1999 LAND ROVER DISCOVERY service

GENERAL INFORMATION
03-22
Rotary coupler
Always follow the Repair procedure for fitting the
rotary coupler.
Comply with all safety and installation procedures to
ensure the system functions correctly. Observe the
following precautions:
lDo not install a rotary coupler if it is suspected to
be defective.
lDo not attempt to service, modify or repair a
rotary coupler.
lDo not cut, splice or modify the wires attached
to yellow SRS connector and lead.
lAlways ensure the rotary coupler connectors
are mated correctly and securely fastened.
lAlways ensure the battery is disconnected
before working on the rotary coupler.
lAlways ensure the rotary coupler is removed
and installed in its centered position and with the
front road wheels in the straight ahead position.
lIf a new rotary coupler is being installed, ensure
the locking tab holding the coupler's rotational
position is not broken; units with a broken
locking tab should not be used.
Warning labels
Warning symbols are displayed at various positions
in the vehicle (either in a suitable prominent position
such as driver and passenger side glass, or attached
to the component itself) to indicate SRS items which
must be treated with particular care. Exact positions
of SRS warning labels may vary dependent on
legislation and market trends.
WARNING: It is imperative that before any work
is undertaken on the SRS system the appropriate
information is read thoroughly.Side window label
aThe need for caution when working in close
proximity to SRS components.
bRefer to the publication where the procedures,
instructions and advice can be found (usually
the Workshop Manual) for working on the SRS
system.
cDo not use rear facing child seats in the front
passenger seat if the vehicle is fitted with a
passenger airbag.
Rotary coupler label
aRefer to the Workshop Manual for detailed
instructions
bEnsure wheels are in the straight ahead
position before removal and refitting
cPart number/Bar code. The code must be
recorded and quoted for ordering purposes

GENERAL INFORMATION
03-24
Air Conditioning System Precautions
General
The air conditioning system contains fluids and
components which could be potentially hazardous to
the service engineer or the environment if not
serviced and handled correctly. The following
guidelines are intended to alert the service engineer
to potential sources of danger and emphasise the
importance of ensuring the integrity of the Air
Conditioning operating conditions and components
fitted to the vehicle.
Where necessary, additional specific precautions are
detailed in the relevant sections of this Manual which
should be referred to prior to commencing repair
operations.
The refrigerant used in the air conditioning system is
HFC-134a (Hydrofluorocarbon) R134a.
WARNING: Servicing must only be carried out by
personnel familiar with both the vehicle system
and the charging and testing equipment. All
operations must be carried out in a well
ventilated area away from open flame and heat
sources.
WARNING: R134a is a hazardous liquid and when
handled incorrectly can cause serious injury.
Suitable protective clothing, consisting of face
protection, heat proof gloves, rubber boots and
rubber apron or waterproof overalls, must be
worn when carrying out operations on the air
conditioning system.Remedial actions
If an accident involving R134a should occur, conduct
the following remedial actions:
lIf liquid R134a enters the eye, do not rub it.
Gently run large quantities of eye wash over
affected eye to raise the temperature. If an eye
wash is not available, cool, clean water may be
used to flush the eye. After rinsing, cover the
eye with a clean pad and seek immediate
medical attention.
lIf liquid R134a is splashed onto the skin, run
large quantities of water over the affected area
to raise the temperature. Implement the same
action if the skin comes in contact with
discharging cylinders. Wrap the contaminated
body parts in blankets (or similar materials) and
seek immediate medical attention.
lIf the debilitating effects of inhalation of R134a
vapour is suspected, seek fresh air. If the
affected person is unconscious, move them
away from the contaminated area to fresh air
and apply artificial respiration and/or oxygen
and seek immediate medical attention.
WARNING: Due to its low evaporating
temperature, R134a must be handled with care.
R134a splashed on any part of the body will
cause immediate freezing of that area. Also,
refrigerant cylinders and replenishment trolleys
when discharging will freeze skin to them if
contact is made.

GENERAL INFORMATION
03-25
Service precautions
Observe the following precautions when handling
components used in the air conditioning system:
lAir conditioning units must not be lifted by their
hoses, pipes or capillary lines.
lHoses and lines must not be subjected to any
twist or stress; the efficiency of the system will
be impaired by kinks or restrictions. Ensure that
hoses are correctly positioned before tightening
couplings, and ensure that all clips and supports
are utilised.
lFlexible hoses should not be positioned close to
the exhaust manifold (less than 100mm) unless
protected by heat shielding.
lCompleted assemblies must be checked for
refrigeration lines touching metal panels. Any
direct contact of components and panels may
transmit noise and so must be eliminated.
lThe appropriate torque wrench must be used
when tightening refrigerant connections to the
stipulated value. An additional spanner must be
used to hold the union to prevent twisting of the
pipe when tightening connections.
lBefore connecting any hose or pipe, ensure that
refrigerant oil is applied to the seat of the new 'O'
rings, BUT NOT to the threads of the
connection.
lAll protective plugs must remain in place to seal
the component until immediately prior to
connection.
lEnsure components are at room temperature
before uncapping, to prevent condensation of
moisture from the air that enters it.
lComponents must not remain uncapped for
longer than 15 minutes. In the event of a delay,
the caps must be fitted.
lWhen disconnecting, immediately cap all air
conditioning pipes to prevent ingress of dirt and
moisture into the system.
lThe receiver/drier contains desiccant which
absorbs moisture. It must be positively sealed at
all times. A receiver/drier that has been left
uncapped must not be used, fit a new unit.
lThe receiver/drier should be the last component
connected to the system to ensure optimum
dehydration and maximum moisture protection
of the system.
lWhenever the refrigerant system is opened, the
receiver/drier must be renewed immediately
before evacuating and recharging the system.
lUse alcohol and a clean lint-free cloth to clean
dirty connections.
lEnsure that all new parts fitted are marked for
use with R134a.
When a major repair has been completed, a leak test
should be conducted; refer to the Air Conditioning
section of this manual for the correct procedure.Refrigerant oil
Refrigerant oil easily absorbs water and must not
be stored for long periods. Do not pour unused
refrigerant oil back into the container. Always
use an approved refrigerant oil.

+ CAPACITIES, FLUIDS, LUBRICANTS
AND SEALANTS, Lubrication.
When replacing components in the A/C system,
drain the refrigerant oil from the component being
replaced into a graduated container. On assembly,
add the quantity of refrigerant oil drained to the new
component.
Compressor
A new compressor is sealed and pressurised with
Nitrogen gas. When fitting a new compressor, slowly
release the sealing cap; gas pressure should be
heard to vent as the seal is broken.
CAUTION: A new compressor should always be
sealed and could be pressurised with nitrogen
gas. To avoid possible oil loss, release the
sealing cap(s) slowly. Do not remove the cap(s)
until immediately prior to connecting the air
conditioning pipes to the compressor.
Rapid refrigerant discharge
If the air conditioning system is involved in accident
damage and the system is punctured, the refrigerant
will discharge rapidly. The rapid discharge of
refrigerant will also result in the loss of most of the oil
from the system. The compressor must be removed
and all the remaining oil in the compressor drained
and refilled as instructed in the air conditioning
section of this manual.

GENERAL DATA
04-11
Clutch - Td5
Type Diaphragm spring, hydraulically operated with self-centering,
preloaded release bearing
Drive plate diameter 267 mm (10.5118 in)
Pressure plate diameter 267 mm (10.5118 in)
Clutch plate friction material Verto F202
Diaphragm finger height when clamped on a 8.5 mm
(0.33 in) thick gauge plate42.5 to 48.5 mm (1.673 to 1.904 in)
Diaphragm finger clearance (service limit) 1.00 mm (0.040 in)
Clutch plate thickness under 6500 N (1461 lb) axial
load:
⇒ New 8.2 to 8.8 mm (0.33 to 0.34 in)
⇒ Service limit 7.0 mm (0.27 in)

GENERAL DATA
04-12
Clutch - V8
Type Diaphragm spring, hydraulically operated with self-centering,
preloaded release bearing
Clutch plate friction material APTEC 385
Drive plate diameter 267 mm (10.5118 in)
Pressure plate diameter 268 mm (10.5512 in)
Clutch plate thickness (clamped state)
⇒ New 8.4-8.9 mm (0.33-0.35 in)
⇒ Service limit 7.1 mm (0.28 in)
Rivet depth:
⇒ New 1.73 mm (0.07 in)
⇒ Service limit 0.25 mm (0.01 in)
Clutch plate runout:
⇒ New 0.5 mm (0.02 in)
⇒ Service limit 0.5 mm (0.02 in)

GENERAL DATA
04-13
Manual gearbox - R380
Type Single helical constant mesh
Gears 5 forward, 1 reverse, all synchromesh
Gear ratios: Td5 Diesel
⇒ First 3.692 : 1
⇒ Second 2.132 : 1
⇒ Third 1.397 : 1
⇒ Fourth 1.0 : 1
⇒ Fifth 0.770 : 1
⇒ Reverse 3.536 : 1
Gear ratios: V8 Petrol
⇒ First 3.321:1
⇒ Second 2.132:1
⇒ Third 1.397:1
⇒ Fourth 1.0:1
⇒ Fifth 0.732:1
⇒ Reverse 3.536:1
Baulk ring clearance:
⇒ New 0.500 mm (0.0197 in)
⇒ Service limit 0.500 mm (0.0197 in)
⇒ Selector fork pad widths - minimum 6.5 mm (0.255 in)
First gear end float:
⇒ New 0.050 - 0.200 mm (0.0020 - 0.0079 in)
⇒ Service limit 0.327 mm (0.0129 in)
Second gear end float:
⇒ New 0.040 - 0.210 mm (0.0016 - 0.0083 in)
⇒ Service limit 0.337 mm (0.0133 in)
Third gear end float:
⇒ New 0.110 - 0.210 mm (0.0043 - 0.0083 in)
⇒ Service limit 0.337 mm (0.0133 in)
Adjust fifth / reverse hub - shim to
⇒ New 0.005 - 0.055 mm (0.0002 - 0.0022 in)
⇒ Service limit 0.055 mm (0.0022 in)
Reverse gear idler shaft clearance
⇒ New 0.040 - 0.380 mm (0.0016 - 0.0150 in)
⇒ Service limit 0.380 mm (0.0150 in)
Mainshaft end float:
⇒ New 0.000 - 0.050 mm (0.0000 - 0.0020 in)
⇒ Service limit 0.000 - 0.050 mm (0.0000 - 0.0020 in)
Layshaft end float:
⇒ New 0.000 - 0.050 mm (0.0000 - 0.0020 in)
⇒ Service limit 0.000 - 0.050 mm (0.0000 - 0.0020 in)

GENERAL DATA
04-19
Brakes
Type Servo assisted, diagonally split hydraulic on outboard discs, with four
channel electronic control ABS
Disc diameter:
⇒ Front 297.0 - 297.4 mm (11.693 - 11.709 in)
⇒ Rear 303.8 - 304.2 mm (11.961 - 11.976 in)
Front disc minimum thickness:
⇒ New 24.9 - 25.1 mm (0.980 – 0.988 in)
⇒ Service limit 22.0 mm (0.866 in)
Rear disc minimum thickness:
⇒ New 12.5 – 12.7 mm (0.492 – 0.500 in)
⇒ Service limit 11.7 mm (0.461 in)
Maximum disc runout 0.15 mm (0.006 in)
Minimum pad material thickness 2.0 mm (0.079 in)
Handbrake Cable operated drum on transfer box rear output shaft

CAPACITIES, FLUIDS, LUBRICANTS AND SEALANTS
09-2
Fluids
Anti-freeze
Use Havoline Extended Life Coolant (XLC), or any
ethylene glycol based anti-freeze (containing no
methanol) with only Organic Acid Technology (OAT)
corrosion inhibitors, to protect the cooling system
CAUTION: No other anti-freeze should be used
with Havoline Extended Life Coolant.
The cooling system should be drained, flushed and
refilled with the correct amount of anti-freeze solution
at the intervals given on the Service Maintenance
Check Sheet.
After filling with anti-freeze solution, attach a warning
label to a prominent position on the vehicle stating
the type of anti-freeze contained in the cooling
system to ensure that the correct type is used for
topping-up.
Brake/Clutch fluid
Use only DOT 4 brake fluid.
PAS fluid
Use Texaco cold climate power assisted steering
fluid PSF 14315.
ACE fluid
Where ambient temperature falls below -20° C (-4°
F), use only Texaco cold climate power assisted
steering fluid PSF 14315. Where ambient
temperature remains above -20° C (-4° F), use either
Texaco cold climate power assisted steering fluid ,
Dexron 11 or Dexron 111 non-synthetic fluid.
Air conditioning
Use only refrigerant R134a.
Refrigerant oil
Use only Nippon Denso ND-oil 8.
Refrigerant oil absorbs water and must not be stored
for long periods. Do not pour unused oil back into the
container.
NOTE: The total quantity of refrigerant oil in the
system is 180 ml.
CAUTION: Do not use any other type of
refrigerant oil.
Anti-Freeze Concentration
The overall anti-freeze concentration should not fall,
by volume, below 50% to ensure that the anti-
corrosion properties of the coolant are maintained.
Anti-freeze concentrations greater than 60% are not
recommended as cooling efficiency will be impaired.
The following recommended quantities of anti-freeze
will provide frost protection to -48°C (-53°F):
Engine - TD5
Engine - V8
Concentration 50%
Amount of Anti-freeze 4 litres
Concentration 50%
Amount of Anti-freeze 6.5 litres
13.5 pts (US)
