1999 MERCEDES-BENZ C-CLASS roof

Drive Sensibly - Save Fuel


Fuel consumption, to a great extent, depends on driving habits and operating conditions. To save fuel you should:
• keep tires at the recommended inflation pressures,
• remove unnecessary loads,
• remove roof rack when not in use,
• allow engine to warm up under low load use,
• avoid frequent acceleration and deceleration,
• have all maintenance work performed at regular intervals by an authorized Mercedes-Benz dealer.

Fuel consumption is also increased by driving in cold weat her, in stop-and-go traffic, on short trips and in hilly country.





MERCEDES-BENZ
ROADSIDE ASSISTANCE
1-800-FOR MERCEDES (in the USA.)
1-800-387-0100 (in Canada)






What You Should Know
at the Gas Station


• Fuel:
To prevent fuel vapors from escaping into open air, fully inse rt filler nozzle unit. Only fill fuel tank until the filler nozzl e
unit cuts out - do not overfill. Leaving the engine running and t he fuel cap open can cause the "Check Engine" lamp to
illuminate. Use premium unleaded gasoline: Posted Octane Index 91 (Average of 96 RON/86 MON).
Fuel tank capacity approx. 16.4 US gal (62.0 I).
This includes approx. 2.1 US gal (8.0 I) reserve.

Warning !
Gasoline is highly flammable and poisonous, it burns violently and can cause serious injury. Whenever you
are around gasoline, avoid inhaling fumes and skin cont act, extinguish all smoking materials. Never allow
sparks, flame or smoking materials near gasoline!


• Engine Oil:
Engine oil level check, see Index.
Fill quantity between upper and lower dipstick marking level: 2.1 US qt (2.0 I).
Recommended engine oils, see Index.

• Spark Plugs:
Approved spark plugs, refer to "Technical Data".


• Coolant:
For normal replenishing, use water (potable water quality).
For further information (e.g. anticor rosion/antifreeze), refer to Index.









ProCarManuals.com

Central Locking System

Radio Frequency and Infrared Remote Control
The electronic main key has an integrated radio and infrar ed remote control. Due to the extended operational range
of
the remote control, it could be possible to unintentionally lock or unlock the vehi cle by pressing the transmit button.
A command received by the central locking system is ac knowledged by the function control lamp blinking once. The
vehicle doors, trunk and fuel filler flap can be centrally locked and unlocked. Opening and closing the windows and
sliding/pop-up roof can only be done with the infrared portion of the remote control. Aim transmitter eye (5) at a
receiver (6 or 7) and press transmit button. With vehicle centrally locked, the trunk can also be opened by using the
remote control. If the electronic key is inserted in steeri ng lock, the vehicle cannot be locked or unlocked with the
remote control.




1. Transmit button

Locking

Unlocking

Opening trunk (if not key locked)
2. PANIC button
3. Release button for mechanical key
4. Lamp for battery check and function control
5. Transmitter eye
6. Infrared receiver in driver's door handle
7. Infrared receiver in front passenger door handle


ProCarManuals.com

Opening the Trunk
A minimum height clearance of 5.9 ft ( 1.8 m) is required to open the trunk lid. Press transmit button
until trunk lid is open.

Important !
Do not place remote control in trunk since trunk is locked again when closing the lid.

Note:
If the trunk was previously locked separately, it will remain locked (see Index).

Opening and Closing Windows and Sliding/Pop-Up Roof from Outside
Aim transmitter eye (5) of remote control at door receivers (6 or 7).
To open:
Continue to press transmit button
after unlocking car
The windows and sliding/pop-up roof begin to open after approx. 1 second. To interrupt opening
procedure, release button.
To close:
Continue to press transmit button
after locking car
The windows and sliding/pop-up roof begin to cl ose after approx. 1 second. To interrupt closing
procedure, release button.

Warning !
Never operate the windows or sliding/pop-up roof if there is the possibility of anyone being
harmed by the opening or closing procedure.
In case the procedure causes potential danger, the procedure can be immediately halted by
releasing the remote control button. To reverse direction of movement press
for opening
or
for closing.

Note:
If the windows and sliding/ pop-up r oof cannot be operated automatically by pressing the transmit
button of the remote control then it may be necessa ry to change the batteries in the transmitter
(if ok, battery check lamp in transmitter will light briefly when transmitting), or to synchronize the
electronic main key, see Electronic main key, in Index.


ProCarManuals.com

Power Windows and Sliding/Pop-Up Roof


1 - Opening
2 - Interrupting
3 - Closing


When locking doors or trunk, turn mechanical key in door lock or trunk lock to position 3 and hold.
The windows and the sliding/pop-up roof begin to cl ose automatically after approximately 1 second.
To interrupt the closing procedure, turn mechanical key to position 2. When unlocking doors or trunk,
turn mechanical key in door lock or trunk lock to position 1 and hold. The windows and the
sliding/pop-up roof begin to open automatically after approximately 1 second. To interrupt the opening
procedure, turn mechanical key to position 2.

Warning !

Never operate the windows or sliding/pop-up roof if there is the possibility of anyone being
harmed by the procedure. In case the procedure causes potential danger, the procedure can
be immediately reversed by turning the mechanic al key to the reversed operational direction:
• for opening position (1)
• for closing position (3).

Note:

If the opening/closing procedure is inte rrupted, it can only be continued by first turning the mechanical
key to the interrupting position (2) and then again to the opening/ closing position (1 or 3) and hold.

ProCarManuals.com

Sliding/Pop-Up Roof (optional)





1. to slide roof open
2. to slide roof closed
3. to raise roof at rear
4. to lower roof at rear

Turn electronic key in steering lock to position 1 or 2. The switch is illuminated when the exterior lamps are
switched on (except standing lamps). With the roof clos ed or tilted open, a screen can be slid into the roof
opening to guard against sun rays. When sliding the roof open, the screen will also retract.


Warning !

When closing the sliding/ pop-up roof, be sure that there is no danger of anyone being harmed by
the closing procedure.


Notes:
The sliding/pop-up roof can be opened or closed manually should an electrical malfunction occur, refer to
Emergency Operation in Index. The sliding/pop-up roof can also be closed with the mechanical key or
infrared remote control while locking the vehicle door s or trunk (see Central Locking System in Index).


ProCarManuals.com

Cleaning and Care of the Vehicle

Warning !
Many cleaning products can be hazardous. Some are poisonous, others are flammable.
Always follow the instructions on the particular container. Always open your car's doors or
windows when cleaning the inside. Never use fluids or solvents that are not designed for
cleaning your car.

In operation, your vehicle is subjected to varying external influences which, if gone unchecked, can
attack the paintwork as well as the underbody and cause lasting damage.
Such damage is caused not only by extreme and varying climatic conditions, but also by air
pollution, road salt, tar, gravel and stone chipping. Grease and oil, fuel, coolant, brake fluid, bird
droppings, insects, tree resins etc. should be removed immediately to avoid paint damage. Frequent
washing reduces and/or eliminates the aggr essiveness and potency of the above adverse
influences.
More frequent washings are necessary to deal with unfavorable conditions; for example, near the
ocean, in industrial areas (smoke, exhaust emissions), or during winter operation.
You should check your vehicle from time to time for stone chipping or other damage. Any damage
should be repaired as soon as possible to prevent the start of corrosion. In doing so, do not neglect
the underside of the car. A prerequisite for a t horough check is a washing of the underbody followed
by a thorough inspection. Damage d areas need to be reundercoated.
Your vehicle has been treated at the factory with a wax-base rustproofing in the body cavities which
will last for the lifetime of t he vehicle. Post-production treatment is neither necessary nor
recommended by Mercedes-Be nz because of the possibility of incompatibility between materials
used in the production proc ess and others applied later.
We have selected car care products and compiled recommendations which are specially matched to
our vehicles and which always reflect the late st technology. You can obtain Mercedes- Benz
approved car care products at your authorized Mercedes-Benz dealer.
Scratches, corrosive deposits, corrosion or damage due to negligent or incorrect care cannot always
be removed or repaired with the car care products recommended here. In such cases it is best to
seek aid at your authorized Mercedes-Benz dealer. The following topics deal with the cleaning and
care of your vehicle and give important "how-to" in formation as well as references to Mercedes-Benz
approved car care products. Additional information can be found in the booklet titled "Car Care".


Engine Cleaning
Prior to cleaning the engine compartment make sure to protect electrical components and
connectors from the intrusion of water and cleaning agents.
Corrosion protection, such as MB Anticorrosion Wax should be applied to the engine compartment
after every engine cleaning. Before applying, all control linkage bushings and joints should be
lubricated. The poly-V-belt and all pulleys should be protected from any wax.


Car Washing
Do not use hot water or wash your car in direct sunlight. Use only a mild car wash detergent, such
as Mercedes-Benz approved Car Shampoo.
Thoroughly spray the car with a diffused jet of wa ter. Direct only a very weak spray towards the
ventilation intake. Use plenty of water an d rinse the sponge and chamois frequently.
Rinse with clear water and thoroughly wipe dry with a chamois. Do not allow cleaning agents to dry
on the finish. If the vehicle has been run through an automatic car wash - in particular one of the
older installations - rewipe the recessed sections in the taillamps (designed to prevent soiling) if
necessary. No solvents (fuels, thi nners etc.) must be used. In the winter, thoroughly remove all
traces of road salt as soon as possible.
When washing the underbody, do not forget to clean the inner sides of the wheels.


Tar Stains
Quickly remove tar stains before they dry and beco me more difficult to remove. A tar remover is
recommended.


Window Cleaning
Use a window cleaning solution on all glass surfac es. An automotive glass cleaner is recommended.


ProCarManuals.com

Rear Seat Cushion

Removal:
Push in locking tabs (on left and right side of seat) and pull up seat at the front. Installation: Slide rear edge of
cushion under the backrest. Push front of cushion down until it locks in place.

Caution!
Watch out for sharp edges when removing or installing the rear seat cushion, and make sure that it is securely
locked in place again, to prevent personal injury.




Emergency Operation of Sliding/Pop-Up Roof

The sliding/pop-up roof can be opened or closed manually should an electrical malfunction occur.
The sliding/pop-up roof drive is located behind the le ns of the left interior lamp between the sun visors.
1. Pry off lens (1) by using a screw driver.
2. Obtain crank (2) (supplied with vehicle) and insert it through hole.

To slide the roof closed or to raise the roof at the rear: turn crank clockwise.
To slide the roof open or to lower the roof at the rear: turn crank counterclockwise.


ProCarManuals.com

Manual Release of Fuel Filler Flap

The manual release knob is located behind the right side trunk panel and felt pad.
In case the central locking system does not release the fuel filler flap, pull the manual
release knob while simultaneously opening the fuel filler flap.


Roof Rack






Use only those roof racks appr oved by Mercedes-Benz to avoid damage to the vehicle.
Follow manufacturer's installation instructions.
Mount supports only between markings on border of roof which
are visible when doors are opened.
