1999 CHEVROLET CORVETTE center console

yellowblue
2-40
Selective Real Time Damping
(SRTD) (Option)
You may have a ride control system on your vehicle
called Selective Real Time Damping (SRTD). The
system provides the following performance benefits:

Reduced Impact Harshness

Improved Road Isolation

Improved High
-Speed Stability

Improved Handling Response
This switch is on the center console. Turn it to select the
suspension characteristic of your choice.
TOUR: Use for normal city and highway driving. This
setting provides a smooth, soft ride.
SPORT: Use where road conditions or personal
preference demand more control. This setting provides
more ªfeel,º or response to the road conditions.
PERF: Use for performance driving. This setting
provides a tight, firm ride and precise response to
road conditions.
You can select a setting at any time. Based on road
conditions, steering wheel angle and your vehicle speed,
the system automatically adjusts to provide the best ride
and handling. Select a new setting whenever driving
conditions change.
There are three Driver Information Center (DIC)
messages that are displayed when a malfunction occurs
with the SRTD system. Refer to ªDIC Warnings and
Messagesº in the Index.

yellowblue
2-56
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Storage Compartments
Instrument Panel Cupholder
The cupholder is located on the center console in front of
the ashtray. To open it, place your thumb on the left side
of the lid and raise the right side with your index finger.
Center Console Storage
To use this storage area, pull up the lid on the driver's
side front edge of the console and swing it to the
passenger's side.
You can use the key to lock and unlock the console.
Don't leave the key in the lock, or it could be damaged
when the driver sits down.
The fuel fill door release button and accessory power
outlet are located inside the center console.

yellowblue
2-60
Sun Visors
To block out glare, you can swing down the visors. You
can also swing them to the side.
Visor Vanity Mirrors
Pull down the sun visor and lift the cover to expose the
vanity mirror.
Lighted Visor Vanity Mirrors (Option)
Pull down the sun visor and lift the cover to expose the
lighted vanity mirror. When the cover is lifted, the lamps
will come on automatically, even if the ignition is off.
Accessory Power Outlet
The accessory power outlet is located inside the center
console storage compartment, on the forward left
-hand
side. Remove the tethered cap to use the outlet. The
outlet can be used to connect electrical equipment such
as a cellular phone or CB radio. Be sure to follow the
installation instructions included with the equipment.
Replace the cap when the accessory power outlet is not
in use.
NOTICE:
When using the accessory power outlet:

The maximum load of any electrical
equipment should not exceed 15 amps.

Be sure to turn off any electrical equipment
when not in use. Leaving electrical
equipment on for extended periods can
drain the battery.
We recommend that you see a qualified technician or your
dealer for the proper installation of your equipment.
Floor Mats (Option)
Your vehicle's floor mats are specially designed to
remain in position under your feet and out of reach of
the accelerator pedal. The driver's side floor mat is held
in place by two locator hooks and the passenger's side is
held in place by one.
Be sure that the driver's side floor mat is properly
placed on the floor so that it does not block the
movement of the accelerator pedal.

yellowblue
2-75
The main components of your instrument panel are:
A. HUD Controls (Option)
B. Turn Signal/Multifunction Lever
C. Driver Information Center (DIC)
(Located in the Instrument Cluster)
D. Instrument Panel Cluster
E. Windshield Wiper/Washer Lever
F. Driver Information Center (DIC) Buttons
G. Hazard Warning Flasher Button
H. Center Air Vent
I. Audio System
J. Comfort Controls
K. Fog Lamp Button (Option)
L. Remote Hatch Release Button (Coupe) or Remote
Trunk Release Button (Convertible/Hardtop)M. Ignition Switch
N. Shift Lever (Automatic Shown)
O. Traction Control System (TCS) Switch/Active
Handling Switch (Option)
P. Accessory Power Outlet
(Located in the Center Console)
Q. Selective Real Time Damping (SRTD) (Option)
R. Instrument Panel Cupholder
S. Remote Fuel Door Release Button
(Located in the Center Console)
T. Ashtray and Cigarette Lighter
U. Parking Brake
V. Glove Box
W. Instrument Panel Fuse Block

yellowblue
2-81 Traction Control System (TCS) Light
This light should come on
briefly as you start the
engine. If the light doesn't
come on then, have it fixed
so it will be ready to warn
you if there's a problem.
If it stays on, or comes on and the DIC shows a
SERVICE TRACTION SYSTEM message when you're
driving, there's a problem with your TCS system and
your vehicle needs service. When this light is on, the
system will not limit wheel spin. Adjust your driving
accordingly. If the driver turns off the Traction Control
System by pressing the button on the console, the TCS
system light will come on and the TRACTION
SYSTEM OFF message will show on the DIC.
Active Handling System Light
If your vehicle has the
optional Active Handling
System, this light will come
on briefly as you start the
engine. If the light does not
come on then, have it fixed
so it will be ready to warn
you if there is a problem.
If it stays on or comes on while you are driving, the
Driver Information Center (DIC) shows a SERVICE
ACTIVE HNDLG message and a chime sounds, there is
a problem with your Active Handling System and your
vehicle needs service. The driver can acknowledge this
message by pressing the RESET button. When the
SERVICE ACTIVE HNDLG message is displayed,
the Active Handling System will not assist you in
controlling the vehicle. You should have the system
serviced as soon as possible. Adjust your
driving accordingly.

yellowblue
2-82
When the system is working, you will see the ACTIVE
HANDLING message displayed in the DIC. You may
also feel or hear the system working. This is normal.
If the driver turns off the Active Handling System by
pressing the button on the console, the Active Handling
System light will come on, a chime will sound, and the
TRAC/ACT HNDLG OFF message will be displayed in
the DIC. The Traction Control System will also be
turned off. See ªDriver Information Center Messagesº in
the Index for more information.
If the Active Handling System and the Traction Control
System are off, pressing the console button momentarily
will turn both systems on. The DIC will display the
TRAC/ACT HNDLG ON message, the instrument
cluster light will be off, and a chime will sound. See
ªDriver Information Center Messagesº in the Index
for more information.Engine Coolant Temperature Gage
This gage shows the engine
coolant temperature. If the
gage pointer moves into the
shaded area, your engine is
too hot!
This means that your engine coolant has overheated.
If you have been operating your vehicle under normal
driving conditions, you should pull off the road, stop
your vehicle and turn off the engine as soon as
possible. (The larger tic marks are in increments of
30
below 220
F (104
C) and in increments of
10
above 220
F (104
C).)
In ªProblems on the Road,º this manual shows what to
do. See ªEngine Overheatingº in the Index.

yellowblue
2-102
DIC Warnings and Messages
The following messages and warnings may appear in the
DIC display. The DIC display area is located in the
instrument cluster below the speedometer and
tachometer, directly above the steering column.
You may receive more than one message at a time.
Messages will appear one behind the other. To
acknowledge a message and remove it from the display,
press RESET. You may scroll through the messages
that may have been sent at the same time. The message
center is continuously updated with the vehicle
performance status.
ABS ACTIVE (Anti
-Lock Brake System Active):
When your anti
-lock system is adjusting brake pressure
to help avoid a braking skid, the ABS ACTIVE message
will be displayed.
Slippery road conditions may exist if this message is
displayed, so adjust your driving accordingly. The
message will stay on for a few seconds after the system
stops adjusting brake pressure.ACT HNDLING WARMING UP: When you first start
you vehicle (especially in during cold winter weather),
and begin to drive away (up to 6 mph (10 km/h)), the
message ACT HNDLING WARMING UP may be
displayed in the DIC, the instrument cluster light will be
on, and a chime will sound. This is normal. You can
acknowledge this message by pressing the RESET
button. The Active Handling system performance is
affected until the next message WARM UP
COMPLETE is displayed in the DIC.
WARM UP COMPLETE : If you receive this message
and hear a chime, the system has completed the
functional check of the Active Handling System.
TRAC/ACT HNDLG - ON: If the Traction Control
and Active Handling Systems are off, depressing the
Active Handling System console button momentarily
will turn both systems on. The message TRAC/ACT
HNDLG
- ON will be displayed temporarily in the DIC,
the instrument cluster light will be off and a chime
will sound.

yellowblue
2-103
TRAC/ACT HNDLG - OFF: By pressing the Active
Handling System console button briefly, the driver can
turn the Traction Control and Active Handling Systems
off. The message TRAC/ACT HNDLG
- OFF will be
displayed in the DIC, the instrument cluster light will be
on and a chime will sound. You can acknowledge this
message by pressing the RESET button. The anti
-lock
brake systems remains on with the Traction Control and
Active Handling Systems off. You should adjust your
driving accordingly.
COMPETITIVE DRIVING: When the Competitive
Driving mode is selected, this message will be displayed
in the DIC. The instrument cluster light will not be on
when the Competitive Driving mode is selected. The
Traction Control System will not be operating while in
the Competitive Driving mode. You should adjust your
driving accordingly.SERVICE ABS (Anti
-Lock Brake System): If the
SERVICE ABS message is displayed when you are
driving, stop as soon as possible and turn the ignition
off. Then start the engine again to reset the system. If
the message stays on, or comes back on again while you
are driving, your vehicle is in need of service. If the
regular brake system warning light isn't on, you still
have brakes, but don't have anti
-lock brakes. If the
regular brake system light is also on, you don't have
anti
-lock brakes and there is a problem with your
brakes. See ªBrake System Warning Lightº earlier in
this section.
If the SERVICE ABS message is being displayed, your
traction control system and the optional active handling
system will also be disabled. The driver information
center will scroll three messages: SERVICE ABS,
SERVICE TRACTION SYS and SERVICE ACTIVE
HNDLG, and the instrument cluster car icon will be
illuminated. The driver can acknowledge these messages
by pressing the reset button three times. When the
service message is displayed the computer controlled
systems will not assist the driver and you should have
the system repaired as soon as possible. Adjust your
driving accordingly.
