1999 CHEVROLET CORVETTE active handling

yellowblue
2-75
The main components of your instrument panel are:
A. HUD Controls (Option)
B. Turn Signal/Multifunction Lever
C. Driver Information Center (DIC)
(Located in the Instrument Cluster)
D. Instrument Panel Cluster
E. Windshield Wiper/Washer Lever
F. Driver Information Center (DIC) Buttons
G. Hazard Warning Flasher Button
H. Center Air Vent
I. Audio System
J. Comfort Controls
K. Fog Lamp Button (Option)
L. Remote Hatch Release Button (Coupe) or Remote
Trunk Release Button (Convertible/Hardtop)M. Ignition Switch
N. Shift Lever (Automatic Shown)
O. Traction Control System (TCS) Switch/Active
Handling Switch (Option)
P. Accessory Power Outlet
(Located in the Center Console)
Q. Selective Real Time Damping (SRTD) (Option)
R. Instrument Panel Cupholder
S. Remote Fuel Door Release Button
(Located in the Center Console)
T. Ashtray and Cigarette Lighter
U. Parking Brake
V. Glove Box
W. Instrument Panel Fuse Block

yellowblue
2-81 Traction Control System (TCS) Light
This light should come on
briefly as you start the
engine. If the light doesn't
come on then, have it fixed
so it will be ready to warn
you if there's a problem.
If it stays on, or comes on and the DIC shows a
SERVICE TRACTION SYSTEM message when you're
driving, there's a problem with your TCS system and
your vehicle needs service. When this light is on, the
system will not limit wheel spin. Adjust your driving
accordingly. If the driver turns off the Traction Control
System by pressing the button on the console, the TCS
system light will come on and the TRACTION
SYSTEM OFF message will show on the DIC.
Active Handling System Light
If your vehicle has the
optional Active Handling
System, this light will come
on briefly as you start the
engine. If the light does not
come on then, have it fixed
so it will be ready to warn
you if there is a problem.
If it stays on or comes on while you are driving, the
Driver Information Center (DIC) shows a SERVICE
ACTIVE HNDLG message and a chime sounds, there is
a problem with your Active Handling System and your
vehicle needs service. The driver can acknowledge this
message by pressing the RESET button. When the
SERVICE ACTIVE HNDLG message is displayed,
the Active Handling System will not assist you in
controlling the vehicle. You should have the system
serviced as soon as possible. Adjust your
driving accordingly.

yellowblue
2-82
When the system is working, you will see the ACTIVE
HANDLING message displayed in the DIC. You may
also feel or hear the system working. This is normal.
If the driver turns off the Active Handling System by
pressing the button on the console, the Active Handling
System light will come on, a chime will sound, and the
TRAC/ACT HNDLG OFF message will be displayed in
the DIC. The Traction Control System will also be
turned off. See ªDriver Information Center Messagesº in
the Index for more information.
If the Active Handling System and the Traction Control
System are off, pressing the console button momentarily
will turn both systems on. The DIC will display the
TRAC/ACT HNDLG ON message, the instrument
cluster light will be off, and a chime will sound. See
ªDriver Information Center Messagesº in the Index
for more information.Engine Coolant Temperature Gage
This gage shows the engine
coolant temperature. If the
gage pointer moves into the
shaded area, your engine is
too hot!
This means that your engine coolant has overheated.
If you have been operating your vehicle under normal
driving conditions, you should pull off the road, stop
your vehicle and turn off the engine as soon as
possible. (The larger tic marks are in increments of
30
below 220
F (104
C) and in increments of
10
above 220
F (104
C).)
In ªProblems on the Road,º this manual shows what to
do. See ªEngine Overheatingº in the Index.

yellowblue
2-102
DIC Warnings and Messages
The following messages and warnings may appear in the
DIC display. The DIC display area is located in the
instrument cluster below the speedometer and
tachometer, directly above the steering column.
You may receive more than one message at a time.
Messages will appear one behind the other. To
acknowledge a message and remove it from the display,
press RESET. You may scroll through the messages
that may have been sent at the same time. The message
center is continuously updated with the vehicle
performance status.
ABS ACTIVE (Anti
-Lock Brake System Active):
When your anti
-lock system is adjusting brake pressure
to help avoid a braking skid, the ABS ACTIVE message
will be displayed.
Slippery road conditions may exist if this message is
displayed, so adjust your driving accordingly. The
message will stay on for a few seconds after the system
stops adjusting brake pressure.ACT HNDLING WARMING UP: When you first start
you vehicle (especially in during cold winter weather),
and begin to drive away (up to 6 mph (10 km/h)), the
message ACT HNDLING WARMING UP may be
displayed in the DIC, the instrument cluster light will be
on, and a chime will sound. This is normal. You can
acknowledge this message by pressing the RESET
button. The Active Handling system performance is
affected until the next message WARM UP
COMPLETE is displayed in the DIC.
WARM UP COMPLETE : If you receive this message
and hear a chime, the system has completed the
functional check of the Active Handling System.
TRAC/ACT HNDLG - ON: If the Traction Control
and Active Handling Systems are off, depressing the
Active Handling System console button momentarily
will turn both systems on. The message TRAC/ACT
HNDLG
- ON will be displayed temporarily in the DIC,
the instrument cluster light will be off and a chime
will sound.

yellowblue
2-103
TRAC/ACT HNDLG - OFF: By pressing the Active
Handling System console button briefly, the driver can
turn the Traction Control and Active Handling Systems
off. The message TRAC/ACT HNDLG
- OFF will be
displayed in the DIC, the instrument cluster light will be
on and a chime will sound. You can acknowledge this
message by pressing the RESET button. The anti
-lock
brake systems remains on with the Traction Control and
Active Handling Systems off. You should adjust your
driving accordingly.
COMPETITIVE DRIVING: When the Competitive
Driving mode is selected, this message will be displayed
in the DIC. The instrument cluster light will not be on
when the Competitive Driving mode is selected. The
Traction Control System will not be operating while in
the Competitive Driving mode. You should adjust your
driving accordingly.SERVICE ABS (Anti
-Lock Brake System): If the
SERVICE ABS message is displayed when you are
driving, stop as soon as possible and turn the ignition
off. Then start the engine again to reset the system. If
the message stays on, or comes back on again while you
are driving, your vehicle is in need of service. If the
regular brake system warning light isn't on, you still
have brakes, but don't have anti
-lock brakes. If the
regular brake system light is also on, you don't have
anti
-lock brakes and there is a problem with your
brakes. See ªBrake System Warning Lightº earlier in
this section.
If the SERVICE ABS message is being displayed, your
traction control system and the optional active handling
system will also be disabled. The driver information
center will scroll three messages: SERVICE ABS,
SERVICE TRACTION SYS and SERVICE ACTIVE
HNDLG, and the instrument cluster car icon will be
illuminated. The driver can acknowledge these messages
by pressing the reset button three times. When the
service message is displayed the computer controlled
systems will not assist the driver and you should have
the system repaired as soon as possible. Adjust your
driving accordingly.

yellowblue
2-106
TRACTION SYSTEM-OFF: You will hear a single
quick tone when this message is displayed. This
message comes on and stays on when the Traction
Control System button on the console is pressed to
turn the system off. To acknowledge this message,
press RESET.
SERVICE TRACTION SYSTEM: If the SERVICE
TRACTION SYS message is displayed when you are
driving, there is a problem with your Traction Control
System and your vehicle is in need of service. When this
message is displayed, the system will not limit wheel
spin. Adjust your driving accordingly.
If you have the optional Active Handling System, the
SERVICE ACTIVE HNDLG message will also be
displayed and the instrument cluster car icon will also be
illuminated. The driver can acknowledge both messages
by pressing the reset button two times which will also
turn off the instrument cluster icon. When the service
messages are displayed, the computer controlled
systems will not assist the driver in controlling the
vehicle. Have the system repaired as soon as possible.
Adjust your driving accordingly.SERVICE RIDE CONTROL: This message is used
to indicate to the driver that the Selective Real Time
Damping (SRTD) system has detected a malfunction
and that the system must be serviced. The SERVICE
RIDE CONTROL message will always come on when a
failure is detected by the Selective Real Time Damping
(SRTD) system. If a fault is present in the SRTD
which causes the shocks to be in their full soft condition,
the SERVICE RIDE CONTROL, SHOCKS
INOPERATIVE and MAXIMUM 80 MPH (129 km/h)
will display together. You will never get a SHOCKS
INOPERATIVE and MAXIMUM SPEED 80 MPH
(129 km/h) message without a SERVICE RIDE
CONTROL message.
SHOCKS INOPERATIVE: You will hear four chimes
when this message is displayed. To acknowledge that
you have read the message and to remove it from the
display, press RESET. The message will reappear every
10 minutes until this condition changes.
This message indicates that a malfunction is present in
the Selective Real Time Damping (SRTD) system which
is causing the shocks to be in their full soft mode.
This is a warning to the driver that the vehicle handling
may be affected. Have your vehicle serviced as soon
as possible.

yellowblue
2-108
HIGH TRANS TEMP (Automatic Transmission
Only): You will hear four chimes when this message
is displayed. To acknowledge this warning, press the
RESET button. After you press the RESET button,
the message will be displayed every 10 minutes until the
condition changes. If you do not press RESET,
the message remains on the display until the
condition changes.
If the transmission fluid temperature rises above
270
F (132
C) or rises rapidly, this message is
displayed. The transmission may shift gears or apply the
torque converter clutch to reduce the fluid temperature.
Driving aggressively or driving on long hills can cause
the transmission fluid temperature to be higher than
normal. If this message appears, you may continue to
drive at a slower speed. You should also monitor the
transmission fluid temperature and allow it to cool to at
least 230
F (110
C). The transmission fluid temperature
can be monitored with the GAGES button on the DIC.
See ªAutomatic Transmission Fluidº in the Index.
You should also check the engine coolant temperature.
If it is also hot, see ªEngine Overheatingº in the Index.If the HIGH TRANS TEMP message is displayed
during normal vehicle operation on flat roads,
your vehicle may need service. See your dealer for
an inspection.
SERVICE ACTIVE HANDLING: If the SERVICE
ACTIVE HNDLG message is displayed, there is a
problem with your Active Handling System and your
vehicle needs service. The instrument cluster light will
also be on and a chime will sound. When this message is
displayed, the system is not working. Adjust your
driving accordingly.
ACTIVE HANDLING: Your vehicle is equipped with
an optional computer controlled system to assist the
driver in controlling the vehicle in difficult driving
conditions. You may feel or hear the system working
and see the ACTIVE HANDLING message displayed in
the DIC. This is normal when the system is operating.

yellowblue
4-10
When this light and the SERVICE TRACTION
SYSTEM message are on, the system will not limit
wheel spin. Adjust your driving accordingly.
The TCS system automatically comes on whenever you
start your vehicle. To limit wheel spin, especially in
slippery road conditions, you should always leave the
system on. But you can turn the TCS system off if you
ever need to.
To turn the system off, press
the button located on the
console. You can turn the
system ON or OFF at any
time by pressing the TCS
switch. The DIC will
display the appropriate
message when you push
the button.
Active Handling System (Option)
The optional Active Handling System is a computer
controlled system that helps the driver maintain
directional control of the vehicle in difficult driving
conditions. This is accomplished by selectively applying
any one of the vehicle's brakes.
When you first start your vehicle and begin to drive
away (6 mph (10 km/h)), the message ACT HNDLG
WARMING UP may be displayed in the DIC, the
instrument cluster light will be on, and a chime will
sound. This is normal. You can acknowledge this
message by pressing the RESET button. The Active
Handling System performance is affected until the
message, WARM UP COMPLETE, is displayed in
the DIC.
The ACTIVE HANDLING message will come on when
the system is operating. See ªDriver Information Center
Messagesº in the Index for more information. You may
also feel or hear the system working. This is normal.
