1999 LEXUS SC300 engine

STARTING AND DRIVING
235
To use the braking power of the engine, downshift the
transmission in the way described below:
1
Shift into the º3º position. The transmission will
downshift to the third gear and engine braking will be
obtained.
When the cruise control is being used, even if you
downshift from ºDº to º3º, engine braking will not be
applied because the cruise control is not cancelled. If
you need to decrease the vehicle speed, see page 245.
2Shift into the º2º position. The transmission will
downshift to the second gear when the vehicle speed is
or becomes lower than 119 km/h (74 mph) and more
powerful engine braking will be obtained.
3Shift into the ºLº position. The transmission will
downshift to the first gear when the vehicle speed is or
becomes lower than 56 km/h (35 mph) and maximum
engine braking will be applied.
CAUTION
Be careful when downshifting on a slippery surface. The
abrupt change in engine speed could cause the vehicle to spin
or skid.

STARTING AND DRIVING
236
(c) Using the º2º and ºLº positions
The º2º and ºLº positions are used for strong engine braking
as described previously.
With the selector lever in º2º or ºLº, you can start the vehicle\
in motion as with the lever in ºDº.
With the selector lever in º2º, the vehicle will start in the first
gear and automatically shift to the second gear.
With the selector lever in ºLº, the transmission is engaged in
the first gear.NOTICE
Be careful not to overrev the engine. Watch the
tachometer to keep engine rpm from going into the red
zone. The approximate maximum allowable speed for
each position is given below for your reference:
º2º 107 km/h (67 mph) . . . .
ºLº 56 km/h (35 mph) . . . .
 Do not continue hill climbing or hard towing for a long
time in the º2º or ºLº position. This may cause severe
automatic transmission damage from overheating. To
prevent such damage, º3º position should be used in
hill climbing or hard towing.

STARTING AND DRIVING
239
(f) Good driving practice
If the transmission repeatedly upshifts and downshifts
between the fourth and overdrive gears when climbing a
gentle slope, shift the selector lever to the º3º position. Be
sure to shift the selector lever to the ºDº position after
climbing the slope.
 When towing a trailer, in order to maintain ef ficient engine
braking and electrical charging performance, do not use
overdrive. The selector lever must be in the º3º position.
CAUTION
Always keep your foot on the brake pedal while stopped with
the engine running. This prevents the vehicle from creeping.
NOTICE
Do not hold the vehicle on an upgrade with the
accelerator pedal. This can cause the transmission to
overheat. Always use the brake pedal or parking brake.
(g) Rocking your vehicle if stuck
CAUTION
If your vehicle becomes stuck in snow, mud, sand, etc., then
you may attempt to rock the vehicle free by moving it forward
and backward. Do not attempt this procedure if people or
objects are anywhere near the vehicle. During the rocking
operation the vehicle may suddenly move forward or back as
it becomes un±stuck, causing injury or damage to nearby
people or objects.

STARTING AND DRIVING
240
NOTICE
If you rock your vehicle, observe the following
precautions to prevent damage to the transmission and
other parts.
Do not depress the accelerator pedal while shifting the
selector lever or before the transmission is completely
shifted to forward or reverse gear.
 Do not race the engine and avoid spinning the wheels.
 If your vehicle remains stuck after rocking the vehicle
several times, consider other ways such as towing.
(h) If you cannot shift the selector lever
If you cannot shift the selector lever even though the brake
pedal is depressed, use the shift lock override button. For
instructions, see ºIf you cannot shift automatic transmission
selector leverº on page 306.

STARTING AND DRIVING
241
ELECTRONIC THROTTLECONTROL SYSTEM
The electronic throttle control system always maintains
appropriate engine output in relation to the accelerator
opening in all driving conditions.
The electronic throttle control system has 3 modes:
Normal, Power and Snow modes.
Normal mode: For ordinary driving, Lexus recommends
that you use the normal mode to improve fuel economy.
Power mode: For more powerful acceleration and sporty
driving.

STARTING AND DRIVING
242In the power mode, the ºECT PWRº light in the instrument
cluster is on and the transmission is shifted up at higher
vehicle speeds and shifted down more responsively than in
the normal mode.
To return to the normal mode, push the driving pattern
selector switch lightly on the ºSNOWº side.
Snow mode: For slippery road surfaces such as in snow. In
this mode, the spinning of the rear wheels is controlled
appropriately.
When you push the driving pattern selector switch on the
ºSNOWº side, the snow mode is turned on and the ºECT
SNOWº light in the instrument cluster comes on.
To return to the normal mode, push the driving pattern
selector switch on the ºSNOWº side again.
When you turn the ignition switch off in the snow mode, the
mode automatically changes to the normal mode.
CRUISE CONTROL
The cruise control allows you to cruise the vehicle at a
desired
speed over 40 km/h (25 mph) with your foot off the
accelerator pedal.
Your cruising speed can be maintained although a slight speed
change may occur when driving up or down a gradient, within
the limits of engine performance. On steeper hills, a great
speed change will occur so it is better to drive without the
cruise control.
When the cruise control is on, the driving pattern of the
automatic transmission is fixed in the normal position,
regardless of the position of the selector switch.
CAUTION
 To help maintain maximum control of your vehicle, do not
use the cruise control when driving in heavy or varying
traffic, or on slippery (rainy, icy or snow±covered) or
winding roads.
 Avoid vehicle speed increases when driving downhill. If the
vehicle speed is too fast in relation to the cruise control set
speed, cancel the cruise control then downshift the
transmission to use engine braking to slow down.

STARTING AND DRIVING
245
If the vehicle speed falls below about 40 km/h (25 mph), the
preset speed will be automatically cancelled.
If the vehicle speed drops 16 km/h (10 mph) below the preset
speed, the preset speed will also automatically be cancelled.
If the preset speed automatically cancels out for other than
these reasons, have your vehicle checked by your Lexus
dealer at the earliest opportunity.
Resetting to a faster speed
Press the control lever upward in the ºRES/ACCº direction
and hold it. Release the lever when the desired speed is
attained. While the lever is held upward, the vehicle will
gradually gain speed.
When
the difference between the actual vehicle speed and the
set speed is less than 5 km/h (3 mph), the set speed can be
increased 1.6 km/h (1 mph) each time by pressing the control
lever upward in the ºRES/ACCº direction quickly within 0.6
seconds.
However, a quicker way to reset is to accelerate the vehicle
and then press the control lever downward in the
ºSET/COASTº direction.
Resetting to a slower speed
Press the control lever downward in the ºSET/COASTº
direction and hold it. Release the lever when the desired
speed is attained. While the lever is held downward, the
vehicle speed will gradually decrease. When
the difference between the actual vehicle speed and the
set speed is less than 5 km/h (3 mph), the set speed can be
lowered 1.6 km/h (1 mph) each time by pressing the control
lever downward in the ºSET/COASTº direction quickly
within 0.6 seconds.
However, a quicker way to reset is to depress the brake pedal
and then press the control lever downward in the
ºSET/COASTº direction.
Even if you downshift the transmission from ºDº to º4º
(SC400) or from ºDº to º3º (SC300) with the cruise control
on, engine braking will not be applied because the cruise
control is not cancelled. To decrease the vehicle speed, reset
to a slower speed with the cruise control lever or depress the
brake pedal. If you use the brake pedal, cruise control is
cancelled.
Resuming the preset speed
If the preset speed is cancelled by pulling the control lever or
by depressing the brake pedal, pushing the lever up in the
ºRES/ACCº direction will restore the speed set prior to
cancellation. However, once the vehicle speed falls below
about 40 km/h (25 mph), the preset speed will not be resumed.
Cruise control failure warning
If the ºCRUISEº indicator light in the instrument cluster
flashes five times and then goes out when using the cruise
control, it means that there is trouble in the cruise control
system. Contact your Lexus dealer.

STARTING AND DRIVING
247
You can turn off the traction control system by pushing
the ºTRAC OFFº switch. The ºTRAC OFFº indicator/
warning light will then come on. Pushing the ºTRAC
OFFº switch a second time turns the system back on and
extinguishes the ºTRAC OFFº indicator/warning light.
You may hear a slight clicking noise in the engine
compartment when the engine is started. This means that the
traction control system is in the self±check mode, and does
not indicate malfunction.
When the traction control system is operating, you may feel
vibration of your vehicle, caused by operation of the brakes.
This indicates the system is functioning properly.
When getting the vehicle out of mud or new snow, etc. the
traction control system will help operate to prevent the wheels
from spinning.
