1999 TOYOTA RAV4 clock

'99 Rav4.U3
1. Instrument panel light control knob
2. Headlight and turn signal switch
3. Wiper and washer switches
4. Clock
5. Center differential lock button or driving
pattern selector button
6. Air conditioning controls
7. Emergency flasher switch
8. Rear window defogger switch
9. Car audio
10. Cigarette lighter
11. Ignition switch
12. Cruise control switch
13. Tilt steering lock release lever
14. Power door lock switch (without power windows)
15. Power rear view mirror control switch

'99 Rav4.U
12
CAUTION
To avoid serious personal injury, you
must do the following. Always make sure the head, hands
and other parts of the body of all
occupants are kept completely in-
side the vehicle before you close
the power windows. If someone's
neck, head or hands gets caught in
a closing window, it could result in
a serious injury. When anyone
closes the power windows, be sure
that they operate the windows safe-
ly.
When small children are in the ve-
hicle, never let them use the power
window switches without supervi-
sion. Use the window lock button to
prevent them from making unex-
pected use of the switches.
Never leave small children alone in
the vehicle, especially with the igni-
tion key still inserted. They could
use the power window switches and
get trapped in a window. Unat-
tended children can become in-
volved in serious accidents.
To open the quarter window, pull the
latch handle toward you and swing it
fully out.
When closing the window, make sure it is
completely closed.
CAUTION
When the quarter windows are
opened, observe the following: Depending on driving conditions,
e.g. driving the vehicle with the
front windows slightly open, you
may smell exhaust fumes in the ve-
hicle. If so, close the quarter win- dows.
LOCKING AND UNLOCKING WITH KEY
Insert the key into the keyhole and turn it.
To lock: Turn the key counterclockwise.
To unlock: Turn the key clockwise.
When closing the back door (hardtop) or
tailgate (soft- top), make sure it is fully
closed.
See ºLuggage stowage precautionsº in
Part 2 for precautions to observe in load-
ing luggage.
Quarter window
(2- door hardtop)
Back door (hardtop) and
tailgate (soft- top)

'99 Rav4.U15
2. To remove the fuel tank cap, turnthe cap slowly counterclockwise,
then pause slightly before removing
it. After removing the cap, hang it
on the cap hanger.
It is not unusual to hear a slight swoosh
when the cap is opened. When insta lling,
turn the cap clockwise till you hear aclick.
If the cap is not tightened securely, the
malfunction indicator lamp comes on.
Make sure the cap is tightened securely.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.
CAUTION
Make sure the cap is tightened se-
curely to prevent fuel sp illage in
case of an accident.
Use only a genuine Toyota fuel tank
cap for replacement. It has a built-
in check valve to reduce fuel tank
vacuum.
Electric moon roof
Sliding operation
Tilting operation

'99 Rav4.U
18
3. Push back the auxiliary catch to re- lease it from the hook. Then lift the
sun roof panel and pull it out. ÐStowingInstall the removed sun roof panel on
the tailgate as follows.
NOTICE
If the rear seats are reclined, return
them to the upright position beforeclosing the tailgate. Otherwise, they will interfere with the installed sun
roof panel, possibly damaging thepanel.
1. Remove the holder from the tailgate by turning the bolts counterclock-
wise.

'99 Rav4.U19
2. Set the front edge of the sun roofpanel into the holders.3. Place the removed holder over thesun roof handle.4. Secure the holder by turning thebolts clockwise.
NOTICE
Do not drive the vehicle without
checking that the roof panel is se-curely attached to the tailgate.

'99 Rav4.U125
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1- 8
Other equipment
Clock
Cigarette lighter and ashtray
Power outlet
G lov e box
Auxiliary box
Floor mat
Clock
The digital clock indicates the time.
The key must be in the ºACCº or ºONº
position.
To reset the hour: Push the ºHº button.
To reset the minutes: Push the ºMº button.
If quick adjustment to a full hour is de-
sired, push the º:00º button.
For example, if the º:00º button is de-
pressed when the time is between
1:01Ð1:29, the time will change to 1:00.
If the time is between 1:30Ð1:59, the
time will change to 2:00.
If the electrical power source has been
disconnected from the clock, the time dis-
play will automatically be set to 1:00 (one
o'clock).
When the instrument panel lights are
turned on, the brightness of the time in-
dication will be reduced.

'99 Rav4.U127
NOTICE
To prevent the fuse from beingblown, do not use the electricityover the total vehicle capacity of 12V/120W.
To prevent the battery from beingdischarged, do not use the power outlet longer than necessary when
the engine is not running.
Close the power outlet lid when thepower outlet is not in use. Insertinga foreign object other than the ap- propriate plug that fits the outlet,
or allowing any liquid into the out-let may cause electrical failure or
short circuits.
Glove box
To use the glove box, do this.
To open: Pull the lever.
To lock: Insert the master key and turn it
clockwise.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
Auxiliary box
2- door hardtop and soft- top (left side)
2- door hardtop and soft- top (right side),
and 4- door hardtop

'99 Rav4.U
164
To remove the spare tire:
Turn the hold- down nuts counterclockwise
with the wheel nut wrench and remove
them.
When storing the spare tire, put it in place
and secure it to prevent it from flying
forward during a collision or s udden brak-
ing. ÐBlocking the wheel2. Block the wheel diagonally opposite
the flat tire to keep the vehicle from
rolling when it is j acked up.
When blocking the wheel, place a wheel
block from the front for the front wheels
or from the rear for the rear wheels. ÐRemoving wheel ornamentSteel wheels
Aluminum wheels
