MAINTENANCE
356
DOES YOUR VEHICLE NEEDREPAIRING?
Be on the alert for changes in performance and sounds,
and visual tip±offs that indicate service is needed. Some
important clues are:

Engine missing, stumbling, or pinging

Appreciable loss of power

Strange engine noises

A fluid leak under the vehicle (However, water
dripping from the air conditioning after use is normal.)

Change in exhaust sound (This may indicate a
dangerous carbon monoxide leak. Drive with the
windows open and have the exhaust system checked
immediately.)

Flat±looking tires, excessive tire squeal when
cornering, uneven tire wear

Vehicle pulls to one side when driving straight on a
level road

Strange noises related to suspension movement

Loss of brake effectiveness, spongy feeling brake
pedal, pedal almost touches floors, vehicle pulls to
one side when braking

Engine coolant temperature continually higher than
normal If you notice any of these clues, take your vehicle to your
Lexus dealer as soon as possible. It probably needs
adjustment or repair.

INTRODUCTION
365
NOTICE

Remember that battery and ignition cablescarry high currents or voltages. Be careful ofaccidentally causing a short circuit.

Before closing the engine hood, check to seethat you have not forgotten any tools, rags, etc.

Do not drive with the air cleaner removed, or
excessive engine wear could result. Alsobackfiring could cause a fire in the enginecompartment.

Do not overfill automatic transmission fluid, orthe transmission could be damaged.

Be careful not to scratch the glass surface withthe wiper frame.
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do±it±yourself maintenance. Remember all Lexus parts
are designed in metric sizes, so your tools must be
metric.
Checking the engine oil level
Parts (if level is low):

Use API grade SJ, ºEnergy±Conservingº multigrade
engine oil or ILSAC multigrade engine oil. For
recommended oil viscosity, see page 382.
Tools:

Rag or paper towel

Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):

ªToyota Long Life Coolantº or equivalent
See ºChecking the engine coolant levelº on page 383
for instructions.

Demineralized or distilled water
Tools:

Funnel (only for adding coolant)

SECTION 6 ± 2
369
SERVICE PROCEDURES AND
SPECIFICATIONS
Engine
Specifications370
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 373
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Facts about engine oil consumption 375
. . . . . . . . . . . . .
Used engine oil 377
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the engine oil level 378
. . . . . . . . . . . . . . . . . . .
Checking the engine coolant level 383
. . . . . . . . . . . . . . .
Spark plugs 387
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ENGINE
372± IGNITION SYSTEM
Spark plug ± Make DENSO NGK
± Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
± ELECTRICAL SYSTEM
Battery ± Maintenance type battery Specific gravity reading at 20 C (68F):
Charging rates Quick charge Slow charge
± Non±maintenance battery Open voltage at 20C (68F):
Charging rates
1.260 Fully charged
1.160 Half charged
1.060 Discharged
15A max.
5A max.
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the key is
removed with all the lights turned off]
5A max.

ENGINE
376The amount of engine oil consumed depends on the
viscosity of the oil, the quality of the oil and the way
the vehicle is driven.
More oil is consumed under driving conditions such as
high speeds and frequent acceleration and
deceleration.
A new engine consumes more oil, since its pistons,
piston rings and cylinder walls have not become
conditioned.
When judging the amount of oil consumption, keep
in mind that the oil may have become diluted,
making it difficult to judge the true level accurately.
For example, if a vehicle is used for repeated short trips
and consumes a normal amount of oil, the dipstick may
not show any drop in the oil level at all, even after 1000
km (600 miles) or more. This is because the oil is
gradually
becoming diluted with fuel or moisture, making
it appear that the oil level has not changed.
The diluting ingredients evaporate out when the vehicle
is then driven at high speeds, as on an expressway,
making it appear that oil is excessively consumed after
driving at high speeds.
Importance of engine oil level check
One of the most important points in proper vehicle
maintenance is to keep the engine oil at the optimum
level so that oil function will not be impaired. Therefore,
it is essential that the oil level be checked regularly.
Lexus recommends that the oil level be checked every
time you refuel the vehicle.
NOTICE
Failure to check the oil level regularly could lead to serious engine trouble due to insufficient oil.
For detailed information on oil level check, see
ºChecking the engine oil levelº on page 378.

ENGINE
378
CHECKING THE ENGINE OILLEVEL
62E001a
With the engine at operating temperature and turned
off, check the oil level on the dipstick.
1. To get a true reading, the vehicle should be on a level
spot. After turning off the engine, wait a few minutes for
the oil to drain back into the bottom of the engine.
2. Pull out the dipstick, and wipe it clean with a rag.
3. Reinsert the dipstick and push it in as far as it will go,
or the reading will not be correct.

ENGINE
381
If the oil level is below or only slightly above the low
line,
add engine oil of the same type as already in the
engine.
Remove the oil filler cap and add engine oil a little at a
time, checking the dipstick. The approximate quantity of
oil needed to fill between the low line and the full line on
the dipstick is indicated below for reference.
When the level reaches within the correct range, return
the filler cap and turn the cap clockwise until you hear a
click.
Oil quantity. L (qt., lmp. qt.) 1.5 (1.6, 1.3)
NOTICE
Avoid overfilling, or the engine could be
damaged. C heck the oil level on the dipstick once
again after adding the oil.

ENGINE
383
Oil identification marks
62L006±1

API Service Symbol
ILSAC Certification
Mark
Either or both API registered marks are added to some
oil containers to help you select the oil you should use.
 The API Service Symbol is located anywhere on the
outside of the container.
The top portion of the label shows the oil quality by
API (American Petroleum Institute) designation such
as SJ. The center portion of the label shows the SAE
viscosity grade such as SAE 5W±30.
ºEnergy±Conservingº, shown in the lower portion,
indicates that the oil has fuel±saving capabilities.
 The ILSAC (International Lubricant Standardization
and Approval Committee) Certification Mark is
displayed on the front of the container.
CHECKING THE ENGINE
COOLANT LEVEL
