1999 BUICK REGAL turn signal

yellowblue
v
For example,
these symbols
are used on an
original battery:
CAUTION
POSSIBLE
INJURY
PROTECT
EYES BY
SHIELDING
CAUSTIC
BATTERY
ACID COULD
CAUSE
BURNS
AVOID
SPARKS OR
FLAMES
SPARK OR
FLAME
COULD
EXPLODE
BATTERY
These symbols
are important
for you and
your passengers
whenever your
vehicle is
driven:
DOOR LOCK
UNLOCK
FASTEN
SEAT
BELTS
POWER
WINDOW
AIR BAG
These symbols
have to do with
your lamps:
MASTER
LIGHTING
SWITCH
TURN
SIGNALS
PARKING
LAMPS
HAZARD
WARNING
FLASHER
DAYTIME
RUNNING
LAMPS
FOG LAMPS
These symbols
are on some of
your controls:
WINDSHIELD
WIPER
WINDSHIELD
WASHER
WINDSHIELD
DEFROSTER
REAR
WINDOW
DEFOGGER
VENTILATING
FAN
These symbols
are used on
warning and
indicator lights:
ENGINE
COOLANT
TEMP
BATTERY
CHARGING
SYSTEM
BRAKE
COOLANT
ENGINE OIL
PRESSURE
ANTI-LOCK
BRAKES
Here are some
other symbols
you may see:
FUSE
LIGHTER
HORN
SPEAKER
FUEL
Vehicle Symbols
These are some of the symbols you may find on your vehicle.
ProCarManuals.com

2-
yellowblue
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-7 Remote Keyless Entry
2
-14 Trunk
2
-14 Theft
2
-15 PASS-Key
II
2
-17 New Vehicle ªBreak-Inº
2
-17 Ignition Positions
2
-19 Starting Your V6 Engine
2
-20 Engine Coolant Heater (If Equipped)
2
-22 Automatic Transaxle Operation
2
-27 Parking Brake
2
-28 Shifting Into PARK (P)
2
-30 Shifting Out of PARK (P)
2
-32 Parking Over Things That Burn
2
-33 Engine Exhaust
2
-33 Running Your Engine While You're Parked
2
-34 Windows2
-35 Horn
2
-35 TILT-WHEEL Adjustable Steering Column
2
-36 Turn Signal/Multifunction Lever
2
-42 Exterior Lamps
2
-45 Interior Lamps
2
-48 Mirrors
2
-50 Storage Compartments
2
-53 Sun Visors
2
-53 Accessory Power Receptacle
2
-54 Auxiliary Power Connection (Power Drop)
2
-55 Astroroof (If Equipped)
2
-55 OnStar
(Option)
2
-56 The Instrument Panel -- Your
Information System
2
-57 Instrument Panel Cluster
2
-60 Warning Lights, Gages and Indicators
2
-75 Driver Information Center
ProCarManuals.com

yellowblue
2-8
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modifications to this system by other than an
authorized service facility could void authorization to
use this equipment.
This system has a range of about 3 feet (1 m) up to 30 feet
(9 m). At times you may notice a decrease in range. This is
normal for any remote keyless entry system. If the
transmitter does not work or if you have to stand closer to
your vehicle for the transmitter to work, try this:

Check to determine if battery replacement is
necessary. See the instructions that follow.

Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.

Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.

If you're still having trouble, see your dealer or a
qualified technician for service.Operation
Press UNLOCK once to
unlock the driver's door and
to turn on the interior lamps
(see ªIllumination on
Remote Activationº in the
Index for more details).
The perimeter lighting feature will also be activated at
night, turning on your headlamps and back
-up lamps for
15
-25 seconds. (This will light the area around the
vehicle.) See ªPerimeter Lightingº in the Index.
Press UNLOCK again within five seconds to unlock all
the doors. To lock all doors, press LOCK. To unlock the
trunk, press the trunk symbol on the remote keyless
entry transmitter. The trunk will only unlock if your
transaxle is in PARK (P).
ProCarManuals.com

yellowblue
2-36
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes your:

Turn Signal and Lane Change Indicator

Headlamp High/Low Beam Changer

Windshield Wipers

Windshield Washer

Cruise Control (If Equipped)

Flash
-to-Pass
Turn Signal and Lane Change Indicator
The turn signal has the following positions: two upward
(for right) and two downward (for left). These positions
allow you to signal a turn or a lane change.
To signal a turn, move the lever all the way up
or down. When the turn is finished, the lever will
return automatically.
An arrow on the instrument
panel will flash in the
direction of the turn or
lane change.
To signal a lane change, just raise or lower the lever
until the arrow starts to flash. Hold it there until you
complete your lane change. The lever will return by
itself when you release it.
If the arrow flashes faster than normal as you signal a
turn or a lane change, a signal bulb may be burned out
and other drivers won't see your turn signal.
ProCarManuals.com

yellowblue
2-37
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check for burned
-out bulbs and then check
the fuse (see ªFuses and Circuit Breakersº in the Index).
A chime will sound if you leave your turn signal on for
more than 3/4 mile (1.2 km).
Headlamp High/Low Beam Changer
To change your headlamps
from low beams to high
beams, or high to low, pull
the multifunction lever all
the way toward you. Then
release it.
When the high beams are on, this light on the instrument
panel also will be on.
Flash-to-Pass Feature
This feature lets you use your high-beam headlamps to
signal the driver in front of you that you want to pass. It
works even if your headlamps are off.
To use it, pull the turn signal lever toward you a little,
but not so far that you hear a click.
If your headlamps are off or on low beam, your
high
-beam headlamps will turn on. They'll stay on as
long as you hold the lever toward you and the
high
-beam indicator on the dash will come on. Release
the lever to turn the high
-beam headlampsªflashº off.
ProCarManuals.com

yellowblue
2-43
If you pull the knob out
halfway, it will turn on your
parking lamps and your
other operating lamps. If
you pull the knob all the
way out, your headlamps
will then come on.
Push the knob in all the way to turn off the lamps.
A warning chime will sound if you open the driver's
door when you turn the ignition switch to OFF, LOCK
or ACCESSORY with the lamps on.
Daytime Running Lamps / Automatic
Headlamp Control
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.A light sensor on top of the instrument panel makes the
DRL work, so be sure it isn't covered.
The DRL system will make your front turn signal lamps
come on when:

the ignition is on,

the headlamp switch is off and

the parking brake is released.
When the DRL are on, only your front turn signal lamps
will be on. The headlamps, taillamps, sidemarker and
other lamps won't be on. Your instrument panel won't
be lit up either.
When it's dark enough outside, your front turn signal
lamps will turn off and your vehicle's headlamps and
parking lamps will turn on. The other lamps that come
on with your headlamps will also come on.
When it's bright enough outside, your headlamps will go
off and your front turn signal lamps will come on.
To idle your vehicle with the DRL off, set the parking
brake while the ignition is in OFF or LOCK. Then start
your vehicle. The DRL, headlamps and parking lamps
will stay off until you release the parking brake.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
ProCarManuals.com

yellowblue
2-45 Fog Lamps
To turn the fog lamps on,
press the fog lamps switch
located below the headlamp
switch on the left side of the
steering column.
A light will glow on the switch to let you know that they
are on. (Your parking lamps or low
-beam headlamps
must be on or your fog lamps won't come on.) Press the
switch again to turn the fog lamps off. The fog lamps
will go off whenever you change to high
-beam
headlamps. When you return to low beams, the fog
lamps will come on again.
Cornering Lamps
The cornering lamps are designed to come on when you
signal a turn. This will provide more light for cornering
at night.
Interior Lamps
Instrument Panel Brightness Control
You can brighten or dim the instrument panel lights by
moving the LIGHTS dial. If you turn the dial past
MAX, your courtesy or interior lamps will come on.
Courtesy Lamps
When any door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easy for you to
enter and leave your vehicle. You can also turn these
lamps on by twisting or turning the interior lights knob
all the way to the right.
Illuminated Entry
Your courtesy lamps will come on and stay on for a set
time whenever you press UNLOCK on the remote
keyless entry transmitter.
If you open a door, the lamps will stay on while it's open
and then turn off automatically about 25 seconds after
you close it. If you press UNLOCK and don't open a
door, the lamps will turn off after about 40 seconds.
ProCarManuals.com

yellowblue
2-47
You may enable or disable the perimeter lighting feature
when the driver performs the following sequence with
the engine not running, the doors closed and the ignition
key in RUN:
1. Apply your brakes.
2. Press and hold the power door lock switch. While
holding the door lock switch press and release the
remote alarm button on the remote keyless entry
transmitter. This will initialize the customization
mode. While in the customization mode, the feature
will sound the number of chimes corresponding to
the current mode: In Mode 1, one chime means the
feature is disabled. In Mode 2, two chimes signal
that the perimeter lighting feature is enabled. Each
additional press will advance the mode by one,
starting from the current mode. During this
procedure, the feature will sound the number of
chimes corresponding to the mode. When the lock
switch is released, the vehicle will remain in the
last mode.
Disconnecting the vehicle's battery for up to a year will
not change the programmed operation of this feature.Rearview Mirror Reading Lamps
Use the switch next to each lamp to turn them on
and off.
Dome Lamp (If Equipped)
The dome lamp will come on when you open the doors.
ProCarManuals.com
