1999 CHEVROLET CAVALIER service indicator

yellowblue
2-70 Engine Coolant Temperature Gage
Standard Cluster Optional Cluster
Your vehicle is equipped with one of these gages. With
the ignition in RUN, this gage shows the engine coolant
temperature.
If the gage pointer moves into the red area, your engine
is too hot! It means that your engine coolant has
overheated. If you have been operating your vehicle
under normal driving conditions, you should pull off the
road, stop your vehicle and turn off the engine as soon
as possible.
In ªProblems on the Road,º this manual shows what to
do. See ªEngine Overheatingº in the Index.
Low Coolant Warning Light
If this light comes on and
stays on, your system is low
on coolant and the engine
may overheat.
See ªEngine Coolantº in the Index and have your
vehicle serviced as soon as you can.
Malfunction Indicator Lamp
(Service Engine Soon Light)
Your vehicle is equipped
with a computer which
monitors operation of the
fuel, ignition and emission
control systems.

yellowblue
2-75 Check Gages Light
This light will come on
briefly when you are
starting the engine.
If the light comes on and stays on while you are driving,
check your various gages to see if they are in the
warning zones or if you are low on fuel.
Fuel Gage
When the ignition is on,
your fuel gage tells you
about how much fuel you
have left.When the indicator nears E (empty), you still have a
little fuel left, but you should get more soon.
Here are four things that some owners ask about. None
of these show a problem with your fuel gage:

At the service station, the gas pump shuts off before
the gage reads F (full).

It takes a little more or less fuel to fill up than the
gage indicated. For example, the gage may have
indicated the tank was half full, but it actually took a
little more or less than half the tank's capacity to fill
the tank.

The gage moves a little when you turn a corner or
speed up.

The gage doesn't go back to E (empty) when you
turn off the ignition.
For your fuel tank capacity, see ªCapacities and
Specificationsº in the Index.

yellowblue
3-24
3. Press and hold the TAPE AUX button for five
seconds. The tape symbol on the display will flash
for two seconds.
4. Insert the scrubbing action cleaning cassette.
5. Eject the cleaning cassette after the manufacturer's
recommended cleaning time.
When the cleaning cassette has been ejected, the cut tape
detection feature is active again.
You may also choose a non
-scrubbing action, wet-type
cleaner which uses a cassette with a fabric belt to clean
the tape head. This type of cleaning cassette will not
eject on its own. A non
-scrubbing action cleaner may
not clean as thoroughly as the scrubbing type cleaner.
The use of a non
-scrubbing action, dry-type cleaning
cassette is not recommended.
After you clean the player, press and hold EJECT for
five seconds to reset the CLN indicator. The radio will
display
--- to show the indicator was reset.
Cassettes are subject to wear and the sound quality
may degrade over time. Always make sure the cassette
tape is in good condition before you have your tape
player serviced.
Care of Your Compact Discs
Handle discs carefully. Store them in their original cases
or other protective cases and away from direct sunlight
and dust. If the surface of a disc is soiled, dampen a
clean, soft cloth in a mild, neutral detergent solution and
clean it, wiping from the center to the edge.
Be sure never to touch the signal surface when handling
discs. Pick up discs by grasping the outer edges or the
edge of the hole and the outer edge.
Care of Your Compact Disc Player
The use of CD lens cleaner discs is not advised, due to
the risk of contaminating the lens of the CD optics with
lubricants internal to the CD mechanism.
Fixed Mast Antenna
The fixed mast antenna can withstand most car washes
without being damaged. If the mast should ever become
slightly bent, you can straighten it out by hand. If the
mast is badly bent, as it might be by vandals, you should
replace it.
Check every once in a while to be sure the mast is still
tightened to the fender.

yellowblue
6-4
If your vehicle is certified to meet California Emission
Standards (indicated on the underhood emission control
label), it is designed to operate on fuels that meet
California specifications. If such fuels are not available
in states adopting California emissions standards, your
vehicle will operate satisfactorily on fuels meeting
federal specifications, but emission control system
performance may be affected. The malfunction indicator
lamp on your instrument panel may turn on and/or your
vehicle may fail a smog
-check test. (See ªMalfunction
Indicator Lampº in the Index.) If this occurs, return to
your authorized Chevrolet dealer for diagnosis to
determine the cause of failure. In the event it is
determined that the cause of the condition is the type of
fuels used, repairs may not be covered by your warranty.
Some gasolines that are not reformulated for low
emissions may contain an octane
-enhancing additive
called methylcyclopentadienyl manganese tricarbonyl
(MMT); ask your service station operator whether or not
the fuel contains MMT. General Motors does not
recommend the use of such gasolines. If fuels containing
MMT are used, spark plug life may be reduced and your
emission control system performance may be affected.
The malfunction indicator lamp on your instrument
panel may turn on. If this occurs, return to your
authorized Chevrolet dealer for service.To provide cleaner air, all gasolines in the United States
are now required to contain additives that will help
prevent deposits from forming in your engine and fuel
system, allowing your emission control system to
function properly. Therefore, you should not have to add
anything to the fuel. In addition, gasolines containing
oxygenates, such as ethers and ethanol, and
reformulated gasolines may be available in your area to
contribute to clean air. General Motors recommends that
you use these gasolines, particularly if they comply with
the specifications described earlier.
NOTICE:
Your vehicle was not designed for fuel that
contains methanol. Don't use it. It can corrode
metal parts in your fuel system and also damage
plastic and rubber parts. That damage wouldn't
be covered under your warranty.

yellowblue
6-33 Brake Wear
Your vehicle has front disc brakes and rear drum brakes.
Disc brake pads have built
-in wear indicators that make
a high
-pitched warning sound when the brake pads are
worn and new pads are needed. The sound may come
and go or be heard all the time your vehicle is moving
(except when you are pushing on the brake
pedal firmly).
CAUTION:
The brake wear warning sound means that soon
your brakes won't work well. That could lead to
an accident. When you hear the brake wear
warning sound, have your vehicle serviced.
NOTICE:
Continuing to drive with worn-out brake pads
could result in costly brake repair.
Some driving conditions or climates may cause a brake
squeal when the brakes are first applied or lightly
applied. This does not mean something is wrong with
your brakes.
See ªCaliper/Knuckle Maintenance Inspectionº in
Section 7 of this manual under Part C ªPeriodic
Maintenance Inspections.º
Properly torqued wheel nuts are necessary to help
prevent brake pulsation. When tires are rotated, inspect
brake pads for wear and evenly torque wheel nuts in the
proper sequence to GM specifications.
Your rear drum brakes don't have wear indicators, but if
you ever hear a rear brake rubbing noise, have the rear
brake linings inspected immediately. Also, the rear
brake drums should be removed and inspected each time
the tires are removed for rotation or changing. When
you have the front brake pads replaced, have the rear
brakes inspected, too.
Brake linings should always be replaced as complete
axle sets.
See ªBrake System Inspectionº in Section 7 of this
manual under Part C ªPeriodic Maintenance
Inspections.º

yellowblue
9-7
Interior 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Coolant Warning 2-70 . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure 2-73 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Passlock
Warning 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Reminder 1-8, 2-65 . . . . . . . . . . . . . . . . . . . . . .
Up-Shift 2-27, 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading Your Vehicle 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Locks
Door 2
-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transaxle Check 7-33 . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinder Service 7-32 . . . . . . . . . . . . . . . . . . . . .
Power Door 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Door Security 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loss of Control 4-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Coolant Warning Light 2-70 . . . . . . . . . . . . . . . . . . . . . .
Lowering the Convertible Top Manually 2-57 . . . . . . . . . . . . .
Lowering Your Convertible Top 2-50 . . . . . . . . . . . . . . . . . . .
Lubricants and Fluids 7-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication Service, Body 7-32 . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance, Normal Replacement Parts 6-63 . . . . . . . . . . .
Maintenance Record 7-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance Schedule 7-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Long Trip/Highway Definition 7-6 . . . . . . . . . . . . . . . . . . .
Long Trip/Highway Intervals 7-6 . . . . . . . . . . . . . . . . . . . . .
Owner Checks and Services 7-30 . . . . . . . . . . . . . . . . . . . . .
Periodic Maintenance Inspections 7-35 . . . . . . . . . . . . . . . .
Recommended Fluids and Lubricants 7-37 . . . . . . . . . . . . .
Scheduled Maintenance Services 7-4 . . . . . . . . . . . . . . . . . . Short Trip/City Definition 7
-5 . . . . . . . . . . . . . . . . . . . . . . .
Short Trip/City Intervals 7-5 . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance, Underbody 6-55 . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Trailer Towing 4-41 . . . . . . . . . . . . . . . . .
Malfunction Indicator Lamp 2-70 . . . . . . . . . . . . . . . . . . . . . .
Manual Front Seat 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Lumbar Support 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Remote Control Mirror 2-46 . . . . . . . . . . . . . . . . . . . .
Manual Transaxle 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check 7-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions 2-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 2-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shifting 2-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your Engine 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . .
Methanol 6-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mirrors
Convex Outside 2
-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night Rearview 2-46 . . . . . . . . . . . . . . . . . . . . .
Manual Remote Control 2-46 . . . . . . . . . . . . . . . . . . . . . . . .
Power Remote Control 2-46 . . . . . . . . . . . . . . . . . . . . . . . . .
Mobility Program 8-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mountain Roads 4-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Multifunction Lever 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Neutral, Automatic Transaxle 2-22 . . . . . . . . . . . . . . . . . . . .
Neutral, Manual Transaxle 2-26 . . . . . . . . . . . . . . . . . . . . . . . .
New Vehicle ªBreak-Inº 2-13 . . . . . . . . . . . . . . . . . . . . . . . . .
Night Vision 4-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-12
TTY Users 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal and Lane Change Signals 2-36 . . . . . . . . . . . . . . .
Turn Signal/Multifunction Lever 2-35 . . . . . . . . . . . . . . . . . . .
Turn Signals When Towing a Trailer 4-39 . . . . . . . . . . . . . . . .
Underbody Flushing Service 7-34 . . . . . . . . . . . . . . . . . . . . .
Underbody Maintenance 6-55 . . . . . . . . . . . . . . . . . . . . . . . . .
Up-Shift Light 2-27, 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle
Control 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage Warnings vii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 6
-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification Number 6-57 . . . . . . . . . . . . . . . . . . . . . . . . .
Loading 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ventilation System 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Visors, Sun 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Devices 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Lights, Gages and Indicators 2-65 . . . . . . . . . . . . . . .
Warranty Information 8-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washer Fluid, Windshield 6-29 . . . . . . . . . . . . . . . . . . . . . . . . Washing Your Vehicle 6
-52 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weatherstrip Lubrication 7-31 . . . . . . . . . . . . . . . . . . . . . . . . .
Weatherstrips 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel
Alignment 6
-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nut Torque 5-26, 6-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used Replacement 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrench 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows
Auto
-Down 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Washer
Fluid 2
-38, 6-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Level Check 7-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wiper 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Check 7-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Replacement 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse 6-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Winter Driving 4-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Blades, Cleaning 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring, Headlamp 6-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrecker Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrench, Wheel 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
