Box (DRB) scan tool with appropriate cartridge for system
diagnosis. Other after-market scan tools may be used for
system diagnosis. The following procedure is for DRB scan
tool usage. Use scan tool manufacturer's instruction for
operating scan tool.
NOTE: Ensure battery is fully charged before proceeding with test.
1) Ensure ignition is off. Connect DRB to Data Link Connector
(DLC) located under driver's side of instrument panel. Using scan
tool, display all Diagnostic Trouble Codes (DTCs). Identify DTCs once
retrieved. See DIAGNOSTIC TROUBLE CODES (DTC) & DRB MESSAGES table.
2) If scan tool will not power up, check for loose cable
connections or faulty cable. If cable connections and cable are okay,
check voltage at DLC terminal No. 16. Voltage should be at least 11
volts. If voltage is not as specified, check wiring circuit and
necessary fuses. See WIRING DIAGRAMS.
3) If scan tool displays an error message, RAM TEST FAILURE,
CARTRIDGE ERROR, KEY PAD TEST FAILURE, or LOW OR HIGH BATTERY, this
indicates a scan tool failure.
4) If DTCs are displayed, perform appropriate test(s). See
DIAGNOSTIC TROUBLE CODES (DTC) & DRB MESSAGES table. If no DTCs are
displayed, see TROUBLE SHOOTING in appropriate AUTOMATIC TRANSMISSION
OVERHAUL article.
DIAGNOSTIC TROUBLE CODES (DTC) & DRB MESSAGES









\









\









\









\









\









\









\







DTC DRB-III Scan Tool Message
P0711 .................. TRANS TEMP SENSOR, NO TEMP RISE AFTER START
P0712 ............................. TRANS TEMP SENSOR VOLTAGE TO LOW
P0713 ............................ TRANS TEMP SENSOR VOLTAGE TO HIGH
P0720 ..................... LOW OUTPUT SPEED SENSOR RPM ABOVE 15 MPH
P0740 .................... TORQ CONVERTER CLU, NO RPM DROP AT LOCKUP
P0743 ........ TORQUE CONVERTER CLUTCH SOLENOID/TRANS RELAY CIRCUITS
P0748 ........... GOVERNOR PRESSURE SOL CONTROL/TRANS RELAY CIRCUITS
P0751 ....................... OD SWITCH PRESSED (LO) MORE THAN 5 MIN\
P0753 ................ TRANS 3-4 SHIFT SOLENOID/TRANS RELAY CIRCUITS
P0783 ....................... 3-4 SHIFT SOL, NO RPM DROP @ 3-4 SHIFT
P1740 (1) .......................... TCC OR O/D SOLENOID PERFORMANCE
P1756 .................... GOV PRESS NOT EQUAL TO TARGET @ 15-20 PSI
P1757 ...................... GOV PRES ABOVE 3 PSI IN GEAR WITH 0 MPH
P1762 .................... GOV PRESS SEN OFFSET VOLTS TO LOW OR HIGH
P1763 ....................... GOVERNOR PRESSURE SENSOR VOLTS TO HIGH
P1763B ...................... GOVERNOR PRESSURE SENSOR VOLTS TO HIGH
P1764 ........................ GOVERNOR PRESSURE SENSOR VOLTS TO LOW
P1765 ..................... TRANS 12 VOLT SUPPLY RELAY CNTRL CIRCUIT
P1899 .......................... P/N SWITCH STUCK IN PARK OR ON GEAR
( 1) - BR body only.









\









\









\









\









\









\









\







CLEARING DIAGNOSTIC TROUBLE CODES
After repairs have been performed, clear DTCs from PCM memory
using scan tool, following scan tool manufacturer's instructions.
NOTE: If malfunction is no longer present after DTC is stored in
PCM memory, the PCM will erase DTC after ignition has been
cycled at least 50 times. DTC may be cleared by using scan
tool. Follow scan tool manufacturer's instructions. DTCs may
also be cleared by disconnecting negative battery cable for a
period of time, but other vehicle control modules may also be

made.
* When using a jumper wire, ensure either jumper wire or
circuit is fuse-protected.
* Before disconnecting connector from any control module,
ensure ignition is off before removing connector.
* When checking voltage or continuity at any control module,
probe connector for control module from pin side. DO NOT
backprobe connector or probe wires through insulation.
* DO NOT cause short circuits when performing electrical tests.
This will set additional Diagnostic Trouble Codes (DTCs),
making diagnosis of original problem more difficult.
* Use specified test equipment when performing electrical
tests.
RETRIEVING DIAGNOSTIC TROUBLE CODES
NOTE: Self-diagnostic tests are written specifically for Chrysler's
Diagnostic Readout Box (DRB). If using a generic scan tool,
ensure it is OBD-II certified. A generic scan tool may not be
capable of performing all necessary test functions.
Ensure battery is fully charged. Turn ignition off. Connect
scan tool to Data Link Connector (DLC). DLC is located under left side\
of instrument panel. Turn ignition on. Using scan tool manufacturer's
instructions, record all DTCs displayed on scan tool. If ant DTCs are
retrieved, perform appropriate test under DIAGNOSTIC TESTS. Once all
repairs are made, clear DTCs. See CLEARING DIAGNOSTIC TROUBLE CODES.
If no DTCs are retrieved and fault still exists, go to CHECKING SPEED
CONTROL OPERATION under SYSTEM TESTS.
CLEARING DIAGNOSTIC TROUBLE CODES
Ensure ignition is off. Connect scan tool to DLC. Turn
ignition on. Using screen prompts on scan tool, erase DTCs from PCM.
DIAGNOSTIC TESTS
FTC P0720: LOW OUTPUT SPEED SENSOR (OSS) RPM MORE THAN 15 MPH
FTC P0720 will set if output shaft speed is less than 60 RPM
for 2.6 seconds when vehicle speed is more than 15 MPH.
Possible Causes:
* Defective Output Speed Sensor (OSS).
* OSS signal circuit open or shorted.
* OSS ground circuit open or shorted.
* Park/Neutral Position (PNP) switch FTC present.
* Defective PNP switch.
* Defective PCM.
1) Turn ignition on. Using scan tool, read DTCs. If FTC
specific good trip is displayed and equal to zero, go to next step. If
FTC specific good trip is equal to more than zero, go to step 13).
2) If there are any Park/Neutral Position (PNP) switch DTCs,\
repair PNP switch FTC first. Perform TEST VER-5A under VERIFICATION
TESTS. If there are no PNP switch DTCs, go to next step.
3) Using scan tool, read PNP switch state. While observing
scan tool, shift transmission through all positions. If scan tool did
not display P/N and D/R in correct positions, repair PNP switch or
circuit as necessary. Perform TEST VER-5A under VERIFICATION TESTS. If


* E LE C TR IC AL S YSTE M U NIF O RM IN SPEC TIO N G UID ELIN ES *

1 999 D odge P ic ku p R 1500
GENERAL INFORMATION
Electrical System Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
ACTUATOR MOTORS (SOLENOIDS) (ELECTRIC)
ACTUATOR MOTORS (VACUUM)
AIR BAGS
ALTERNATORS AND GENERATORS
AMPLIFIERS
ANTENNAS
BATTERIES
BATTERY CABLES
BATTERY CABLES
BATTERY HOLD DOWN HARDWARE
BATTERY TRAYS AND HOLD DOWN HARDWARE
BATTERY WIRES
BELTS
BULB SOCKETS
BULBS, SEALED BEAMS AND LEDS
CD PLAYERS
CIGARETTE LIGHTER ASSEMBLIES
CIRCUIT BREAKERS
CLUTCH SWITCHES
CONNECTORS
CONTROL MODULES
CRUISE CONTROL BRAKE SWITCHES
CRUISE CONTROL CABLES
CRUISE CONTROL CLUTCH SWITCHES
CRUISE CONTROL LINKAGES AND CABLES
CRUISE CONTROL RESERVOIRS
CRUISE CONTROL TUBES
CRUISE CONTROL VACUUM DUMP RELEASE VALVES
CRUISE CONTROL VACUUM HOSES, TUBES AND RESERVOIRS
CRUISE CONTROL VEHICLE SPEED SENSORS
DEFOGGERS
DEFROSTERS
DELAYS
DIMMERS
ELECTRIC HEATERS
EQUALIZERS
FUSE BLOCKS
FUSE BOXES AND BLOCKS
FUSES, FUSIBLE LINKS AND CIRCUIT BREAKERS
FUSIBLE LINKS
GAUGES
GENERATORS
GROUND CABLES AND STRAPS
GROUND STRAPS
HEADLIGHT ADJUSTERS
HEATING ELEMENTS (DEFROSTERS, DEFOGGERS, ELECTRIC HEATERS AND SEATS)
HORNS AND SIRENS

Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
(1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Inoperative includes intermittent operation or out of OEM
specification.









\









\









\









\









\









\









\


ELECTRIC HEATERS
See
HEATING ELEMENTS (DEFROSTERS, DEFOGGERS, ELECTRIC HEATERS AND SEATS) .
EQUALIZERS
See
RECEIVERS, AMPLIFIERS, EQUALIZERS AND SUB-WOOFER VOLUME CONTROLS .
FUSE BLOCKS
See FUSE BOXES AND BLOCKS .
FUSE BOXES AND BLOCKS
FUSE BOX AND BLOCK INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Broken, affecting
performance ............ A ............ Require replacement.
Broken, not affecting
performance ............ .. ........ No service suggested or
required.
Burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Burned, not affecting
performance ............ 2 ........... ( 1) Suggest repair or
replacement.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... ( 1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Cover missing ........... C ... Require replacement of cover.
Cracked, affecting
performance ............ A .. Require repair or replacement.
Cracked, not affecting
performance ............ 1 .. Suggest repair or replacement.
Melted, affecting
performance ............ A ........ ( 1) Require replacement.


SEA TS - P O W ER

1999 D odge P ic ku p R 1500
1999 ACCESSORIES & EQUIPMENT
CHRY - Power Seats
Ram Pickup, Ram Van & Ram Wagon
DESCRIPTION & OPERATION
Driver's power seat can be adjusted in 6 different
directions: up, down, forward, back, tilt forward, or tilt rearward.
The power seat system consists of a 6-way switch, motor assembly, seat
adjuster, motor cable, housing and wiring harness.
The power seat system receives battery power through circuit
breaker and a fuse in the Power Distribution Center (PDC). Battery
voltage is available to power seat system at all times. Three
permanent magnet reversible motors are coupled through cables to worm
gear box assemblies located in the seat tracks, providing the various
seat movements.
On Ram Pickup with extended cab (club cab and quad cab),
driver's seat also includes power operated lumbar support. Lumbar
support can be inflated or deflated as needed, using additional
switch. On seats with lumbar support, seat back remains at same
height, while seat cushion raises and lowers. On seats without lumbar
support, entire seat raises and lowers. On all seats, entire seat
moves forward and backward.
TROUBLE SHOOTING
NOTE: Before any testing is attempted, the battery should be fully
charged and all connections and terminals cleaned and
tightened to ensure proper continuity and chassis grounds.
POWER SEAT INOPERATIVE
With dome light on, apply power seat switch in direction of
failure. If dome light dims, power seat may be jamming. Check for
binding or obstructions. If dome light does not dim, check individual
components. See COMPONENT TESTS.
COMPONENT TESTS
HARNESS VOLTAGE TEST
NOTE: This test will determine whether or not voltage is continuous
through body harness to power seat switch.
1) Remove power seat switch from mounting position and
disconnect switch from wiring harness. See POWER SEAT SWITCH under
REMOVAL & INSTALLATION.
2) Connect test light lead to ground terminal (Black wire on
Ram Van and Ram Wagon; Black/Orange wire on Ram Pickup) at power seat
switch harness connector. Using test light, probe power supply wire
(Red/Light Blue wire) at power seat switch harness connector.
3) If test light comes on, power and ground circuits to power
seat switch are good. If test light does not come on, check ground
circuit. See WIRING DIAGRAMS. Repair as necessary. If ground circuit
is okay, check power supply. See CIRCUIT BREAKER. Check ground circuit
for continuity.

CIRCUIT BREAKER
1) Circuit breaker is located in fuse block. On Ram Van and
Ram Wagon, fuse block is located under glove box door. On Ram Pickup,
fuse block is located at extreme left end of instrument panel under
protective cover. On all models, pull circuit breaker outward
slightly, ensuring circuit breaker terminals still contact terminals
in fuse block. Connect negative voltmeter lead to ground. With
positive lead, check each terminal of circuit breaker for voltage.
2) If battery voltage exists at both terminals, circuit
breaker is good. If battery voltage exists at only one terminal,
circuit breaker is defective. Replace circuit breaker. If battery
voltage does not exist at either terminal, check for open or shorted
circuit to fuse box. Repair as necessary.
MOTOR
1) Operate power seat switch to move all 3 seat motors. Seat
should move in all directions. If one or more motors operate, see
POWER SEAT SWITCH. If no motors operate, go to next step.
2) Check circuit breaker in fuse block. See CIRCUIT BREAKER.
If circuit breaker is good, go to next step. If circuit breaker is
faulty, replace circuit breaker and retest system.
3) Remove power seat switch. See POWER SEAT SWITCH under
REMOVAL & INSTALLATION. Check for battery voltage at power supply (Red
wire on Ram Van and Ram Wagon; Red/Light Blue wire on Ram Pickup). If
battery voltage exists, go to next step. If battery voltage does not
exist, repair open in wire.
4) Check for continuity between switch connector ground
circuit (Black wire on Ram Van and Ram Wagon; Black/Orange wire on Ram
Pickup) and ground. If continuity exists, go to next step. If
continuity does not exist, repair open in wire.
5) Test power seat switch. See POWER SEAT SWITCH. Replace
switch as necessary and retest system. If switch tests good, check
wiring harness between switch connector and motor. Repair as
necessary. If wiring is okay, replace defective power seat
adjuster/motors assembly.
POWER SEAT SWITCH
Remove switch from mounting position. See POWER SEAT SWITCH
under REMOVAL & INSTALLATION. Using an ohmmeter, check continuity
between power seat switch terminals as indicated. See POWER SEAT
SWITCH CONTINUITY TEST (RAM PICKUP) or POWER SEAT SWITCH CONTINUITY
TEST (RAM VAN & RAM WAGON) table. See Fig. 1 or 2. If continuity does
not exist as specified, replace switch. If continuity exists as
specified, switch is okay.
Fig. 1: Testing Power Seat Switch Terminals (Ram Pickup)
Courtesy of Chrysler Corp.

STE ER IN G C O LU M N S W IT C HES
1999 D odge P ic ku p R 1500
1999 ACCESSORIES & EQUIPMENT
CHRY - Steering Column Switches
Dakota, Durango & Ram Pickup
WARNING: Deactivate air bag system before performing any service
operation involving steering column components. See
appropriate AIR BAG RESTRAINT SYSTEMS article. DO NOT apply
electrical power to any component on steering column without
first disconnecting air bag module. Air bag may deploy. Wait
at least 2 minutes after disconnecting negative battery cable
before servicing air bag system. System reserve capacitor,
integral to ACM, maintains air bag system voltage for about 2
minutes after battery is disconnected. Servicing air bag
system before 2-minute period may cause accidental air bag
deployment and possible personal injury.
DESCRIPTION
Turn signal, hazard flasher, headlight beam selector,
headlight flash-to-pass, windshield wipe, pulse wipe and windshield
wash systems use a common switch assembly (multifunction switch)
mounted within upper steering column housing.
Ignition switch and lock cylinder are incorporated into an
assembly attached to side of steering column. Ignition switch assembly
can be serviced as a separate unit, but requires removal of lock
cylinder.
COMPONENT LOCATIONS
COMPONENT LOCATIONS








\









\









\









\









\









\









\







Component Location
Combination Flasher Relay ........................... Junction Block
Horn ............................... In Right Front Corner Of Engine
Compartment
Horn Relay ............................ In Power Distribution Center
Junction Block ................. Under Left Side Of Instrument Panel
Power Distribution Center ...... In Left Side Of Engine Compartment,
On Left Inner Panel
Relay/Flasher Module ........ Under Right Side Of Instrument Panel,
Behind Glove Box









\









\









\









\









\









\









\







TROUBLE SHOOTING
TURN SIGNAL AND HAZARD FLASHER SYSTEM
Bulbs Burn Out Rapidly
Check charging system. See appropriate GENERATORS &
REGULATORS article in STARTING & CHARGING SYSTEMS.
Hazard Flashers Inoperative
Blown fuse. Faulty hazard flasher. Open circuit in feed wire
to hazard switch. Faulty turn signal/hazard switch. Open or grounded
circuit in wiring to external lights.


WIN DO W S - P O W ER

1999 D odge P ic ku p R 1500
1999 ACCESSORIES & EQUIPMENT
CHRY - Power Windows
Caravan, Dakota, Durango, Ram Pickup, Ram Van, Ram Wagon,
Town & Country, & Voyager
DESCRIPTION & OPERATION
A permanent magnet motor moves each of the power windows,
including power vent windows. A positive and negative battery
connection to either of the 2 motor terminals will cause the motor to
rotate in one direction. Reversing current through these same 2
connections will cause the motor to rotate in the opposite direction.
Each individual motor is grounded through the master switch by a wire
attached to the instrument panel reinforcement.
Caravan, Durango, Town & Country and Voyager are equipped
with an Auto Down feature. Drivers window can be lowered without
having to hold the switch in the down position. Auto Down feature can
be activated by pressing down switch past first detent. Caravan, Town
& Country and Voyager have optional power vent windows. Power rear
vent windows are operated by switches mounted in driver's door panel.
NOTE: Power window circuits on Caravan, Town & Country, and Voyager
use Positive Temperature Coefficient (PTC) devices. The PTC
is a specified amperage solid-state resettable fuse. PTCs are
located in junction box behind driver's side of instrument
panel, to left of steering column. To reset PTC, all current
must be removed from PTC for approximately 20 seconds.
ADJUSTMENTS
WINDOWS
Remove door trim panel. See DOOR TRIM PANEL under REMOVAL &
INSTALLATION. Loosen bolts holding window to regulator. Raise window
fully, seating window in frame. Tighten bolts. Install door trim
panel.
TROUBLE SHOOTING
CARAVAN, TOWN & COUNTRY, & VOYAGER
Inspect both No. 8 and 9 (9-amp) PTCs in junction block.
Junction block is located under left side of instrument panel.
* Inspect fuse No. 23 (40-amp) in Power Distribution Center
(PDC). PDC is located on left side of engine compartment.
* Inspect ground at instrument panel left side cowl.
DAKOTA & DURANGO
Inspect circuit breaker No. 20 (20-amp on Dakota, 25-amp on
Durango) in fuse block. Fuse block is located on left end of
instrument panel.
* Inspect fuse No. 9 (40-amp) in Power Distribution Center
(PDC). PDC is located in left front corner of engine
