1999 BUICK CENTURY Owner's Manual

yellowblue
6-59 Headlamp Wiring
The headlamp wiring is protected by a circuit breaker in
the underhood electrical center. An electrical overload
will cause the lamps to go on and off, or in some cases
to remain off. If this happens, have your headlamp
system checked right away.
Windshield Wipers
The windshield wiper motor is protected by a circuit
breaker and a fuse. If the motor overheats due to heavy
snow, etc., the wiper will stop until the motor cools. If
the overload is caused by some electrical problem, have
it fixed.
Power Windows and Other Power Options
Circuit breakers in the fuse panel protect the power
windows and other power accessories. When the current
load is too heavy, the circuit breaker opens and closes,
protecting the circuit until the problem is fixed.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers
and fusible thermal links in the wiring itself. This
greatly reduces the chance of fires caused by
electrical problems.Look at the silver
-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical size
and rating.
Instrument Panel Fuse Block
Some fuses are located in a
fuse block on the
passenger's side of the
instrument panel. Pull off
the cover labeled FUSES to
expose the fuses.

yellowblue
6-60
Circuit
BreakerDescription
A Tire Inflation Monitor Reset Button
B Power Windows/Sunroof
C Rear Defog
D Power SeatsFuse Description
1 Not Used
4 Ignition Signal
-- Hot in Run and
Start
-- PCM, BCM U/H Relay
5 Remote Radio Premium Sound
6 Power Mirrors
8 Panel Dimming
10 Ignition Signal
-- Hot in Run, Unlock and
Start
-- Cluster, Powertrain Control
Module, Body Control Module
13 DRL Module
14 Interior Lamps
15 Door Locks
17 Taillamps, License Lamp
18 Radio
19 Heated Mirror
20 Cruise Control
22 Clusters
23 Cigarette Lighter
-- Auxiliary Power
Connection (Power Drop), Data Link

yellowblue
6-61
Fuse Description
24 Stoplamps
26 Parking Lamps
27 Auxiliary Power Connection
(Power Drop)
-- Hot in ACC and Run
28 Crank Signal
-- Body Control Module,
Cluster, Powertrain Control Modules
29 Ignition Signal
-- HVAC Control Head
30 Brake Transmission Shift Interlock (BTSI)
31 Air Bag
32 Body Control Module
33 Hazard Flashers
34 Not UsedFuse Description
36 Ignition Signal
-- Hot in ACC and
Run
-- Body Control Module
38 Low Blower
39 Anti
-Lock Brakes
40 Turn Signals
41 Radio, HVAC Head, Remote Keyless
Entry, Cluster
42 High Blower
43 Not Used
44 Audio Steering Wheel Controls
45 Wipers

yellowblue
6-62
Underhood Electrical Center -- Passenger's Side
Some fuses and relays are located in the underhood
electrical center on the passenger's side of the
engine compartment.Fuse Description
1 ABS
2 Starter Solenoid
3 Power Seats, Rear Defog
4 High Blower, Hazard Flasher,
Stoplamps, Power Mirror, Door Locks
5 Ignition Switch, BTSI, Stoplamps,
ABS, Turn Signals, Cluster, Air Bag,
DRL Module
6 Cooling Fan
7 Interior Lamps, Retained Accessory
Power, Keyless Entry, Data Link, HVAC
Head, Cluster, Radio, AUX Power
(Power Drop), Cigarette Lighter
8 Ignition Switch, Wipers, Radio, Steering
Wheel Controls, Body Control Module,
AUX Power (Power Drop), Power
Windows, Sunroof, HVAC Controls,
DRL, Rear Defog Relay

yellowblue
6-63
Relay Description
9 Cooling Fan 2
10 Cooling Fan 3
11 Starter Solenoid
12 Cooling Fan 1
13 Ignition Main
14 Not Used
15 A/C Clutch
16 Horn
17 Not Used
18 Not Used
19 Fuel Pump
20 Not Used
21 Generator
22 ECM
23 A/C Compressor Clutch
24 Cooling Fan
25 Electronic Ignition
26 TransaxleFuse Description
27 Horn
28 Fuel Injector
29 Oxygen Sensor
30 Engine Emissions
31 Not Used
32 Headlamp (Right)
33 Rear Compartment Release
34 Parking Lamps
35 Fuel Pump
36 Headlamp (Left)
37 Spare
38 Spare
39 Spare
40 Spare
41 Spare
42 Spare
43 Fuse Puller
SYMBOL A/C Compressor Clutch Diode

yellowblue
6-64
Replacement Bulbs
Exterior Lamps Bulb Number
Back
-up 1156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stop 3155. . . . . . . . . . . . . . .
Front Parking/Turn Signal 4157NAK. . . . . . . . . . .
Headlamp, High Beam 9005. . . . . . . . . . . . . . . . . .
Headlamp, Low Beam 9006. . . . . . . . . . . . . . . . . . .
Stop/Tail/Turn Signal 3057. . . . . . . . . . . . . . . . . . .
Tail (Applique) 194. . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps Bulb Number
Dome Lamp 9425542. . . . . . . . . . . . . . . . . . . . . . .
*For service information on these bulbs, contact your
dealer service department.
Capacities and Specifications
4T60E:
Automatic Transaxle
Pan Removal and Replacement 7.0 quarts (6.7 L). . .
After Complete Overhaul 9.6 quarts (9.2 L). . . . . .
* When draining/replacing converter, more fluid will
be needed.
Cooling System Including
Reservoir 11.6 quarts (10.9 L) . . . . . . . . . . . . . . . . .
Refrigerant (R
-134a),
Air Conditioning*1.88 lbs. (0.85 kg) . . . . . . . . . . .
*See ªAir Conditioning Refrigerantsº later in
this section.
Engine Crankcase
Oil and Filter Change 4.5 quarts (4.3 L). . . . . . . . .
Wheel Nut Torque100 lb
-ft (140 N´m) . . . . . . . . . .
Fuel Tank17.5 gallons (66.2 L) . . . . . . . . . . . . . . . . .
*Note: All capacities are approximate. When adding, be
sure to fill to the approximate level, as recommended in
this manual. See ªRecommended Fluids and Lubricantsº
in the Index.

yellowblue
6-65 Engine Specifications
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 191 CID. . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-6 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) . . . . . . . . . . .
Horsepower 160 @ 5200. . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same. If the
air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used. If
you're not sure, ask your dealer.
Normal Maintenance
Replacement Parts
Engine/Air Cleaner Filter AC Type A1208C . . . . .
Passenger Compartment Air Filter 10406026 . . . .
Battery AC Type 600 CCA . . . . . . . . . . . . . . . . . . . .
Engine Oil Filter AC Type PF47 . . . . . . . . . . . . . . . PCV Valve AC Type CV892C . . . . . . . . . . . . . . . . . .
Radiator Cap AC Type RC27 . . . . . . . . . . . . . . . . . .
RKE Batteries Type CR2032 (2) or equivalent . . . .
Spark Plugs
3100 (Code M) V6 AC Type 41
-940 . . . . . . . . . . . .
Gap: 0.060 inches (1.52 mm) . . . . . . . . . . . . . . . . . .
Wiper Blade
Type Hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 22 inches (56 cm). . . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Wheelbase 109.0 inches (276.9 cm). . . . . . . . . . . . . .
Tread (Front) 62.0 inches (157.6 cm). . . . . . . . . . . . .
Tread (Rear) 61.1 inches (155.3 cm). . . . . . . . . . . . . .
Overall Length 194.6 inches (494.2 cm). . . . . . . . . . .
Overall Width 72.7 inches (184.5 cm). . . . . . . . . . . . .
Overall Height 56.6 inches (143.8 cm). . . . . . . . . . . .

yellowblue
6-66
-NOTES
