1999 CHEVROLET TRACKER instrument panel

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-40
Mirrors
Inside Day/Night Rearview Mirror
An inside rearview mirror is attached to your
windshield. The mirror has pivots so that you can adjust
it up and down or side to side.
You can adjust the mirror for day or night driving. Pull
the tab for night driving to reduce glare. Push the tab for
daytime driving.
Outside Manual Adjust Mirrors
Adjust these mirrors by hand so that you can just
see the side of your vehicle when you are sitting in a
comfortable driving position.
Power Remote Control Mirrors
(If Equipped)
JE±12±0018±X
The switch to control the
power mirrors is located on
the lower left side of the
instrument panel.
You can only adjust the mirrors when the ignition switch
is in the ON or ACC position.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-41
To adjust the mirrors:
1. Move the selector switch to the L (left) or R (right)
to select the mirror you wish to adjust.
2. Press the outer part of the pad that matches the
direction you want to move the mirror.
3. Return the selector switch to the center position to
help prevent moving the mirror accidentally.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Storage Compartments
Glove Box
To open the glove box, pull the latch toward you.
Use your key to lock and unlock the glove box.
The glove box has a two
-position detent for opening the
door. Lower the door to the first detent for access to the
glove box. Pull it to the next detent for further access.
Door Storage
Each door has a storage compartment.
Coinholder
Your instrument panel has a coinholder located to the
left of the steering wheel.
Cupholder
Two cupholders are on the center console next to the
parking brake lever.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-56
The Instrument Panel -- Your Information System
JE±12±0033±X

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-57
A. Side Defroster Vent
B. Air Vent
C. Turn Signal/Multifunction Lever
D. Instrument Cluster
E. Windshield Wiper/Washer Lever
F. Hazard Switch
G. Rear Window Defogger (If Equipped)
H. Comfort Controls
I. Vent Shut
-off Thumbwheel
J. Audio System
K. AshtrayL. Shift Lever
M. Power Mode Switch (If Equipped)
N. Cigarette Lighter
O. Ignition Switch
P. Instrument Panel Fuse Block
Q. Hood Release
R. Instrument Panel Brightness Control
S. Power Remote Control Mirror (If Equipped)
T. Cruise Control Button (If Equipped)
U. Coinholder
V. Rear Window Wiper/Washer (If Equipped)

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-58
Instrument Panel Cluster
Your instrument cluster is designed to let you know at a glance how your vehicle is running. You'll know how fast
you're going, about how much fuel you have left, and many other things you'll need to know to drive safely
and economically.
JE±12±0034±X

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-60
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you are
familiar with this section, you should not be alarmed
when this happens.
Gages can indicate when there may be or is a problem
with one of your vehicle's functions. Often gages and
warning lights work together to let you know when
there's a problem with your vehicle.
When one of the warning lights comes on and stays on
when you are driving, or when one of the gages shows
there may be a problem, check the section that tells you
what to do about it. Please follow this manual's advice.
Waiting to do repairs can be costly
-- and even
dangerous. So please get to know your warning lights
and gages. They're a big help.
Safety Belt Reminder Light
When the key is turned to ON or START, a tone will
come on for about eight seconds to remind people to
fasten their safety belts, unless the driver's safety belt is
already buckled.
X±01±2040±T
The safety belt light will
also come on and stay on
until the driver's belt
is buckled.
Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows AIR BAG. The system checks the
air bag's electrical system for malfunctions. The light
tells you if there is an electrical problem. The system
check includes the air bag sensors, the air bag modules,
the wiring and the crash sensing and diagnostic module.
For more information on the air bag system, see ªAir
Bagº in the Index.
X±01±0001±T
This light will come on
when you start your engine,
and it will flash for a few
seconds. Then the light
should go out. This means
the system is ready.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-2
Comfort Controls
With this system, you can control the heating and
ventilation in your vehicle. If you have the air
conditioning option, you can also control cooling.
Your vehicle also has the flow
-through ventilation
system described later in this section.
Climate Control System
JE±13±0001±X
Airflow Lever
VENT: This position directs the airflow through
the instrument panel vents.
BI-LEVEL: This position directs air through the
instrument panel vents and toward the floor.
FLOOR: This position directs air toward the floor.
DEFOG: This position directs air toward the floor,
the windshield and side windows. The air conditioning
compressor will run automatically in this setting.
DEFROST: This position directs air to the
windshield and side windows. The air conditioning
compressor will run automatically in this setting.
Fan Control Lever
Slide the lever away from OFF to turn the system on.
Move the lever toward the fan symbol to increase the
fan's speed.
Temperature Control Lever
Slide the lever to change the temperature of the air
flowing from the system. Move it to the right for
warmer air and to the left for cooler air. Without
optional air conditioning, the air temperature cannot be
less than the outside air temperature.
Air Intake Lever
RECIRCULATE: Choose this position to
recirculate the inside air through the comfort control system.
OUTSIDE AIR: Choose this position to circulate
outside air through the comfort control system.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
4-7
Avoid needless heavy braking. Some people drive in
spurts
-- heavy acceleration followed by heavy
braking
-- rather than keeping pace with traffic. This is a
mistake. Your brakes may not have time to cool between
hard stops. Your brakes will wear out much faster if you
do a lot of heavy braking. If you keep pace with the
traffic and allow realistic following distances, you will
eliminate a lot of unnecessary braking. That means
better braking and longer brake life.
If your engine ever stops while you're driving, brake
normally but don't pump your brakes. If you do, the
pedal may get harder to push down. If your engine
stops, you will still have some power brake assist. But
you will use it when you brake. Once the power assist is
used up, it may take longer to stop and the brake pedal
will be harder to push.
Anti-Lock Brakes (Option)
Your vehicle may have anti-lock brakes (ABS). ABS is
an advanced electronic braking system that will help
prevent a braking skid.
X±02±0111±T
If your vehicle has anti-lock
brakes, this warning light on
the instrument panel will
come on briefly when you
start your vehicle.
When you start your engine, or when you begin to drive
away, your anti
-lock brake system will check itself. You
may hear a momentary motor or clicking noise while
this test is going on, and you may even notice that your
brake pedal moves or pulses a little. This is normal.
If there's a problem with the anti
-lock brake system, the
anti
-lock brake system warning light will stay on. See
ªAnti
-Lock Brake System Warning Lightº in the Index.
