1999 Lexus LS400 key

SWITCHES
47


1For driver's window
2For front passenger's window
3For left rear window
4For right rear window
To raise or lower the windows, use the switch on
each door. The passengers' windows can also be
controlled by the switches on the driver's door.
The power windows work when the ignition key is in the
ºONº position.
Key off operation:
Even if the ignition key is turned to
the ºACCº or ºLOCKº position, the window can be
operated until any of the doors is opened (or for about 45
seconds).
12L010

SWITCHES
49
Operating the windows from outside the
vehicle
The windows can be operated using an ignition key.*
NOTE: *This feature can be set inoperative. Ask your
Lexus dealer for details.
12L043±1
Insert the ignition key into the key hole on the
driver's side.
To close the windows: Turn the key in the locking
direction and hold it.
After the door is locked, the window begins to close. To
stop in the middle, return the key.
To open the windows: Turn the key in the unlocking
direction and hold it.
After the door is unlocked, the window begins to open.
To stop in the middle, return the key.

SWITCHES
50
Jam protection function
During automatic raising operation, key off raising
operation or raising operation using the ignition key from
the outside, the window stops and is lowered if
something gets caught between the window and window
frame.
If an impact is given to the window, this function may
work without anything caught.
CAUTION
 Never try jamming any part of your body to make the
jam protection function work intentionally.
 The jam protection function may not work when
something gets caught just before the window fully
closed.
CAUTION

SWITCHES
51
To avoid serious personal injury, you must do the
following.
Always m ake sure the head, hands and other parts of
the body of all occupants are kept completely inside
the vehicle before you close the power windows. If
someone's neck, head or hands gets caught in a
closing window, it could result in a serious injury.
When anyone closes the power windows, be sure
that they operate the windows safely.
 When small children are in the vehicle, never let them
use the power window switches without supervision.
Use the window lock switch to prevent them from
making unexpected use of the switches.
 Never leave small children alone in the vehicle,
especially with the ignition key still inserted. They
could use the power window switches and get
trapped in a window. Unattended children can
become involved in serious accidents.

SWITCHES
53
To turn on the emergency flashers, push the switch.
All the turn signal lights will flash. The emergency
flashers
will work with the engine running or off and with
or without the ignition key.
Turn on the emergency flashers to warn other drivers if
you must stop your vehicle where it might be a traffic
hazard.
Always pull your vehicle as far off the road as possible.
The turn signal light switch will not work when the
emergency flashers are in operation.
NOTICE
To prevent the battery from being discharged, do not leave the switch on longer than necessarywhen the engine is not running.
SEAT HEATER SWITCHES
12L013a

SWITCHES
54The seat heater has two switches; one marked ºLº
(for the left seat) and the other marked ºRº (for the
right seat). Push these switches to turn the
respective seat heater on, and push the switches
again to turn them off.
The ignition key must be in the ºONº position.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
63
(a) If parking brake
is off, stop and
check.
(b) Fasten driver's seat belt.

(Indicator and buzzer)
(c) Fasten front passenger's
seat belt.
(Under the center vent)
(d) Take vehicle to Lexus dealer
immediately.
(e) Stop and check. (f) Take vehicle to
Lexus dealer.
(g) Take vehicle to Lexus dealer.
(h) Close all doors.
(i) Low fuel level Fill up tank. warning light
(j) Key reminder buzzer Remove key.
or
or

GAUGES, METERS AND SERVICE REMINDER INDICATORS
66If the brake fluid level is correct ...
Have
the warning system checked by your Lexus dealer.
(b) Driver's Seat Belt Reminder Light
and Buzzer
Once the ignition key is turned to ºONº or ºSTARTº, the
reminder light flashes and buzzer sounds if the driver's
seat belt is not fastened. Unless the driver fastens the
belt, the light stays flashing and the buzzer stops after
about 4 to 8 seconds.
(c) Front Passenger's Seat BeltReminder Light
Once the ignition key is turned to ºONº or ºSTARTº, the
reminder light flashes if a passenger sits in the front
passenger seat and does not fasten the seat belt.
Unless the front passenger fastens the belt, the light
stays flashing.
If luggage load is placed on the front passenger seat,
depending on its weight and how it is placed on the seat,
built±in sensors in the seat cushion may detect the
pressure, causing the reminder light to come on.
(d) SRS Warning Light
The indicators come on when the ignition key is
turned to the ºACCº or ºONº position. It goes off
after about 6 seconds. This means the SRS is
operating properly.
The SRS warning light system monitors the airbag
sensor assemblies, inflators, seat belt pretensioners,
warning light, interconnecting wiring and power sources.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the parts monitored by the
warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
 The light does not come on as described above.
 The light stays on or flashes.
 The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front
passenger airbags fail. If the light flashes, the side
airbags and/or seat belt pretensioners fail.
