Cooling System
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and radiator cool down beforeremoving the radiator cap.RADIATOR CAP
1. Make sure the engine and radiator
are cool.
2. Turn the radiator cap counter- clockwise, without pressing down
on it, until it stops. This relieves
any pressure remaining in the
cooling system. 3. Remove the radiator cap by
pushing down and turningcounterclockwise.
CONTINUED
Maintenance

Spark Plugs
The spark plugs in your car shouldbe replaced according to the time
and distance recommendations in
the maintenance schedule. Replacement
1. Remove the cover on the front cylinder bank by turning the two
clips one quarter turn
counterclockwise.
2. Clean up any dirt and oil that have collected around the ignition coils. 3. Disconnect the wire connector
from the ignition coil by pushingon the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.
CONTINUED
Maintenance

Lights
3. Remove the bulb by turning itapproximately one-quarter turn
counterclockwise.
4. Insert the new bulb into the hole and turn it one-quarter turn clock-
wise to lock it in place.
5. Push the electrical connector back onto the bulb. Make sure it is onall the way.
6. Turn on the headlights to test the new bulb.
7. Reinstall the radiator reserve tank. Replacing Front Turn Signal and
Side Marker Light Bulbs
1. If you are changing the bulb on the driver's side, start the engine,
turn the steering wheel all the way
to the right, and turn off the
engine. If you are changing the
bulb on the passenger's side, turn the steering wheel to the left.
HOLDING CLIP
2. Use a flat-tipped screwdriver to remove the holding clip from the
inner fender.
3. Pull the inner fender away from the fender and bumper.
CONTINUED
Maintenance

Lights
4. Remove the socket from theheadlight assembly by turning it
one-quarter turn counterclockwise. 5. Remove the burned out bulb from
the socket by pushing it in and
turning counterclockwise until it unlocks.
6. Install the new bulb in the socket. Turn it clockwise to lock it in place.
7. Insert the socket back into the headlight assembly. Turn it
clockwise to lock it in place.
8. Test the lights to make sure the new bulb is working.
9. Put the inner fender cover in place. Install the holding clip. Lock it in
place by pushing on the center. Replacing Rear Bulbs
CARGO NET MOUNTING
BUTTON
FASTENER
1. Open the trunk.Remove the fastener on the edge
of the trunk opening by turning it
counterclockwise with a coin. Unscrew the cargo net mounting
button. Pull the lining back.
Maintenance

Lights
2. Determine which of the four bulbsis burned out: stop/taillight or turn
signal light, back-up light
3. Remove the socket by turning it one-quarter turn counterclockwise. 4. Pull the bulb straight out of its
socket
Push the new bulb straight into
the socket until it bottoms.
5. Reinstall the socket into the light assembly by turning it clockwise
until it locks.
6. Test the lights to make sure the new bulb is working.
7. Reinstall the trunk lining. Make sure it is installed under the edge
of the trunk seal 8. Put the fastener in the hole on the
side of the trunk lining and push
on the center until it locks (the
center is flush with the head).
9. Screw the cargo net mounting button back into the hole.
Maintenance

Lights
Replacing a High-mount BrakeLight Bulb
1. Open the trunk and remove the socket from the light assembly byturning it one-quarter turn counter-
clockwise.
2. Remove the burned-out bulb by pulling it straight out of the socket
3. Install the new bulb and reinstall the socket Make sure the newbulb is working. Replacing a Rear License Bulb
1. Use a small phillips screwdriver to remove the lens from the license
plate light assembly.
2. Remove the bulb by pulling it straight out Push the new bulbinto the socket
3. Reinstall the lens. Replacing Bulbs in the Interior
Lights
The ceiling light, door light and vanity mirror light come apart thesame way, but they do not use the
same type of bulb.
Maintenance

Changing a Flat Tire
6. The jack is behind a cover in theright fender. Remove the cover by
turning the handle counterclock-
wise, then pulling on the cover.
JACK
7. Turn the jack's end bracket counterclockwise to loosen it, then
remove the jack.
WHEEL NUTS
8. Loosen the five wheel nuts 1/2turn with the wheel wrench.
Faking Care of the Unexpected

Changing a Flat Tire
JACKING POINT
9. Locate the jacking point nearestthe tire you need to change. It is
pointed to by an arrow molded into
the underside of the body. Place
the jack under the jacking point.
Turn the end bracket clockwise until the top of the jack contacts
the jacking point. Make sure the
jacking point tab is resting in the
jack notch.
WHEEL WRENCH
10. Use the extension and wheel wrench as shown to raise the
vehicle until the flat tire is off theground. 11. Remove the wheel nuts and flat
tire. Temporarily place the flat tireon the ground with the outsidesurface of the wheel facing up.
Placing the wheel face down could
mar its finish.
CONTINUED
Taking Care of the Unexpected
EXTENSION
