1999 CHEVROLET VENTURE relay

yellowblue
6-62
Maxi Fuse Usage
1
-COOL FAN 2 Coolant Fans
2 Not Used
3
-HEADLAMPS Circuit Breakers: FRT HVAC HI
BLWR, and HEADLAMP Fuses
(Instrument Panel): HAZARD
and STOPLAMP
4
-BATT MAIN 2 Circuit Breaker: PWR
SEAT/PSD. Fuses (Instrument
Panel): ELC and RR DEFOGMaxi Fuse Usage
5
-IGN MAIN 1 Ignition Switch to Fuses
(Instrument Panel): ABS/TCS
IGN, CRUISE, DRL, ELEC
PRNDL, IGN 1, PSD, SIR, T/SIG
and PCM [IGN MAIN Relay
(Underhood Electrical Center
Fuses: A/C CLU, ELEK IGN,
IGN 1
-U/H, INJ, TCC)]
6
-COOL FAN 1 Coolant Fans
7
-BATT MAIN 1 Fuses (Instrument Panel): ABS
MOD BATT, CIGAR/DLC,
CTSY LAMP, FRT PWR SCKT,
PWR LOCK, PWR MIRROR and
RR PWR SCKT
8
-IGN MAIN 2 Ignition Switch to Fuses (I/P):
BCM PRGRM, FRT HVAC
LOW/MED BLWR, FRT
WPR/WSHR, HVAC/DRL,
MALL/RADIO/DIC, PWR QRT
VENT, RR HVAC, RR
WPR/WSHR, SWC ACCY and
PWR WDO Circuit Breaker

yellowblue
6-63
Mini Relays Usage
9
-COOL FAN RH FAN 1, LH FAN 2
10
-COOL FAN 2 LH FAN 2
11
-IGN MAIN FUSES: A/C CLU, IGN 1-U/H,
INS, ELEK IGN, TCC
12
-COOL FAN 1 RH FAN 1, LH FAN 2
Micro Relays Usage
13
-A/C CLU A/C Clutch
14
-FUEL PUMP Fuel Pump
15
-F/PMP SPD
CONTNot Used
16
-HORN Horn
17
-FOG LAMP LH Fog Lamp, RH Fog Lamp,
Fog Lamp Indicator
Mini Fuse Usage
18
-INJ Fuel Injectors 1-6
19
-SPARE Not Used
20 Not UsedMini Fuse Usage
21
-IGN1-UH Evaporative Emissions (EVAP)
Canister Purge Valve, Heated
Oxygen Sensors 1 and 2, Mass
Air Flow (MAF) Sensor
22
-SPARE Not Used
23
-SPARE Not Used
24
-SPARE Not Used
25
-ELEK IGN Ignition Control Module (ICM)
26
-SPARE Not Used
27
-B/U LAMP Transaxle Range Switch to
Back
-up Lamps
28
-A/C CLU A/C CLU Relay to A/C
Compressor Clutch Oil
29
-RADIO Driver Information Display,
Heater A/C Control, Radio, Rear
Side Door Actuator Control
Motor, Remote Control Door
Lock Receiver (RCDLR),
Security Indicator Lamp and
Theft
-Deterrent Shock Sensor

yellowblue
6-64
Mini Fuse Usage
30
-ALT SENSE Generator
31
-TCC Automatic Transaxle (Torque
Converter Clutch Solenoids)
Stoplamp Switch to PCM
32
-FUEL PUMP Fuel Pump Relay
33
-ECM SENSE Powertrain Control Module
(PCM)
34 Not Used
35
-FOG LP Fog Lamp Relay
36
-HORN Horn Relay
37
-PARK LP Daytime Running Lamps (DRL)
Control Module, Headlamps and
Instrument Panel Dimmer Switch
Theft
-Deterrent Relay to
Headlamps
38 Not Used
39
-Spare Not Used
40 Mini Fuse Puller
Replacement Bulbs
Headlamps 9004-HBI . . . . . . . . . . . . . . . . . . . . . . . . .
Front Turn Signal/
Parking Lamps 3157NA or 3157 NAK. . . . . . . . . .
Front Sidemarker Lamps 194. . . . . . . . . . . . . . . . . . .
Stop/Taillamps (Top) 3057. . . . . . . . . . . . . . . . . . . . .
Signal Lamps (2nd from Top) 3156. . . . . . . . . . . . . .
Back
-up Lamps (3rd from Top) 3156. . . . . . . . . . . . .
Taillamps (Bottom) 3057. . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions.
Please refer to ªRecommended Fluids and Lubricantsº
in the Index for more information.
Automatic Transaxle
Pan Removal and Replacement 8.0 quarts (7.5 L). . .
Cooling System
With A/C 9.6 quarts (9.1 L). . . . . . . . . . . . . . . . . . . .
With Rear Climate Control 11.9 quarts (11.3 L). . . . .
