1999 OLDSMOBILE AURORA turn signal

yellowblue
4-37 Turn Signals When Towing a Trailer
The arrows on your instrument panel will flash
whenever you signal a turn or lane change. Properly
hooked up, the trailer lamps will also flash, telling other
drivers you're about to turn, change lanes or stop.
When towing a trailer, the arrows on your instrument
panel will flash for turns even if the bulbs on the trailer
are burned out. Thus, you may think drivers behind
you are seeing your signal when they are not. It's
important to check occasionally to be sure the trailer
bulbs are still working.
Your vehicle may have bulb warning messages. When
you plug a trailer lighting system into your vehicle's
lighting system, its bulb warning messages may not let
you know if one of your lamps goes out. So, when you
have a trailer lighting system plugged in, be sure to
check your vehicle and trailer lamps from time to time
to be sure they're all working. Once you disconnect the
trailer lamps, the bulb warning messages again can tell
you if one of your vehicle lamps is out.
Driving On Grades
Reduce speed and shift to a lower gear before you start
down a long or steep downgrade. If you don't shift
down, you might have to use your brakes so much that
they would get hot and no longer work well.
Parking on Hills
CAUTION:
You really should not park your vehicle, with a
trailer attached, on a hill. If something goes
wrong, your rig could start to move. People can
be injured, and both your vehicle and the trailer
can be damaged.
But if you ever have to park your rig on a hill, here's
how to do it:
1. Apply your regular brakes, but don't shift into
PARK (P) yet.
2. Have someone place chocks under the trailer wheels.
3. When the wheel chocks are in place, release the
regular brakes until the chocks absorb the load.
4. Reapply the regular brakes. Then apply your parking
brake, and then shift to PARK (P).
5. Release the regular brakes.
ProCarManuals.com

yellowblue
5-2
Hazard Warning Flashers
Your hazard warning flashers let you warn others. They
also let police know you have a problem. Your front and
rear turn signal lamps will flash on and off.
Press down on the button
located on top of the
steering column, then
release it to turn on the
hazard warning flashers.
The HAZARD light on the
instrument panel will also
come on.
Your hazard flashers work no matter what position your
key is in, and even if the key isn't in.
To turn off the flashers, press the button down again.
When the flashers are on, your turn signals won't work.
ProCarManuals.com

yellowblue
6-33
Bulb Replacement
This section describes bulb changing procedures for
some of your interior and exterior lamps. For any bulb
changing procedure not listed in this section, contact
your service department.
For the type of bulb to use, see ªReplacement Bulbsº
in the Index.
Halogen Bulbs
CAUTION:
Halogen bulbs have pressurized gas inside and
can burst if you drop or scratch the bulb. You or
others could be injured. Be sure to read and
follow the instructions on the bulb package.
Headlamps
A. Front Turn Signal
B. Headlamps
The entire front headlamp assembly must be removed to
replace the front turn signal (A) and low
-beam and
high
-beam headlamp (B) bulbs. You may find it easier
to remove the air cleaner assembly when replacing bulbs
on the driver's side.
If more hand clearance is required, remove the air
cleaner assembly as instructed in Steps 1 through 3
earlier in this section.
ProCarManuals.com

yellowblue
6-38 Front Turn Signal
The front turn signal bulb is on the inboard edge of the
headlamp assembly. To replace a bulb, do the following:
1. Remove the headlamp assembly if you need more
hand clearance.
2. Reach in and press the locking tab while twisting
the bulb assembly one
-quarter of a turn
counterclockwise.
3. Replace the bulb and reverse Step 2 to reassemble.
4. If you removed the headlamp assembly, reassemble
it by aligning the pin and tightening the two bolts to
secure it.
Taillamps
A. Rear Turn Signal
B. Taillamps
ProCarManuals.com

yellowblue
6-40
5. Pull out the taillamp assembly to reach the bulb and
pull it out. To replace, push the bulb back in.
6. Reverse Steps 1 through 5 to replace the taillamp
filler, wing nuts and carpeting.
Rear Turn Signal
The rear turn signal bulb is located on the outboard edge
of the taillamp assembly. Follow the taillamp procedure
for replacing a turn signal bulb.
Back-Up Lamps
To replace a back-up lamp, do the following:
1. Remove the license plate to expose the bulb cover.
ProCarManuals.com

yellowblue
6-63
Fuse Usage
1 Supplemental Inflatable Restraint
(Air Bag)
2 Injectors
3
Anti
-Lock Brake System
4 Left Exterior Lamps
5 Turn Signal Lamps
6 Injectors
7 Climate Controls
8 Right Exterior Lamps
9 Chime (Ignition 1), Memory Set
10 Powertrain Control Module, VATS
PASS
-Key
II
11 Auxiliary Power
12 Interior Lamps
13 Shift Solenoids
14 Linear EGRFuse Usage
15 Cruise Control
16 Perimeter Lights
17 Driver Information Center
18 Converter Oxygen Sensors
19 Radio
20 Open
21 Climate Control Relay
22 Fog Lamps
23 Windshield Wipers
24 Flat Pack Motor
25 TMNSS
26 Cigarette Lighter
27 Crank, Air Bag Module
28 Climate Control Blower
ProCarManuals.com

yellowblue
6-70
Replacement Bulbs
EXTERIOR LAMPS BULB
Front
Front Turn Signal Lamps 3157NA. . . . . . . . . . . . . . . .
Halogen Headlamps
Low Beam 9006. . . . . . . . . . . . . . . . . . . . . . . . . . . .
High Beam 9005. . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear
Back
-Up Lamps 3155. . . . . . . . . . . . . . . . . . . . . . . . .
Stop/Taillamps 3057. . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Turn Signal Lamps 3057. . . . . . . . . . . . . . . . . .
INTERIOR LAMPS BULB
Overhead
Rail Courtesy/Reading Lamps 168. . . . . . . . . . . . . . .
For service information on other bulbs, contact your
dealer's service department.
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions. Please refer to
ªRecommended Fluids and Lubricantsº in the Index for
more information.
Engine Code (L47) 4.0L V
-8
Automatic Transaxle (Overdrive)
When draining or replacing torque converter, more
fluid may be needed.
Pan Removal, Drain Plug
and Replacement 11.0 quarts (10.4 L). . . . . . . . . . . .
After Complete Overhaul 12.6 quarts (12.0 L). . . . . .
When performing either transaxle procedure, check
fluid level when done. More fluid may be needed.
Cooling System13.0 quarts (12.3 L) . . . . . . . . . . . . .
Engine Crankcase7.0 quarts (6.6 L) . . . . . . . . . . . .
When changing filter, up to 0.5 quart (0.5 L) more oil
may be needed.
Fuel Tank18.5 gallons (70.0 L) . . . . . . . . . . . . . . . . .
Windshield Washer
Fluid Tanks3.8 quarts (3.6 L) . . . . . . . . . . . . . . . .
