1999 CHEVROLET METRO Owners Manual

yellowblue
2-47
-NOTES

yellowblue
2-48
-NOTES

3-
yellowblue
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle. Be
sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control System
3
-3 Air Conditioner Controls (If Equipped)
3
-3 Heating
3
-4 Defogging and Defrosting
3
-4 Rear Window Defogger (If Equipped)
3
-4 Ventilation System
3
-6 Audio Systems
3
-6 Setting the Clock
3
-6AM-FM Stereo (If Equipped)3
-8AM-FM Stereo with Cassette Tape Player and
Automatic Tone Control (If Equipped)
3
-11 AM-FM Stereo with Compact Disc Player and
Automatic Tone Control (If Equipped)
3
-15 Understanding Radio Reception
3
-15 Tips About Your Audio System
3
-16 Care of Your Cassette Tape Player
3
-17 Care of Your Compact Discs
3
-17 Care of Your Compact Disc Player
3
-17 Antenna (If Equipped)

yellowblue
3-2
Comfort Controls
With this system, you can control the heating and
ventilation in your vehicle. If you have the air
conditioning option, you can also control cooling.
Your vehicle also has the flow
-through ventilation
system described later in this section.
Climate Control System
Airflow Lever
VENT: This position directs the airflow through
the instrument panel vents.
BI-LEVEL: This position directs air through the
instrument panel vents and toward the floor.
FLOOR: This position directs air toward the floor.
DEFOG: This position directs air toward the
floor, the windshield and side windows.
DEFROST: This position directs air to the
windshield and side windows.
Fan Control Lever
Slide the lever away from OFF to turn the system on.
Move the lever toward the fan symbol to increase the
fan's speed.
Temperature Control Lever
Slide the lever to change the temperature of the air
flowing from the system. Move it to the right for
warmer air and to the left for cooler air. Without
optional air conditioning, the air temperature can't be
less than the outside air temperature.
Air Intake Lever
CIRCULATE: Choose this position to circulate
outside air through the comfort control system.
RECIRCULATE: Choose this position to
recirculate the inside air through the comfort
control system.

yellowblue
3-3 Air Conditioner Controls (If Equipped)
The air conditioning system
uses the same controls as
described previously. The
function of each lever is
explained under ªClimate
Control Systemº in this
part. The incoming air is
cooled and dehumidified
instead of being heated.
Push the A/C button to change your comfort control
system from heating to air conditioning. A light will
come on when the air conditioning is on. The A/C
button can also control the humidity in your vehicle.
The air conditioner works best if you keep your
windows closed. On very hot days, open the windows
just long enough for the hot air to escape.For normal cooling, push the A/C button and move the
air intake lever to CIRCULATE. For faster cooling,
move the lever to RECIRCULATE. Then move the
airflow lever to VENT, the temperature control lever
toward the left and the fan control lever toward the
fan symbol.
On days when it is raining or the humidity is high,
follow these dehumidifying steps to help clean windows
that are cloudy with moisture. Push the A/C button.
Move the air intake lever to CIRCULATE. Move the
airflow lever to DEFROST and the fan control lever
toward the fan symbol. Adjust the temperature control
lever to a comfortable setting.
Heating
For the quickest results, move the air intake lever to
RECIRCULATE. Move the airflow lever to FLOOR, the
temperature control lever toward the right for warmer
air and the fan control lever toward the fan symbol. You
should switch to CIRCULATE once in a while to avoid
stale air and cloudy windows.

yellowblue
3-4 Defogging and Defrosting
Slide the air intake lever to CIRCULATE and the
airflow lever to DEFROST to direct air to the
windshield vents. Then slide the temperature control
lever toward the right and the fan control lever toward
the fan symbol. When the windshield is clear, turn down
the fan speed.
Rear Window Defogger (If Equipped)
The rear window defogger
uses a warming grid to
remove fog from the
rear window.Press the switch to turn on the defogger. Press the switch
again to turn the defogger off. The rear window
defogger will also turn off if you turn the ignition switch
to ACC or LOCK, but will turn back on when the
ignition is turned back to ON.
Do not attach anything like a temporary vehicle license
or a decal across the defogger grid on the rear window.NOTICE:
Don't use a razor blade or something else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.
Ventilation System
For mild outside temperatures, when little heating or
cooling is needed, you can still direct outside air through
your vehicle.
Move the air intake lever to CIRCULATE and the
airflow lever to BI
-LEVEL. Adjust the temperature
lever to a comfortable setting and move the fan control
lever toward the fan symbol.

yellowblue
3-5
Your vehicle's flow-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the car when the fan is running and
the air intake lever is at CIRCULATE.
Your vehicle has air outlets that allow you to adjust the
direction and amount of airflow inside the vehicle.
Move the outlet from side to side or up and down to
direct airflow to your preference. Increase or reduce the
amount of airflow by opening and closing the louvers.Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). The heater
and defroster will work far better, reducing the
chance of fogging the inside of your windows.

When you enter a car in cold weather, move the fan
control lever toward the fan symbol for a few
moments before driving off. This helps clear the
intake ducts of snow and moisture, and reduces the
chance of fogging the inside of your windows.

Keep the air path under the front seats clear of
objects. This helps air to circulate throughout
your vehicle.

yellowblue
3-6
Audio Systems
Your Delco Electronics audio system has been designed
to operate easily and give years of listening pleasure.
You will get the most enjoyment out of it if you acquaint
yourself with it first. Find out what your Delco
Electronics system can do and how to operate all its
controls, to be sure you're getting the most out of the
advanced engineering that went into it.
Setting the Clock
Press and hold RECALL (TIME SET) to set the correct
hour. At the same time, press and hold the TUNE left
arrow (H) until the correct hour appears.
Press and hold RECALL (TIME SET) to set the correct
minute. At the same time, press and hold the TUNE
right arrow (M) until the correct minute appears.
AM-FM Stereo (If Equipped)
Playing the Radio
PWR
-VOLUME: This knob turns the system on and
off and controls the volume. To increase volume and
turn the radio on, turn the knob clockwise. Turn it
counterclockwise to decrease volume.
RECALL: Display the time with the ignition off by
pressing this button. When the radio is playing, press
this button to recall the station frequency.
