1999 BUICK REGAL brake light

yellowblue
v
For example,
these symbols
are used on an
original battery:
CAUTION
POSSIBLE
INJURY
PROTECT
EYES BY
SHIELDING
CAUSTIC
BATTERY
ACID COULD
CAUSE
BURNS
AVOID
SPARKS OR
FLAMES
SPARK OR
FLAME
COULD
EXPLODE
BATTERY
These symbols
are important
for you and
your passengers
whenever your
vehicle is
driven:
DOOR LOCK
UNLOCK
FASTEN
SEAT
BELTS
POWER
WINDOW
AIR BAG
These symbols
have to do with
your lamps:
MASTER
LIGHTING
SWITCH
TURN
SIGNALS
PARKING
LAMPS
HAZARD
WARNING
FLASHER
DAYTIME
RUNNING
LAMPS
FOG LAMPS
These symbols
are on some of
your controls:
WINDSHIELD
WIPER
WINDSHIELD
WASHER
WINDSHIELD
DEFROSTER
REAR
WINDOW
DEFOGGER
VENTILATING
FAN
These symbols
are used on
warning and
indicator lights:
ENGINE
COOLANT
TEMP
BATTERY
CHARGING
SYSTEM
BRAKE
COOLANT
ENGINE OIL
PRESSURE
ANTI-LOCK
BRAKES
Here are some
other symbols
you may see:
FUSE
LIGHTER
HORN
SPEAKER
FUEL
Vehicle Symbols
These are some of the symbols you may find on your vehicle.
ProCarManuals.com

2-
yellowblue
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-7 Remote Keyless Entry
2
-14 Trunk
2
-14 Theft
2
-15 PASS-Key
II
2
-17 New Vehicle ªBreak-Inº
2
-17 Ignition Positions
2
-19 Starting Your V6 Engine
2
-20 Engine Coolant Heater (If Equipped)
2
-22 Automatic Transaxle Operation
2
-27 Parking Brake
2
-28 Shifting Into PARK (P)
2
-30 Shifting Out of PARK (P)
2
-32 Parking Over Things That Burn
2
-33 Engine Exhaust
2
-33 Running Your Engine While You're Parked
2
-34 Windows2
-35 Horn
2
-35 TILT-WHEEL Adjustable Steering Column
2
-36 Turn Signal/Multifunction Lever
2
-42 Exterior Lamps
2
-45 Interior Lamps
2
-48 Mirrors
2
-50 Storage Compartments
2
-53 Sun Visors
2
-53 Accessory Power Receptacle
2
-54 Auxiliary Power Connection (Power Drop)
2
-55 Astroroof (If Equipped)
2
-55 OnStar
(Option)
2
-56 The Instrument Panel -- Your
Information System
2
-57 Instrument Panel Cluster
2
-60 Warning Lights, Gages and Indicators
2
-75 Driver Information Center
ProCarManuals.com

yellowblue
2-26
FIRST (1): This position gives you even more power
(but lower fuel economy) than SECOND (2). You can
use it on very steep hills, or in deep snow or mud. If the
shift lever is put in FIRST (1), the transaxle won't shift
into first gear until the vehicle is going slowly enough.
NOTICE:
If your front wheels can't rotate, don't try to
drive. This might happen if you were stuck in
very deep sand or mud or were up against a solid
object. You could damage your transaxle.
Also, if you stop when going uphill, don't hold
your vehicle there with only the accelerator
pedal. This could overheat and damage the
transaxle. Use your brakes or shift into PARK (P)
to hold your vehicle in position on a hill.
Driver Selectable Shift (If Equipped)
Press the driver selectable
shift button to allow the
transaxle to shift at higher
engine speeds, increasing
shift firmness and
acceleration performance.
The PERF SHIFT light on
your instrument panel
cluster will glow when the
driver selectable shifting
feature is in performance
shift mode.
Downshifts will occur at a lower percentage of
accelerator use while you're in the driver selectable
shift mode.
ProCarManuals.com

yellowblue
2-27
Press the button again to return to normal shifting. The
PERF SHIFT light will turn off when in normal shifting
mode. The transaxle will then shift at lower engine
speeds, increasing fuel economy.
Parking Brake
To set the parking brake,
hold the regular brake pedal
down with your right foot.
Push down the parking
brake pedal with your
left foot.
To release the parking brake, hold the regular brake
pedal down with your right foot and push the parking
brake pedal with your left foot. When you lift your left
foot, the parking brake pedal will follow it to the
released position.A warning chime will sound if the parking brake is set,
the ignition is on and the shift lever is not in PARK (P)
or NEUTRAL (N).
NOTICE:
Driving with the parking brake on can cause
your rear brakes to overheat. You may have to
replace them, and you could also damage other
parts of your vehicle.
If you are towing a trailer and parking on any hill, see
ªTowing a Trailerº in the Index. That section shows
what to do first to keep the trailer from moving.
ProCarManuals.com

yellowblue
2-39 Windshield Washer
At the top of the multifunction lever, there's a paddle
with the word PUSH on it. To spray washer fluid on the
windshield, push the paddle. The wipers will run for
several sweeps and then either stop or return to your
preset speed. See ªWindshield Washer Fluidº in
the Index.
CAUTION:
In freezing weather, don't use your washer until
the windshield is warmed. Otherwise the washer
fluid can form ice on the windshield, blocking
your vision.
The LOW WASH light on
your instrument panel
cluster will glow when the
fluid level is low.
Cruise Control (If Equipped)
With cruise control, you can maintain a speed of about
25 mph (40 km/h) or more without keeping your foot on
the accelerator. This can really help on long trips.
Cruise control does not work at speeds below about
25 mph (40 km/h).
When you apply your brakes, the cruise control
shuts off.
ProCarManuals.com

yellowblue
2-42
Using Cruise Control on Hills
How well your cruise control will work on hills depends
upon your speed, load and the steepness of the hills.
When going up steep hills, you may have to step on the
accelerator pedal to maintain your speed. When going
downhill, you may have to brake or shift to a lower gear
to keep your speed down. Of course, applying the brake
takes you out of cruise control. Many drivers find this to
be too much trouble and don't use cruise control on
steep hills.
Ending Cruise Control
There are two ways to turn off the cruise control:

Step lightly on the brake pedal; OR

Move the cruise switch to OFF.
Erasing Cruise Speed Memory
When you turn off the cruise control or the ignition, or
shift into PARK (P) or NEUTRAL (N), your cruise
control set speed memory is erased.Exterior Lamps
The lamp controls are located on the instrument panel.
They control these systems:

Headlamps

Taillamps

Parking Lamps

License Lamps

Sidemarker Lamps

Instrument Panel Lights

Courtesy Lamps

Fog Lamps

Cornering Lamps
ProCarManuals.com

yellowblue
2-43
If you pull the knob out
halfway, it will turn on your
parking lamps and your
other operating lamps. If
you pull the knob all the
way out, your headlamps
will then come on.
Push the knob in all the way to turn off the lamps.
A warning chime will sound if you open the driver's
door when you turn the ignition switch to OFF, LOCK
or ACCESSORY with the lamps on.
Daytime Running Lamps / Automatic
Headlamp Control
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.A light sensor on top of the instrument panel makes the
DRL work, so be sure it isn't covered.
The DRL system will make your front turn signal lamps
come on when:

the ignition is on,

the headlamp switch is off and

the parking brake is released.
When the DRL are on, only your front turn signal lamps
will be on. The headlamps, taillamps, sidemarker and
other lamps won't be on. Your instrument panel won't
be lit up either.
When it's dark enough outside, your front turn signal
lamps will turn off and your vehicle's headlamps and
parking lamps will turn on. The other lamps that come
on with your headlamps will also come on.
When it's bright enough outside, your headlamps will go
off and your front turn signal lamps will come on.
To idle your vehicle with the DRL off, set the parking
brake while the ignition is in OFF or LOCK. Then start
your vehicle. The DRL, headlamps and parking lamps
will stay off until you release the parking brake.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
ProCarManuals.com

yellowblue
2-47
You may enable or disable the perimeter lighting feature
when the driver performs the following sequence with
the engine not running, the doors closed and the ignition
key in RUN:
1. Apply your brakes.
2. Press and hold the power door lock switch. While
holding the door lock switch press and release the
remote alarm button on the remote keyless entry
transmitter. This will initialize the customization
mode. While in the customization mode, the feature
will sound the number of chimes corresponding to
the current mode: In Mode 1, one chime means the
feature is disabled. In Mode 2, two chimes signal
that the perimeter lighting feature is enabled. Each
additional press will advance the mode by one,
starting from the current mode. During this
procedure, the feature will sound the number of
chimes corresponding to the mode. When the lock
switch is released, the vehicle will remain in the
last mode.
Disconnecting the vehicle's battery for up to a year will
not change the programmed operation of this feature.Rearview Mirror Reading Lamps
Use the switch next to each lamp to turn them on
and off.
Dome Lamp (If Equipped)
The dome lamp will come on when you open the doors.
ProCarManuals.com
