Page 9 of 14
PERFORMANCE
0-100 km/h (0-60 mph)6.2 seconds
400 meters (quarter mile)14.63 seconds @ 156.7 km/h
(97.4 mph)
Top speed225 km/h (140 mph)
Braking, 100-0 km/h (60-0 mph)41.8 meters (137 ft.)
183 meter slalom (600 ft.)102.4 km/h (63.6 mph)
61 meter skid pad (200 ft.)0.85 g
Performance
9
Page 10 of 14
OPTIONS, COLOR AND TRIM
²Tonneau cover
²6±disc CD player
²Trailer tow package
Exterior:
²Black Clearcoat
²Oxford White
²Bright Red Clearcoat
Interior:
²Medium Graphite Leather/Cloth
Options, color and trim
10
Page 11 of 14
MOTORCRAFT PART NUMBERS
Component 5.4L Supercharged V8 engine
Air filter element FA-1634
Fuel filter FG-986B
Battery BXT-65-650
Oil filter FL-820S
PCV valve EV-233
Spark plugs
1AGSF-12E or AGSF-12FM12
1
Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
2If a spark plug is removed for inspection, it must be reinstalled in the
same cylinder. Use only AGSF-12FM1 spark plugs for replacement.
Maintenance
11
Page 12 of 14
REFILL CAPACITIES
Fluid Ford Part Name Capacity
Brake fluid High Performance
DOT 3 Motor Vehicle
Brake FluidFill to line on reservoir
Engine oil (includes
filter change)Motorcraft 5W-30
Super Premium Motor
Oil5.7L (6.0 quarts)
Engine coolant
1Premium Engine
Coolant24.1L (25.5 quarts)
Intercooler coolant
1Premium Engine
Coolant4.0L (4.2 quarts)
Power steering fluid Motorcraft MERCONt
AT FFill to line on reservoir
Rear axle lubricant
2Motorcraft SAE 80W90
Premium Rear Axle
Lubricant3.3-3.8L
(7.5-8.0 pints)
Fuel tank N/A 94.6L (25.0 gallons)
Transmission fluid
3Motorcraft MERCONt
AT F15.0L (15.9 pints)
Windshield washer
fluidUltra-Clear Windshield
Washer Concentrate4.0L (4.25 quarts)
1Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford
Extended Life Engine Coolant (orange in color).
2Fill 6 mm to 14 mm (1/4 inch to 9/16 inch) below bottom of fill hole.
Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546-A, Ford
specification EST-M2C118±A for complete refill of Traction-Lok axles.
Your vehicle's rear axle is filled with a synthetic rear axle lubricant and is
considered lubricated for life. These lubricants do not need to be
checked or changed unless a leak is suspected, service is required or the
axle assembly has been submerged in water. The axle lubricant should
be changed any time the rear axle has been submerged in water.
3Ensure the correct automatic transmission fluid is used. Transmission
fluid requirements are indicated on the dipstick or on the dipstick
handle. MERCONtand MERCONtV are not interchangeable. DO NOT
mix MERCONtand MERCONtV. Refer to your Scheduled Maintenance
Guide to determine the correct service interval.
Maintenance
12
Page 13 of 14
OCTANE RECOMMENDATIONS
Your vehicle is designed to use
ªPremiumº unleaded gasoline with
an (R+M)/2 octane rating of 91 or
higher for optimum performance.
The use of gasolines with lower
octane ratings may degrade performance. We do not recommend the use
of gasolines labeled as ªPremiumº in high altitude areas that are sold
with octane ratings of less than 91.
If your engine knocks under any driving conditions while you are using
fuel with the recommended octane rating, see your dealer or a qualified
service technician to prevent any engine damage.
WHEELS AND TIRES
Tires295/45 ZR 18 BSW tires
WheelsSVT-Signature style, 18 in x 9.5 in aluminum 5-spoke wheels
TIRE ROTATION
²Unidirectional tire rotation
For vehicles equipped with
unidirectional tires and full-size
spare, your vehicle can be driven
with the unidirectional full-size
spare, rotating counter to the
directional arrow on the tire
sidewall.
Your unidirectional full-size spare
tire is rotated for wear balance. Best
performance may be achieved by
remounting the tire to the wheel, if
necessary, to permit tire rotation
with the directional arrow on the
tire sidewall.
SPARE TIRE AND WHEEL
Your vehicle is equipped a 235/70R-16 spare tire on a steel wheel rim.
This is for temporary use only. Replace this spare tire with a repaired
road tire as soon as possible.
91(R+M)/2 METHOD
Maintenance
13
Page 14 of 14
A WORD ABOUT WARRANTY COVERAGE
The F±150 Lightning carries the same warranty coverage as other Ford
F-150 models. This information is covered in its entirety in the Ford
Motor Company Warranty Guide.
The F±150 Lightning or any SVT can be serviced under warranty at any
Ford-Lincoln-Mercury dealer nationwide.
SVT does not recommend modifying or racing our vehicles, as they are
designed and built to be driven as delivered from the factory. The Ford
Motor Company Warranty Guide discusses the installation of aftermarket
parts and their effect on warranty coverage as follows:
Repairs are not reimbursable under warranty when:
²ªThe repairs are required because of abuse, misuse, racing, fire,
negligence, accident, modification or a natural disaster.º
²ªThe repairs are required due to installation of a non-Ford part.º
A word about warranty coverage
14
