only in case of emergency. Such a
tire should be replaced by a new tire
immediately, and should not be
mounted together with new tires.
Between the axlesThe tread wear patterns at the front end
differ from those at the rear Ð the actual
patterns will vary according to individ-
ual driving conditions. In the interests of
safety and maintaining optimal handling
characteristics, interaxle tire rotation is
not recommended.
If a proposed interaxle rotation of tires
is based on economic considerations,
one should consider whether the costs
for the rotation are likely to be recap-
tured by any increase in the service life
of the tires which might be realized. In
principle, interaxle tire rotation should
be performed at short intervals, with a
maximum of 3,000 miles (5,000 km).
Consult your authorized BMW center
for more information.

137n
RepairsIndexOverview Controls Car care Technology Data
Tire rotation Wheel and tire combinationsShould you decide to rotate the tires, it
is essential to comply with the follow-
ing: Rotate tires on the same side only,
since braking characteristics and road
grip could otherwise be adversely
affected.
Following tire rotation, correct the tire
inflation pressure.
If different tire sizes are mounted
on the front and rear axles (refer to
page 140), the wheels may not be
rotated from one axle to the other.<
The right choiceUse only tires approved by BMW.
Refer to the information beginning on
page 140.
Because of the high speeds this vehicle
can reach, the use of specific tire
brands, specifications and dimensions
is mandatory. Consult any BMW center
for details.
Comply with national, state, or province
regulations.
The correct wheel-tire combina-
tion affects different systems such
as ABS, ATC, ASC+T/DSC. The func-
tion of these systems is impaired if im-
proper wheel-tire combinations are
used.
For this reason, use only tires of the
same brand and tread pattern. In the
event of a flat tire if you have mounted
winter tires, for example, remount the
approved wheel-tire combination as
soon as possible.<
Codes on tires and wheelsThe tire codes will aid you in selecting
the correct tire.
Codes on radial tires:
The speed rating indicates the ap-
proved maximum speed for the tire.
Summer tires:
S = up to 112 mph (180 km/h)
T = up to 118 mph (190 km/h)
H = up to 130 mph (210 km/h)
V = up to 150 mph (240 km/h)
W = up to 167 mph (270 km/h)
Y = up to 186 mph (300 km/h)
ZR= over 150 mph (240 km/h)Example:
Nominal width
in mm
Aspect ratio in %
Radial tire code
Rim diameter in inches
Load rating
(not on ZR tires)
Speed rating
(before R on ZR tires)
235/60 R 16 100 W

138n
Wheel and tire combinations Winter tiresWinter tires:
Q M+S = up to 100 mph (160 km/h)
T M+S = up to 118 mph (190 km/h)
H M+S = up to 130 mph (210 km/h)
Codes stamped on light-alloy wheels:
Protect valve inserts against dirt using
screw-on valve stem caps. Dirt in the
valves frequently leads to slow leaks. Example:
Rim width
in inches
Code letter for
flange type
Symbol for full-drop
center rim
Rim diameter in inches
Hump on the 2 rim shoulders
8x16H2
J
Choosing the right tireBMW recommends winter tires (M+S
radial tires) for driving in adverse winter
road conditions. While tires known as
all-season tires (M+S designation) pro-
vide better winter traction than summer
tires with load ratings H, V, W, Y and
ZR, they generally do not achieve the
performance of winter tires.
In the interests of safe tracking and
steering response, install radial tires
made by the same manufacturer and
with the same tread configuration on all
four wheels if you elect to mount winter
tires.
Mount only winter tires which have
been approved by BMW. Any BMW
center will be glad to provide you with
information for selecting the best winter
tires for your particular driving condi-
tions.

Everything from A to Z Third brake lamp, bulb
replacement171
Through-loading
system112
Tilt alarm38
Tire134
Change173
Code137
Damage134
Inflation pressure30, 134
Monitoring inflation
pressure92, 194
Renewal135
Rotation between
axles135
Tread134
Valve caps138
Tire Pressure Control
(RDC)92, 194
Tools166
Torque198
Tow fittings183
Towing183
Tow-starting183
Track width199
Transmission70
Tread depth, tires134
Trip odometer82
Trunk, capacity201
Turn signal77
Bulb replacement169
Turning circle199
U
Universal Transmitter105
Used oil151

V
Valve caps138
Vanity mirror55
Vehicle battery176
Vehicle care, exterior156
Vehicle care, interior158
Vehicle Identification
Number153
Vehicle painting156
Vehicle removal from
service160
Vehicle storage160
Ventilation98, 102
Ventilation in the rear102
Ventilation while parked104
Ventilation, draft-free102
Vinyl upholstery, care158
Viscosity150

W
Warning lamps22
Warranty and Service Guide
Booklet (Canadian
models)154
Washer fluid reservoir
Capacity203
Filling148Washing your car155
Water on the roads125
Waxing, paintwork157
Weights201
Wheelbase199
Wheels and tires137
Width199
Windows
Convenience
operation36
Windows, convenience
operating mode36, 37
Windshield washer fluid
reservoir, capacity203
Windshield washer nozzle
adjustment148
Windshield washer reservoir,
filling148
Windshield wipers77
Winter driving130
Winter operation130
Winter tires138
Wiper blade
replacement166
Wiper/Washer system77
Work in the engine
compartment143

X
Xenon lamps94, 168, 195
