1999 VOLVO V70 remote control

Master key
This key operates all locks (ignition switch/steering wheel lock, driver's door, trunk/tailgate and glove compartment).
Service key
This key operates the driver's door and the ignition switch/steering wheel lock.
NOTE:
An an added anti-theft measure, new keys have been developed which may take slightly longer to copy or replace if
the original keys are misplaced. Duplicate keys may be ordered from your Volvo retailer.
The key number codes are stamped on a separate tag supplied with the keys. This tag should be separated from the
key ring and kept in a safe place.
Immobilizer (start inhibitor)
Each of the keys supplied with your car contains a coded transmitter and receiver (transponder). The code in the key is
transmitted to an antenna in the ignition switch where it is compared to the code stored in the start inhibitor module.
The car can only be started if a properly coded key is used.
If you misplace a key, take the other keys to an authorized Volvo retailer. The existing code in the start inhibitor
module and all the keys will be erased as an antitheft measure and a new code will be programmed in.
NOTE:
Not more than one of the keys for you car should be kept on the same key ring. This could cause conflicting signals to
be transmitted to the ignition switch, making it imposible to start the car.
This device complies with FCC rules Part 15. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference and (2) this device must accept any interference that may be received, including
interference that may cause undesired operation.
pg. 43 Doors and Locks
Doors and locks
Your car is equipped with a two door operated central locking system.
The key, used on the driver's doors, the remote control, or central locking button, will lock/unlock all doors,
trunk/tailgate.
ProCarManuals.com

Remote keyless entry system
Your car is equipped with a remote control transmitter. This transmitter uses a readio frequency which will allow
“keyless” entry into the passenger compartment or the trunk. You will be supplied with two coded key ring
transmitters, which willenable you to lock/unlock all doors and the trunk/tailgate from a distance of 10-15 feet (3-5
meters).
The car can also be locked/unlocked with the key.
As an extra security precaution in certain situations (valet parking,etc.), Volvo recommends that the transmitter not be
included when the keys are given to anyone. The service key can be used instead. If one of transmitters is misplaced ,
contact the nearest authorized Volvo retailer for assistance.
Using the remote control
* Press the LOCK button once to lock all doors and trunk/tailgate.
ProCarManuals.com

* Press the UNLOCK button once to unlock the driver’s door only. Press this button again (within 10 seconds) to
unlock all doors, trunk/tailgate.
* Press the OPEN TRUNK/TAILGATE button twice within 3 seconds to pop open the trunk or unlock the tailgateThis device complies with FCC rules Part 15. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference and (2) this device must accept any interference that may be received, including
interferencethat may cause undesired operation.
NOTE: If only the driver’s door is unlocked, the lock will automatically reengage (re-lock) and the alarm will reset
after 2 minutes unless the door has been opened.
The lock/unlock and alarm features can also be utilized by using the keys. See section: Doors and Locks on page 43
.
If the alarm LED glows coninuously for 5 seconds, this indicates a fault in the system or that a door is not properly
closed.
WARNING! Volvo does not recommend using the transmitter to lock the doors from inside the car. On cars
equipped with an alarm, the alarm would be activated and would sound when one of the doors is opened. The doors
must not be locked using the remote transmitter while the vehicle is occupied. In case of an accident, this may hinder
rapid access to the occupants of the vehicle. The alarm will also sound on models equipped with this feature.
NOTE : To avoid leaving your keys in the car, make a habit of always locking the car with the remote control.

Contents | Top of Page
ProCarManuals.com

Chapter 10 - Audio systems
pg. 141 Audio systems
Audio systems
This chapter describes the audio system in your car. pg. 142
SC-813
pg. 155
SC-816
pg. 171
SC-900/901
pg. 194
General information
pg. 142 Audio system SC-813 (certain models)
The following pages describe the use of your SC-813 Cassette radio and CD remote control
1. On/off (push)
2.
Volume (turn)
Pause/Mute (push)
Balance (pull)
3. Active Sound Control
4. CD changer selector
5.
Tape mode selector
Tape direction selector PROG
6. Bass control
7. Treble control
8. Fader control
9.
Preset buttons
ProCarManuals.com

P
Paint touch -up............................110Parking brake...........................19,32Parking brake reminder light...............20Parking lights.............................22Polishing.................................113Power seats............................49,108Power steering fluid..................126,134Power windows..........................40,108
R
Radio
SC-813..................................142
SC-816..................................155 SC-900/901..............................171Radio Data System - RDS...................176Rails (roof)...............................75Reading lights.............................51Rear fog light..........................19,24Rear suspension...........................136Rear window demister.......................25Rear/side -view mirrors.....................50Refueling..................................67Remote control (central locking system)....44Remote keyless entry system................44Replacing bulbs........................96-101Replacing fuses...........................102Reporting Safety Defects...................14Road Assistance...........................140Roadholding................................75Roof rails/racks...........................75
S
Safety defects (reporting).................14Safety locks...............................48Seat belt maintenance......................14Seat belts.............................2,3,12Seat belts - cleaning.....................114Seats......................................49Securing cargo.............................62Service reminder indicator..............19,21Servicing.............................120,121Shift lock..............................69,71Shiftlock release (override)..............108Side cargo net.............................61Side Impact Protection System (SIPS)........8Side -view mirrors - heated.................25SIPS........................................8Snow chains................................87Snow tires.................................87Spare tire.................................94Spare tire (sedan).........................55Spare tire (wagon).........................56Spark plugs...............................136Specifications............................133Spool -out (seat belt)......................12SRS.....................................5,6,7SRS diagnostic system......................20SRS warning light.....................5,19,20Stability and Traction Control(STC).19,21,25,81Start Inhibitor (Immobilizer)..............42Starting the engine........................69Steering wheel adjustment..................34Steering wheel lock........................23Storage compartments.......................54Studded tires..............................87Sun roof............................25,52,108
