Instrument
s an d Control s

This section gives information about the controls and displays thatcontribute to the daily operation of
your Acura. All the essential controls are within easy reach.
Control Locations............................ 52
Indicator Lights................................ 53
Gauges.............................................. 58
Speedometer................................ 58

Tachometer.................................. 58
Odometer...................................... 59

Trip Meter/Outside Temperature Indicator............ 59
Temperature Gauge.................... 60 Fuel Gauge................................... 60
Maintenance Required Indicator.................................... 61
Controls Near the Steering Wheel........................................ 62

Headlights.................................... 63

Automatic Lighting..................... 64
Daytime Running Lights............. 65

Instrument Panel Brightness..... 66

Turn Signals................................. 66

Fog Lights.................................... 67 Windshield Wipers...................... 68
Windshield Washers................... 70

Hazard Warning........................... 70

Rear Window Defogger.............. 71
Steering Wheel Adjustments..... 71
Steering Wheel Controls ................ 73 Cruise Control.............................. 73
Remote Audio Controls .............. 76
Keys and Locks................................ 77 Keys............................................... 77
Immobilizer System..................... 78
Ignition Switch............................. 80
Power Door Locks....................... 81
Remote Transmitter.................... 82
Childproof Door Locks............... 85

Trunk............................................86
Glove Box..................................... 87

HomeLink Universal Transmitter......... 88
Customer Assistance.................. 88

Important Safety Precautions.... 88

Training the Transmitter............ 89
Training With a Rolling Code System....................................... 91
Erasing Codes.............................. 92

Seat Adjustments............................. 93
Driver's Seat Adjustments.......... 93
Driver's Lumbar Support............ 95

Front Passenger's Seat

Adjustments............................. 95

Head Restraints........................... 95

Armrest............................................. 96
Mirrors.............................................. 98

Adjusting the Power Mirrors..... 98

Driving Position Memory

System......................................... 100

Seat Heaters................................... 102

Ski Sleeve........................................ 103

Power Windows............................. 105

Moonroof........................................ 106

Parking Brake................................ 108

Digital Clock................................... 108
Sunglasses Holder......................... 110
Beverage Holder............................111

Console Compartment.................. 112

Coin Box......................................... 112
Sun Visor......................................... 113
Vanity Mirror................................. 113
Accessory Power Socket.............. 114 Cigarette Lighter........................... 115

Ashtrays.......................................... 116
Ceiling Lights................................. 117
Courtesy Lights............................. 118

Instrument s an d Control s

Indicato
r Light s

Sea t Bel t Reminde r Ligh t
This indicator lights when you turn the ignition switch ON (II). It is a
reminder to you and your passengers
to protect yourselves by fastening
the seat belts. A beeper also sounds
if you have not fastened your seat

belt.

If you do not fasten your seat belt,
the beeper will stop after a few seconds but the light stays on until
you do. Both the light and the beeper stay off if you fasten your seat belt
before turning on the ignition. Lo
w Oi l Pressur e
Indicato r

The engine can be severely damaged if this light flashes or stays on when

the engine is running. For complete

information, see page 282.

Charging Syste m
Indicato r

If this light comes on when the
engine is running, the battery is not

being charged. For complete
information, see page 283.
Parkin
g Brak e an d Brak e Syste m
Indicato r
This light has two functions:
1. It comes on when you turn the ignition switch ON (II) as a
reminder to check the parking
brake. If the parking brake is not set, it goes off after the engine
starts. If the parking brake is set,
it goes off when you release the
parking brake with the engine
running. Driving with the parking
brake applied can damage the
brakes and tires.
2. If it remains lit after you release the parking brake while the engineis running, or comes on while
driving, it can indicate a problem
in the brake system. For complete
information, see page 285.
Instrument s an d Control s U.S
.
Canad
a

BRAK E

Indicato
r Light s
Doo r an d Brak e Lam p Monito r
The appropriate light comes on in this display if the trunk or any dooris not closed tightly. If a brake light
does not work, the BRAK E LAM P
indicator comes on when you push
the brake pedal with the ignition switch ON (II).
A burned out brake light is a hazard when drivers behind you cannot tell
you are braking. Have your brakelights repaired right away.
All the lights in the monitor display come on for a few seconds when you
turn the ignition switch ON (II). Tur
n Signa l an d
Hazar d Warnin g
Indicator s
The left or right turn signal light blinks when you signal a lane changeor turn. If the light does not blink or
blinks rapidly, it usually means one of the turn signal bulbs is burned out (see page 248). Replace the bulb as
soon as possible, since other drivers
cannot see that you are signalling.
When you turn on the Hazard
Warning switch, both turn signal lights blink. All turn signals on the outside of the vehicle should flash.
Low Fue l Indicato r
This light comes on as a reminder that you must refuel soon. Hig
h Bea m Indicato r
This light comes on with the high beam headlights. See page 63 for
information on the headlight

controls.

On Canadian models, this indicator
conies on with reduced brightness
when the Daytime Running Lights (DRL) are on (see page 65).
"Daytim e Runnin g
Lights " Indicato r

Canadian models only

This indicator lights when you turn the ignition switch to ON (II) with
the headlight switch off and the
parking brake set. It should go off if
you turn on the headlights or release the parking brake. If it comes on atany other time, it means there is a
problem with the DRL. There may also be a problem with the high

beam headlights.

Instrument s an d Control s
D R L

Control
s Nea r th e Steerin g Whee l

Do not leave the light switch in
AUTO if you will not be driving the car for an extended period (a week
or more). You should also turn off
the lights if you plan to leave the engine idling or the engine off for a
long time. This will prevent the
battery from discharging.
The automatic lighting feature iscontrolled by a sensor located on top
of the dashboard. Do not cover thissensor or spill liquids on it. Daytim
e Runnin g Light s
(Canadia n Models )
With the headlight switch off, the high beam headlights come on with
reduced brightness when you turn
the ignition switch to ON (II) andrelease the parking brake. They
remain on until you turn the ignition off, even if you set the parking brake.
The headlights revert to normal operation when you turn them on
with the switch.
Instrument s an d Control s

LIGH
T
SENSO R

Steerin
g Whee l Control s

3. Press and release the SET/decel button on the steering wheel. TheCRUISE CONTROL light on the
instrument panel comes on to show the system is now activated. The cruise control may not hold the
set speed when you are going up and
down hills. If your speed increases
going down a hill, use the brakes to slow down to the desired speed. This
will cancel the cruise control. To resume the set speed, press the
RESUME/accel button. The
CRUISE CONTROL light on the
instrument panel comes on.
When climbing a steep hill, the automatic transmission may
downshift to hold the set speed. Changing the Set Speed
You can increase the set cruising
speed in any of these ways: Press and hold the RESUME/
accel button. The car will acceler- ate. When you reach the desired
cruising speed, release the button. Push on the accelerator pedal. Ac-
celerate to the desired cruising
speed and press the SET/decel
button. To increase your speed in very
small amounts, tap the RESUME/
accel button repeatedly. Each time
you do this, your car will speed up about 1 mph (1.6 km/h).

Instrument s an d Control s

RESUME
/

acce l

BUTTO N

SET/dece l
BUTTO N

Steerin
g Whee l Control s

You can decrease the set cruising speed in any of these ways: Press and hold the SET/decel
button. The car will decelerate. Release the button when you
reach the desired speed. Tap the brake pedal lightly with
your foot. The CRUISE CONTROL light on the
instrument panel will go out.
When the car slows to the desired speed, press the SET/decel button.
The car will then maintain the desired speed.
To slow down in very small amounts, tap the SET/decel
button repeatedly. Each time you do this, your car will slow down
about 1 mph (1.6 km/h). Even with the cruise control turned
on, you can still use the accelerator
pedal to speed up for passing. After
completing the pass, take your foot
off the accelerator pedal. The car
will return to the set cruising speed.
Resting your foot on the brake pedal
will cause the cruise control to
cancel.
Cancelling the Cruise Control

CANCEL

BUTTO N

You can cancel the cruise control in any of these ways:
Tap the brake pedal. Push the CANCEL button on the

steering wheel.

Press the Cruise Control Master

Switch.

Instrument s an d Control s

CONTINUED

Steerin
g Whee l Control s

When you push the CANCEL button, or tap the brake pedal, the CRUISE
CONTROL light on the instrument
panel will go out and the car will
begin to slow down. You can use the accelerator pedal in the normal way.
The system remembers the previously-set cruising speed. To
return to that speed, accelerate toabove 25 mph (40 km/h) and then
press and release the RESUME/ accel button. The CRUISE
CONTROL light comes on. The car
will accelerate to the same cruising speed as before. Pressing the Cruise Control Master
Switch turns the system completely
off and erases the previous cruising
speed from memory. To use the
system again, refer to Using the

Cruise Control.
Remot
e Audi o Control s

AUDIO/C H

BUTTO N

These buttons let you control some functions of the audio system with-out removing your hands from the
wheel. Refer to page 161 for a com- plete explanation.
Instrument s an d Control s

Drivin
g Positio n Memor y Syste m

Doing any of the following after
pressing the MEMO button will cancel the storing procedure. Not pressing a memory button
within 5 seconds. Readjusting the seat or steering

position.

Readjusting the outside mirror

position.

Each memory button stores only one driving position. Storing a new
position erases the previous setting stored in that button's memory. If
you want to add a new position while retaining the current one, use theother memory button.
All stored driving positions will be lost if your car's battery goes dead or
is disconnected. Selecting a Memorized Position
You can select memorized positions as follows.
1. Make sure the parking brake is set and the shift lever is in Park.
2. Insert the key in the ignition switch. If you do not insert the key
in the ignition switch, the steering
wheel will not adjust to the memorized position until you do. 3. Press the desired memory button
(1 or 2) until you hear a beep, then
release the button.
The system will move the seat, steering wheel and outside mirrors
to the memorized positions. The
indicator light in the selected memory button will flash during
movement. When the adjustments are complete, you will hear two
beeps and the indicator light will
remain on.

CONTINUED

Instrument s an d Control s
MEMOR
Y BUTTON S
