1999 DODGE RAM check engine

NOTE: A leaking fuel injector or high-pressure fuel line may cause
a rough idle, Black smoke, poor engine performance, poor fuel
economy and fuel knock. Following procedure is for
determining if fuel injector is defective.
WARNING: DO NOT allow diesel fuel to contact hot engine when checking
fuel injector, as high exhaust temperatures could cause a
fire. Use care when working around high-pressure fuel lines,
as fuel is under extreme pressure and could penetrate skin,
causing personal injury. Wear safety goggles and protective
clothing when checking fuel injectors.
Fuel Injector
1) Since a leaking high-pressure fuel line may cause the same
symptoms, check for leaking high-pressure fuel line before checking
fuel injector. To check for a leaking high-pressure fuel line, start
engine and allow engine to idle.
2) Inspect high-pressure fuel lines and connections for signs
of fuel leakage by placing cardboard over high-pressure fuel line and
connection. Note if leak is being detected by fuel being sprayed onto
cardboard. If leak exists, repair leak by tightening high-pressure
fuel line nut to 18 ft. lbs. (24 N.m) or replacing high-pressure fuel
line as necessary. If high-pressure fuel line is replaced, bleed air
from fuel system. See FUEL LINE BLEEDING under FUEL SYSTEM in REMOVAL,
OVERHAUL & INSTALLATION article.
3) To check for defective fuel injector, start and idle
engine. Loosen high-pressure fuel line nut at fuel injector and listen
for a decrease in engine speed. Tighten high-pressure fuel line nut to
18 ft. lbs. (24 N.m).
4) If fuel injector is operating properly, engine idle speed
should decrease when high-pressure fuel line nut is loosened. Repeat
procedure on each fuel injector.
5) If engine idle speed does not decrease, fuel injector is
defective and should be removed and tested with a diesel fuel injector
tester. Replace fuel injector if fuel injector opening (pop) pressure
is not about 4500 psi (316 kg/cm

).
EMISSION SYSTEMS & SUB-SYSTEMS
INTAKE MANIFOLD AIR HEATER SYSTEM
Intake Manifold Air Heater Preheat/Postheat Cycle
For testing information on intake manifold air heater system,
see DTC P0380: INTAKE AIR HEATER RELAY NO. 1 CONTROL CIRCUIT and DTC
P0382: INTAKE AIR HEATER RELAY NO. 2 CONTROL CIRCUIT tests in SELF-
DIAGNOSTICS - JEEP, TRUCKS & RWD VANS article.
MISCELLANEOUS CONTROLS
NOTE: Although some controlled devices listed here are not
technically engine performance components, they can affect
driveability if they malfunction.
TRANSMISSION
Park/Neutral Switch (A/T Models)
Park/neutral switch is mounted on transmission case, near
shift lever and contains a 3-pin connector. If problem exists in
park/neutral switch or wiring circuit, a Diagnostic Trouble Code (DTC)\
will be stored in Powertrain Control Module (PCM). See DTC P1899: P/N
SWITCH STUCK IN PARK OR IN GEAR test in SELF-DIAGNOSTICS - JEEP,


I - S YSTE M /C O M PO NEN T T E STS - R W D - G ASO LIN E

1999 D odge P ic ku p R 1500
1999 ENGINE PERFORMANCE
CHRY - System & Component Testing - Trucks & RWD Vans - Gas
Dodge: Dakota, Durango, Ram Pickup, Ram Van, Ram Wagon
Jeep Cherokee, Grand Cherokee, Wrangler
INTRODUCTION
Before testing individual components or systems, perform
procedures in BASIC DIAGNOSTIC PROCEDURES - TRUCKS & RWD VANS -
GASOLINE article. Since many computer controlled and monitored
components set a fault message if they malfunction, also perform
procedures in SELF-DIAGNOSTICS - JEEP, TRUCKS & RWD VANS article.
NOTE: Testing of individual components does not isolate possible
shorts or opens in wiring harness of electronically
controlled systems. Perform all voltage tests using a Digital
Volt-Ohmmeter (DVOM) with a minimum 10-megohm input impedance\
unless otherwise instructed in procedure. Use an ohmmeter to
isolate wiring harness shorts or opens.
COMPUTERIZED ENGINE CONTROLS
POWERTRAIN CONTROL MODULE (PCM)
PCM power and ground circuits may be checked by performing
TEST NS-1 in SELF-DIAGNOSTICS - JEEP, TRUCKS & RWD VANS article. For
PCM location, see PCM LOCATION table.
PCM LOCATION









\









\









\









\









\









\









\







Application Location
Dakota & Durango ................. Right Front Fender, Near Firewall
Ram Pickup, Ram Van & Ram Wagon ...... On Firewall, Near Wiper Motor









\









\









\









\









\









\









\







ENGINE SENSORS, SOLENOIDS & SWITCHES
SENSORS
Camshaft Position (CMP) Sensor
See appropriate DTC P0340: NO CAM SIGNAL AT PCM test in SELF-
DIAGNOSTICS - JEEP, TRUCKS & RWD VANS article.
Crankshaft Position (CKP) Sensor
See appropriate DTC P0320: NO CRANK REFERENCE SIGNAL AT PCM
test in SELF-DIAGNOSTICS - JEEP, TRUCKS & RWD VANS article.
Engine Coolant Temperature (ECT) Sensor
See appropriate DTC P0117: ECT SENSOR VOLTAGE TOO LOW and DTC
P0118: ECT SENSOR VOLTAGE TOO HIGH tests in SELF-DIAGNOSTICS - JEEP,
TRUCKS & RWD VANS article.
Heated Oxygen Sensor (HO2S)
See appropriate DTC for oxygen sensor in SELF-DIAGNOSTICS -
JEEP, TRUCKS & RWD VANS article.

See appropriate DTC P0505: IAC MOTOR CIRCUIT in SELF-
DIAGNOSTICS - JEEP, TRUCKS & RWD VANS article.
IGNITION SYSTEM
NOTE: For basic ignition checks, see TEST NS-SEL: NO START TEST
SELECTION in SELF-DIAGNOSTICS - JEEP, TRUCKS & RWD VANS
article.
EMISSION SYSTEMS & SUB-SYSTEMS
NOTE: To locate emission components, refer to emission control
information label in engine compartment.
AIR INJECTION
No Air Supply (Ram Pickup 5.9L & 8.0L)
1) Start engine, and increase engine speed to 1500 RPM. Check
air supply at rubber hoses. If air supply increases with RPM, air pump
operation is okay.
2) If air pump is okay, check for leakage at hoses and
fittings. Repair or replace hoses as necessary.
3) If hoses are okay, check pressure relief valve for
leakage. If air is expelled through pressure relief valve at idle,
replace relief valve.
4) If relief valve is okay on 5.9L, test is complete. On 8.
0L, check inlet air filter. Repair air filter if plugged. If air
filter is okay, test is complete.
CRANKCASE VENTILATION (CCV)
8.0L
1) CCV system does NOT use a PCV valve. System consists of a
fixed orifice (Gray color) that is calibrated to a specific flow rate.\
The fixed orifice (located on intake manifold) is connected by a tube
to right valve cover.
2) A similar orifice is used on left cylinder head, but is
Black in color and cannot be interchanged with Gray orifice. Ensure
orifice, tubes and fittings are clean and in good condition. No
further information is available from manufacturer.
EXHAUST GAS RECIRCULATION (EGR)
EGR Valve
See TEST NTC-2: CHECKING EGR SYSTEM in SELF-DIAGNOSTICS -
JEEP, TRUCKS & RWD VANS article.
FUEL EVAPORATION
EVAP Canister
EVAP canister is located in engine compartment. Canister has
no moving parts. Check for loose, missing, cracked or broken
connections and parts. Repair or replace as necessary. No liquid
should be in canister.
LEAK DETECTION PUMP (LDP)
LDP
See appropriate DTC P1494: LEAK DETECTION PUMP SWITCH OR
MECHANICAL FAULT test in SELF-DIAGNOSTICS - JEEP, TRUCKS & RWD VANS


H - T E STS W /O C O DES - D IE SEL

1999 D odge P ic ku p R 1500
1999 ENGINE PERFORMANCE
CHRY - Trouble Shooting - No Codes - Diesel
Ram Pickup
INTRODUCTION
Before using this article, perform steps in BASIC DIAGNOSTIC
PROCEDURES - TRUCKS - DIESEL and SELF-DIAGNOSTICS - JEEP, TRUCKS & RWD
VANS articles. Use this article to diagnose driveability problems
existing when a hard Diagnostic Trouble Code (FTC) is not present.
NOTE: Some driveability problems may have been corrected by
manufacturer with a revised Powertrain Control Module (PCM).
Check with manufacturer for latest PCM application.
Symptom checks direct the technician to malfunctioning
component(s) for further diagnosis. A symptom should lead to a
specific component, system test or adjustment.
Use TEST PROCEDURES under INTERMITTENTS to locate
driveability problems that DO NOT occur when the vehicle is being
tested. These test procedures should also be used if an intermittent
(soft) FTC was present, but no problem is found during self-diagnostic\
testing.
NOTE: For specific testing procedures, see SELF-DIAGNOSTICS -
JEEP, TRUCKS & RWD VANS article. For specifications, see ON
-VEHICLE ADJUSTMENTS - TRUCKS - DIESEL or SERVICE &
ADJUSTMENT SPECIFICATIONS - TRUCKS article.
SYMPTOMS
SYMPTOM DIAGNOSIS
Symptom checks cannot be used properly unless the problem
occurs while the vehicle is being tested. To reduce diagnostic time,
ensure steps in BASIC DIAGNOSTIC PROCEDURES - TRUCKS - DIESEL and
SELF-DIAGNOSTICS - JEEP, TRUCKS & RWD VANS articles were performed
before diagnosing a symptom. Symptoms available for diagnosis are as
follows:
* Black Exhaust Smoke
* White Exhaust Smoke
* Blue Exhaust Smoke
BLACK EXHAUST SMOKE
* Air filter dirty or plugged:
* Air intake system restricted:
* Exhaust system restriction is above specification:
* Poor fuel quality:
* Fuel injection pump malfunctioning:
* Fuel injector malfunctioning or leaking:
* Fuel return system restricted:
* Intake manifold restricted:
* Turbocharger problem.
WHITE EXHAUST SMOKE


H - T E STS W /O C O DES - G ASO LIN E
1999 D odge P ic ku p R 1500
1999 ENGINE PERFORMANCE
CHRY - Trouble Shooting - No Codes - Gasoline
Avenger, Breeze, Caravan, Cirrus, Concorde, Dakota, Durango,
Intrepid, LHS, Neon, Ram Pickup, Ram Van, Ram Wagon,
Stratus, Town & Country, Sebring Convertible, Sebring
Coupe, Voyager, 300M
INTRODUCTION
Before diagnosing symptoms or intermittent faults, perform
basic diagnostic procedures in the appropriate BASIC DIAGNOSTIC
PROCEDURES article and applicable self-diagnostic tests in the
appropriate SELF-DIAGNOSTICS article. Use this article to diagnose
driveability problems existing when a hard fault code is not present.
NOTE: Some driveability problems may have been corrected by
manufacturer with a revised Powertrain Control Module (PCM).
Check with manufacturer for latest PCM application.
Symptom checks direct the technician to malfunctioning
component(s) for further diagnosis. A symptom should lead to a
specific component, system test or adjustment.
Use intermittent test procedures to locate driveability
problems that do not occur when the vehicle is being tested. These
problems may cause a noticeable driveability problem or cause the
Malfunction Indicator Light (MIL) to illuminate on some vehicles.
These test procedures should also be used if a soft (intermittent)
trouble code is present, but no problem is found during self-
diagnostic testing.
NOTE: For specific testing procedures, see appropriate SELF
-DIAGNOSTICS article. For specifications, see appropriate ON
-VEHICLE ADJUSTMENTS and SERVICE & ADJUSTMENT SPECIFICATIONS
articles.
SYMPTOMS
SYMPTOM DIAGNOSIS
Symptom checks cannot be used properly unless the problem
occurs while the vehicle is being tested. To reduce diagnostic time,
ensure basic diagnostic procedures and self-diagnostic were performed
before diagnosing a symptom. Symptoms available for diagnosis are as
follows:
* Hard Start
* Starts But Stalls
* Hesitation Or Stumble
* Surging
* Lack Of Power
* Knocking
* Engine Misfire
* Backfire
* Rough Or Erratic Idle
* Poor Fuel Economy
HARD START

Check the following:
* Check secondary ignition system
* Check engine vacuum
* Check fuel pressure
* Check Engine Coolant Temperature (ECT) sensor calibration
* Check Throttle Position (TP) sensor calibration
* Check Manifold Absolute Pressure (MAP) calibration
* Check minimum idle airflow
* Check Idle Air Control (IAC) motor operation
* Check engine mechanical condition
* Check evaporative system
* Check EGR system
* Check coolant temperature sensor and connector
* Check Intake Air Temperature (IAT) sensor calibration
STARTS BUT STALLS
Check the following:
* Check secondary ignition system
* Check PCM power and ground circuits
* Check fuel pressure
* Check Engine Coolant Temperature (ECT) sensor calibration
* Check Throttle Position (TP) sensor calibration
* Check Manifold Absolute Pressure (MAP) calibration
* Check minimum idle airflow
* Check Idle Air Control (IAC) motor operation
HESITATION OR STUMBLE
Check the following:
* Check secondary ignition system
* Check PCM power and ground circuits
* Check engine vacuum
* Check fuel pressure
* Check Engine Coolant Temperature (ECT) sensor calibration
* Check Throttle Position (TP) sensor calibration
* Check Manifold Absolute Pressure (MAP) calibration
* Check minimum idle airflow
* Check oxygen sensor switching
* Check oxygen sensor heater
* Check Idle Air Control (IAC) motor operation
* Check engine mechanical condition
* Check evaporative system
* Check EGR system
* Check Intake Air Temperature (IAT) sensor calibration
* Check Park/Neutral Position (PNP) switch.
SURGING
Check the following:
* Check secondary ignition system
* Check PCM power and ground circuits
* Check engine vacuum
* Check fuel pressure
* Check Engine Coolant Temperature (ECT) sensor calibration
* Check Throttle Position (TP) sensor calibration
* Check Manifold Absolute Pressure (MAP) calibration
* Check minimum idle airflow

* Check oxygen sensor switching
* Check Idle Air Control (IAC) motor operation
* Check evaporative system.
LACK OF POWER
Check the following:
* Check secondary ignition system
* Check PCM power and ground circuits
* Check fuel pressure
* Check Engine Coolant Temperature (ECT) sensor calibration
* Check Throttle Position (TP) sensor calibration
* Check Manifold Absolute Pressure (MAP) calibration
* Check minimum idle airflow
* Check oxygen sensor switching
* Check Idle Air Control (IAC) motor operation
* Check EGR system.
KNOCKING
Check the following:
* Check secondary ignition system
* Check PCM power and ground circuits
* Check fuel pressure
* Check Engine Coolant Temperature (ECT) sensor calibration
* Check Throttle Position (TP) sensor calibration
* Check Manifold Absolute Pressure (MAP) calibration
* Check minimum idle airflow
* Check oxygen sensor switching
* Check Idle Air Control (IAC) motor operation
* Check evaporative system.
ENGINE MISFIRE
Check the following:
* Check secondary ignition system
* Check PCM power and ground circuits
* Check fuel pressure
* Check minimum idle airflow
* Check oxygen sensor switching
* Check Idle Air Control (IAC) motor operation
* Check EGR system.
BACKFIRE
Check the following:
* Check secondary ignition system
* Check PCM power and ground circuits
* Check fuel pressure
* Check Manifold Absolute Pressure (MAP) calibration
* Check minimum idle airflow
* Check oxygen sensor switching
* Check EGR system.
ROUGH OR ERRATIC IDLE
Check the following:

* Check secondary ignition system
* Check PCM power and ground circuits
* Check engine vacuum
* Check fuel pressure
* Check Engine Coolant Temperature (ECT) sensor calibration
* Check Throttle Position (TP) sensor calibration
* Check Manifold Absolute Pressure (MAP) calibration
* Check minimum idle airflow
* Check oxygen sensor switching
* Check oxygen sensor heater
* Check Idle Air Control (IAC) motor operation
* Check engine mechanical condition
* Check evaporative system
* Check EGR system
* Check Intake Air Temperature (IAT) motor operation
* Check Park/Neutral Position (PNP) switch.
POOR FUEL ECONOMY
Check the following:
* Check secondary ignition system
* Check PCM power and ground circuits
* Check engine vacuum
* Check fuel pressure
* Check Engine Coolant Temperature (ECT) sensor calibration
* Check Throttle Position (TP) sensor calibration
* Check Manifold Absolute Pressure (MAP) calibration
* Check minimum idle airflow
* Check oxygen sensor switching
* Check oxygen sensor heater
* Check Idle Air Control (IAC) motor operation
* Check engine mechanical condition
* Check evaporative system
* Check EGR system
* Check Intake Air Temperature (IAT) motor operation
* Check Park/Neutral Position (PNP) switch.
INTERMITTENTS
INTERMITTENT PROBLEM DIAGNOSIS
Intermittent fault testing requires duplicating circuit or
component failure to identify the problem. These procedures may lead
to PCM setting a Diagnostic Trouble Code (FTC) which may help in
diagnosis.
If problem vehicle does not produce FTC, monitor voltage or
resistance values using a DVOM while attempting to reproduce
conditions causing intermittent fault. A status change on DVOM
indicates a fault has been located.
Use a DVOM to pinpoint faults. When monitoring voltage,
ensure ignition switch is in ON position or engine is running. Ensure
ignition switch is in OFF position or negative battery cable is
disconnected when monitoring circuit resistance. Status changes on
DVOM during test procedures indicate area of fault.
TEST PROCEDURES
Intermittent Simulation
To reproduce the conditions creating an intermittent fault,
use the following methods:
