1999 OLDSMOBILE INTRIGUE key

yellowblue
2-63 Low Oil Level Light
Your engine is equipped
with an oil level monitoring
system. When the ignition is
turned to ON, the LOW
OIL level light will briefly
come on.
If the light does not flash, have it fixed so it will be
ready to warn you if there's a problem.
If the light stays on, stop the vehicle on a level surface
and turn the engine off. Check the oil level using the
engine oil dipstick. (See ªEngine Oilº in the Index.) If
the light does not flash, have the low oil level sensor
system repaired so it will be ready to warn you if there's
a problem.
The oil level monitoring system only checks oil level
during the brief period between key on and engine
crank. It does not monitor engine oil level when the
engine is running. Additionally, an oil level check is
only performed if the engine has been turned off for a
considerable period of time, allowing the oil normally in
circulation to drain back into the oil pan.
Change Oil Light
The CHANGE OIL light
should come on briefly as a
bulb check when you start
the engine. If the light
doesn't come on, have
it serviced.
If the CHANGE OIL light comes on and stays on after
you start the engine, have the oil changed.
For additional information see ªEngine Oil, When to
Changeº in the Index. To reset the Oil Life Monitor, See
ªHow to Reset the Change Oil Lightº in the Index.
Security Light
This light will come on
when you turn the key to
START and will stay on
until the vehicle starts.
If you're driving and the security light comes on and
remains on, your Passlock

system is not working
properly. Your vehicle is not protected by Passlock and
you should see your dealer.
ProCarManuals.com

yellowblue
4-3
Drunken Driving
Death and injury associated with drinking and driving is
a national tragedy. It's the number one contributor to the
highway death toll, claiming thousands of victims
every year.
Alcohol affects four things that anyone needs to drive
a vehicle:

Judgment

Muscular Coordination

Vision

Attentiveness.
Police records show that almost half of all motor
vehicle
-related deaths involve alcohol. In most cases,
these deaths are the result of someone who was drinking
and driving. In recent years, over 17,000 annual motor
vehicle
-related deaths have been associated with the use
of alcohol, with more than 300,000 people injured.
Many adults
-- by some estimates, nearly half the adult
population
-- choose never to drink alcohol, so they
never drive after drinking. For persons under 21, it's
against the law in every U.S. state to drink alcohol.
There are good medical, psychological and
developmental reasons for these laws.The obvious way to solve the leading highway safety
problem is for people never to drink alcohol and then
drive. But what if people do? How much is ªtoo muchº
if the driver plans to drive? It's a lot less than many
might think. Although it depends on each person and
situation, here is some general information on
the problem.
The Blood Alcohol Concentration (BAC) of someone
who is drinking depends upon four things:

The amount of alcohol consumed

The drinker's body weight

The amount of food that is consumed before and
during drinking

The length of time it has taken the drinker to
consume the alcohol.
According to the American Medical Association, a
180
-lb. (82 kg) person who drinks three 12-ounce
(355 ml) bottles of beer in an hour will end up with a
BAC of about 0.06 percent. The person would reach the
same BAC by drinking three 4
-ounce (120 ml) glasses
of wine or three mixed drinks if each had 1
-1/2 ounces
(45 ml) of a liquor like whiskey, gin or vodka.
ProCarManuals.com

yellowblue
4-32
To tow your vehicle, follow these steps:
1. Put the front wheels on a dolly.
2. Put the vehicle in PARK (P).
3. Set the parking brake and then remove the key.
4. Clamp the steering wheel in a straight
-ahead position
with a clamping device designed for towing.
5. Release the parking brake.
Loading Your Vehicle
Two labels on your vehicle show how much weight it
may properly carry. The Tire
-Loading Information label
is inside the trunk lid. The label tells you the proper size,
speed rating and recommended inflation pressures for
the tires on your vehicle. It also gives you important
information about the number of people that can be in
your vehicle and the total weight you can carry. This
includes the weight of all occupants, cargo and all
nonfactory
-installed options.
ProCarManuals.com

yellowblue
5-2
Hazard Warning Flashers
Your hazard warning flashers let you warn others. They
also let police know you have a problem. Your front and
rear turn signal lamps will flash on and off.
Press the switch located on
your instrument panel to
make your front and rear
turn signal lamps flash on
and off. Your hazard
warning flashers work no
matter what position your
key is in, and even if the
key isn't in.
To turn off the flashers, press the switch again. When
the hazard warning flashers are on, your turn signals
won't work.
Other Warning Devices
If you carry reflective triangles, you can set one up at
the side of the road about 300 feet (100 m) behind
your vehicle.
ProCarManuals.com

yellowblue
6-18
How to Reset the CHANGE OIL Light
After changing the engine oil, the system must be reset.
To reset the CHANGE OIL light after an oil change:
1. With the ignition key in ON but the engine off, fully
push and release the accelerator pedal slowly three
times within five seconds.
2. If the CHANGE OIL light flashes, the system
is resetting.
3. Turn the key to OFF after the light has finished
flashing, then start the vehicle. If the CHANGE OIL
light comes back on, the engine oil life monitor has
not reset. Repeat the procedure.
What to Do with Used Oil
Did you know that used engine oil contains certain
elements that may be unhealthy for your skin and could
even cause cancer? Don't let used oil stay on your skin
for very long. Clean your skin and nails with soap and
water, or a good hand cleaner. Wash or properly throw
away clothing or rags containing used engine oil. (See
the manufacturer's warnings about the use and disposal
of oil products.)Used oil can be a real threat to the environment. If you
change your own oil, be sure to drain all free
-flowing oil
from the filter before disposal. Don't ever dispose of oil
by putting it in the trash, pouring it on the ground, into
sewers, or into streams or bodies of water. Instead,
recycle it by taking it to a place that collects used oil. If
you have a problem properly disposing of your used oil,
ask your dealer, a service station or a local recycling
center for help.
Engine Air Cleaner/Filter
To check or replace the air filter:
1. Loosen the wing nut on
the air duct.
3800 V6 Engine
ProCarManuals.com

yellowblue
6-65
Fuse Description
HEATED
MIRRORHeated Outside Rearview Mirrors
IGN 0:
CLUSTER
PCM, & BCMInstrument Panel Cluster,
Powertrain Control Module,
Body Control
LOW BLOWER HVAC Control Assembly,
Blower Motor
HVAC Air Temperature Valve Motor,
HVAC Control Assembly,
Solenoid Box, Compass Mirror
CRUISE Cruise Control Module
ABS (3800 V6
Only)Electronic Brake Control Module
(EBCM), ABS Relay, Traction
Control System Disable Switch
BTSI Brake
-Transaxle Shift Interlock
TURN
SIGNALS,
CORN LPSTurn Signals, Cornering Lamps
AIR BAG Air Bag System
CLUSTER Instrument Panel Cluster
DRL Daytime Running LampsFuse Description
PCM, BCM,
U/H RELAYPowertrain Control Module, Body
Control Module, Underhood
Ignition/Relay
RADIO, HVAC,
RFA CLUSTER,
DATA LINKRadio, HVAC Control Assembly,
Instrument Panel Cluster, Remote
Keyless Entry Module, Data Link
Connector, Bose Amplifier
ABS, BCM ABS1
-- Electronic Brake Control
Module (EBCM) (3800 V6 Only),
Body Control Module
CIGAR LTR,
AUX POWERAuxiliary Power, Cigarette
Lighter, Power Drop
INADV POWER
BUSVanity Mirrors, Instrument Panel
Courtesy Lamps, Instrument Panel
Compartment Lamps, Trunk
Courtesy Lamp, Header Courtesy
and Reading Lamps, I/S Lighted
Rearview Mirror
CD CHANGER Cartridge Disk Changer
HIGH BLOWER High Blower Relay
HAZARD Hazard Switch
ProCarManuals.com

yellowblue
6-68
Fuse Description
5 Ignition Switch, Brake Transaxle Shift
Interlock, Stoplamps, Anti
-Lock Brake
System, Turn Signals, Cluster, Air Bag,
Daytime Running Lamps Module
6 Cooling Fan
7 Interior Lamps, Anti
-Lock Brake System
(3800 V6 Engine Only), Keyless Entry,
Data Link, HVAC Head, Cluster, Radio,
Auxiliary Power, Cigarette Lighter,
Bose Amplifier
8 Ignition Switch, Wipers, Radio, Steering
Wheel Controls, Body Control Module,
Auxiliary Power, Power Windows,
Sunroof, HVAC Controls, DRL, Rear
Defog Relay
Relay Description
9 Cooling Fan 2
10 Cooling Fan 3
11 Starter Solenoid
12 Cooling Fan 1Relay Description
13 Ignition Main
14 Air Pump (3.5L V6 if equipped with
California Emissions)
15 Air Conditioning Clutch
16 Horn
17 Fog Lamps
18 Not Used
19 Fuel Pump
Fuse Description
20 Air Pump (3.5L V6))
21 Generator
22 Electronic Control Module
23 Air Conditioning Compressor Clutch
24 Not Used
25 Electronic Ignition (3800 V6 Engine
Only), Fuel Injectors/Electronic Ignition
(3.5L V6 Engine Only)
26 Transaxle Sensor
ProCarManuals.com

yellowblue
7-15 At Least Twice a Year
Restraint System Check
Make sure the safety belt reminder light and all your
belts, buckles, latch plates, retractors and anchorages are
working properly. Look for any other loose or damaged
safety belt system parts. If you see anything that might
keep a safety belt system from doing its job, have it
repaired. Have any torn or frayed safety belts replaced.
Also look for any opened or broken air bag coverings,
and have them repaired or replaced. (The air bag system
does not need regular maintenance.)
Wiper Blade Check
Inspect wiper blades for wear or cracking. Replace blade
inserts that appear worn or damaged or that streak or
miss areas of the windshield. Also see ªWiper Blades,
Cleaningº in the Index.
Weatherstrip Lubrication
Silicone grease on weatherstrips will make them last
longer, seal better, and not stick or squeak. Apply
silicone grease with a clean cloth. During very cold,
damp weather more frequent application may be
required. (See ªRecommended Fluids and Lubricantsº
in the Index.)Automatic Transaxle Check
Check the transaxle fluid level; add if needed. See
ªAutomatic Transaxle Fluidº in the Index. A fluid loss
may indicate a problem. Check the system and repair
if needed.
At Least Once a Year
Key Lock Cylinders Service
Lubricate the key lock cylinders with the lubricant
specified in Part D.
Body Lubrication Service
Lubricate all key lock cylinders, hood latch assembly,
secondary latch, pivots, spring anchor and release pawl
and hood and door hinges, including those for the rear
compartment, glove box door, console door and any
folding seat hardware. Part D tells you what to use.
More frequent lubrication may be required when
exposed to a corrosive environment.
ProCarManuals.com
