Edition 08.96


Cylinder Head, Valve Gear15
Removing
- Remove camshaft page 15-16.
- Remove bucket tappets (do not mix up) and place down with running surface facing down.
- Move piston of the relevant cylinder into top dead centre (TDC).
- Insert assembly device MP 1-213 and set
mounting at height of stud bolt.
- Use assembly lever and thrust piece MP 1-211 to remove valve springs.
Note:
The valves are supported on the piston crownwhen carrying out this step.
- Use MP 1-206 to pull off valve stem seals. Installing
- Fit plastic sleeve -A- onto the valve stem in
order to avoid damaging the new valve stem seals.
- Oil valve stem seal -B-, insert into the fitting tool MP 1-306 and carefully push onto the valve guide.
Notes:
Wait about 30 minutes before starting the
engine after installing the camshaft. The
hydraulic compensating elements have tosettle (otherwise valves will strike the piston).
