1999 BUICK REGAL low beam

yellowblue
2-36
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes your:

Turn Signal and Lane Change Indicator

Headlamp High/Low Beam Changer

Windshield Wipers

Windshield Washer

Cruise Control (If Equipped)

Flash
-to-Pass
Turn Signal and Lane Change Indicator
The turn signal has the following positions: two upward
(for right) and two downward (for left). These positions
allow you to signal a turn or a lane change.
To signal a turn, move the lever all the way up
or down. When the turn is finished, the lever will
return automatically.
An arrow on the instrument
panel will flash in the
direction of the turn or
lane change.
To signal a lane change, just raise or lower the lever
until the arrow starts to flash. Hold it there until you
complete your lane change. The lever will return by
itself when you release it.
If the arrow flashes faster than normal as you signal a
turn or a lane change, a signal bulb may be burned out
and other drivers won't see your turn signal.
ProCarManuals.com

yellowblue
2-37
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check for burned
-out bulbs and then check
the fuse (see ªFuses and Circuit Breakersº in the Index).
A chime will sound if you leave your turn signal on for
more than 3/4 mile (1.2 km).
Headlamp High/Low Beam Changer
To change your headlamps
from low beams to high
beams, or high to low, pull
the multifunction lever all
the way toward you. Then
release it.
When the high beams are on, this light on the instrument
panel also will be on.
Flash-to-Pass Feature
This feature lets you use your high-beam headlamps to
signal the driver in front of you that you want to pass. It
works even if your headlamps are off.
To use it, pull the turn signal lever toward you a little,
but not so far that you hear a click.
If your headlamps are off or on low beam, your
high
-beam headlamps will turn on. They'll stay on as
long as you hold the lever toward you and the
high
-beam indicator on the dash will come on. Release
the lever to turn the high
-beam headlampsªflashº off.
ProCarManuals.com

yellowblue
2-45 Fog Lamps
To turn the fog lamps on,
press the fog lamps switch
located below the headlamp
switch on the left side of the
steering column.
A light will glow on the switch to let you know that they
are on. (Your parking lamps or low
-beam headlamps
must be on or your fog lamps won't come on.) Press the
switch again to turn the fog lamps off. The fog lamps
will go off whenever you change to high
-beam
headlamps. When you return to low beams, the fog
lamps will come on again.
Cornering Lamps
The cornering lamps are designed to come on when you
signal a turn. This will provide more light for cornering
at night.
Interior Lamps
Instrument Panel Brightness Control
You can brighten or dim the instrument panel lights by
moving the LIGHTS dial. If you turn the dial past
MAX, your courtesy or interior lamps will come on.
Courtesy Lamps
When any door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easy for you to
enter and leave your vehicle. You can also turn these
lamps on by twisting or turning the interior lights knob
all the way to the right.
Illuminated Entry
Your courtesy lamps will come on and stay on for a set
time whenever you press UNLOCK on the remote
keyless entry transmitter.
If you open a door, the lamps will stay on while it's open
and then turn off automatically about 25 seconds after
you close it. If you press UNLOCK and don't open a
door, the lamps will turn off after about 40 seconds.
ProCarManuals.com

yellowblue
4-18 Night Vision
No one can see as well at night as in the daytime. But as
we get older these differences increase. A 50
-year-old
driver may require at least twice as much light to see the
same thing at night as a 20
-year-old.
What you do in the daytime can also affect your night
vision. For example, if you spend the day in bright
sunshine you are wise to wear sunglasses. Your eyes will
have less trouble adjusting to night. But if you're
driving, don't wear sunglasses at night. They may cut
down on glare from headlamps, but they also make a lot
of things invisible.
You can be temporarily blinded by approaching
headlamps. It can take a second or two, or even several
seconds, for your eyes to readjust to the dark. When you
are faced with severe glare (as from a driver who
doesn't lower the high beams, or a vehicle with
misaimed headlamps), slow down a little. Avoid staring
directly into the approaching headlamps.Keep your windshield and all the glass on your vehicle
clean
-- inside and out. Glare at night is made much
worse by dirt on the glass. Even the inside of the glass
can build up a film caused by dust. Dirty glass makes
lights dazzle and flash more than clean glass would,
making the pupils of your eyes contract repeatedly.
Remember that your headlamps light up far less of a
roadway when you are in a turn or curve. Keep your
eyes moving; that way, it's easier to pick out dimly
lighted objects. Just as your headlamps should be
checked regularly for proper aim, so should your eyes
be examined regularly. Some drivers suffer from night
blindness
-- the inability to see in dim light -- and aren't
even aware of it.
ProCarManuals.com

yellowblue
6-37
5. Remove the rubber access cover (from behind the
bulb you are replacing).
6. Quarter twist and turn the bulb socket and remove it
from the lamp.
7. Lift the plastic locking tab on the electrical
connector and pull the connector from the headlamp
bulb socket.
8. Connect the new headlamp bulb to the wiring harness,
making sure the connector tab snaps into place.
9. Insert the bulb socket into the headlamp assembly.10. Reverse all steps and reassemble the headlamp
assembly, then check the lamps.
Headlamp Aiming
Your vehicle has a headlamp system equipped with
horizontal and vertical aim indicators. The aim has been
pre
-set at the factory and should need no further
adjustment. This is true even though your vertical and
horizontal aim indicators may not fall exactly on the ª0º
(zero) marks on their scales.
If your vehicle is damaged in an accident, the headlamp
aim may be affected. Aim adjustment may be necessary
if it is difficult to see lane markers (for horizontal aim),
or if oncoming drivers flash their high beams at you (for
vertical aim). If you believe your headlamps need to be
re
-aimed, we recommend that you take it to your dealer
for service; however, it is possible for you to re
-aim
your headlamps as described in the following procedure.
NOTICE:
To make sure your headlamps are aimed
properly, read all the instructions before
beginning. Failure to follow these instructions
could cause damage to headlamp parts.
ProCarManuals.com

yellowblue
6-71
Replacement Bulbs
Exterior Lamps Bulb Number
Back
-Up 1156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stop 3155. . . . . . . . . . . . . . . .
Front Parking/Turn Signal 4175 NAK. . . . . . . . . . . . .
Headlamp, High Beam 9005. . . . . . . . . . . . . . . . . . . .
Headlamp, Low Beam 9006. . . . . . . . . . . . . . . . . . . .
Stop/Tail/Turn Signal 3057. . . . . . . . . . . . . . . . . . . . .
Tail (Applique) 194. . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Lamps BulbNumber
Dome Lamp 9425542. . . . . . . . . . . . . . . . . . . . . . . . .
*For service information on these bulbs, contact your
dealer service department.
Capacities and Specifications
4T65E:
Automatic Transaxle
Pan Removal and Replacement 7.4 quarts (7.0 L). .
After Complete Overhaul 10.0 quarts (9.5 L). . . . .
* When draining/replacing converter, more fluid will
be needed.
Cooling System Including Reservoir
3800 (Code K) V6 12.3 quarts (11.6 L). . . . . . . . . . .
3800 Supercharged (Code 1) V6 12.3 quarts (11.6 L)
Refrigerant (R
-134a), Air Conditioning*1.88 lbs.
(0.85 kg)
*See ªAir Conditioning Refrigerantsº later in this
section.
Engine Crankcase
Oil and Filter Change 4.5 quarts (4.3 L). . . . . . . . . . .
Wheel Nut Torque100 lb
-ft (140 N´m) . . . . . . . . . .
Fuel Tank17.5 gallons (66.2 L) . . . . . . . . . . . . . . . . .
*Note: All capacities are approximate. When adding, be
sure to fill to the approximate level, as recommended in
this manual. See ªRecommended Fluids and Lubricantsº
in the Index.
ProCarManuals.com

yellowblue
9-5
First Gear, Automatic Transaxle 2-26 . . . . . . . . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluids and Lubricants 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Parking and Turn Signal Lamp
Bulb Replacement 6
-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canadian 6-4, 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Full-Range Traction Control System 4-9 . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-66 . . . . . . . . . . . . . . . . . . . . . . .
Gages
Engine Coolant Temperature 2-66 . . . . . . . . . . . . . . . . . . . .
Fuel 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAWR 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions, Automatic Transaxle 2-22 . . . . . . . . . . . . . . . .
Glove Box 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Mobility Program for Persons with Disabilities 8-5 . . . . .
Gross Axle Weight Rating (GAWR) 4-32 . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating (GVWR) 4-32 . . . . . . . . . . . . . .
Guide en Fran†ais ii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR 4
-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Head Restraints 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps
Aiming 6
-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Bulb Replacement 6
-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flash-to-Pass 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam Changer 2-37 . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing Impaired, Customer Assistance 8-4 . . . . . . . . . . . . . .
Heated Seats 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heating 3-4, 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Beam Headlamps 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . .
Highway Hypnosis 4-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hill and Mountain Roads 4-25 . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches, Trailer 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood
Checking Things Under 6
-8 . . . . . . . . . . . . . . . . . . . . . . . . .
Release 6-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydroplaning 4-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Positions 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transaxle Lock Check 7-18 . . . . . . . . . . . . . . . . . . . .
Illuminated Entry 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation, Tire 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspections
Brake System 7
-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Cooling System 7-19 . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust System 7-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Drive Axle Boot 7-19 . . . . . . . . . . . . . . . . . . . . . . . . .
Front Drive Axle Seal 7-19 . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 7-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension 7-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle System 7-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com

yellowblue
9-7
Lockout Protection Feature 2-7 . . . . . . . . . . . . . . . . . . . . . .
Manual Door 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Door 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Programmable Automatic Power Door 2-5 . . . . . . . . . . . . .
Rear-Door Child Security 2-6 . . . . . . . . . . . . . . . . . . . . . . .
Trunk 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Window 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loss of Control 4-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low
Coolant Warning Light 2
-66, 6-27 . . . . . . . . . . . . . . . . . . . .
Fuel Light 2-75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Level Light 2-71, 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire Light 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction Light 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washer Fluid Warning Light 2-39, 2-73 . . . . . . . . . . . . . . .
Low-Beam Headlamps 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubricants and Fluids 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication Service, Body 7-16 . . . . . . . . . . . . . . . . . . . . . . . .
Magnetic Variable Effort Steering4-12 . . . . . . . . . . . . . . .
Maintenance, Normal Replacement Parts 6-73 . . . . . . . . . . . .
Maintenance Record 7-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance Schedule 7-1, 7-5 . . . . . . . . . . . . . . . . . . . . . . . .
How it's Organized 7-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction 7-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance Schedule, Recommended Fluids
and Lubricants 7
-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Owner Checks and Services 7-15 . . . . . . . . . . . . . . . . . . . . .
Periodic Maintenance Inspections 7-19 . . . . . . . . . . . . . . . .
Scheduled Maintenance Services 7-4 . . . . . . . . . . . . . . . . . .
Your Vehicle and the Environment 7-2 . . . . . . . . . . . . . . . . Maintenance, Underbody 6
-62 . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Trailer Towing 4-39 . . . . . . . . . . . . . . . . .
Malfunction Indicator Lamp 2-67 . . . . . . . . . . . . . . . . . . . . . .
Manual
Door Locks 2
-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Seat 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Methanol 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mirrors 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Dimming/Heated Outside Rearview 2-49 . . . . .
Convex Outside 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrochromic Day/Night 2-48 . . . . . . . . . . . . . . . . . . . . . .
Power Outside Foldaway 2-49 . . . . . . . . . . . . . . . . . . . . . . .
Visor Vanity 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMT 6-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mountain Roads 4-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Multifunction Lever 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Net, Trunk Convenience 2-52 . . . . . . . . . . . . . . . . . . . . . . . .
Neutral, Automatic Transaxle 2-24 . . . . . . . . . . . . . . . . . . . . .
New Vehicle ªBreak-Inº 2-17 . . . . . . . . . . . . . . . . . . . . . . . . .
Night Vision 4-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer 2-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer, Trip 2-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Offices, Customer Assistance 8-4 . . . . . . . . . . . . . . . . . . . . . .
Off-Road Recovery 4-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil, Engine 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Warning Light 2-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OnStar
2-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overdrive (
), Automatic 2-24, 2-25 . . . . . . . . . . . . . . . . . . .
ProCarManuals.com
