Self-levelling suspension, A6
The compressor
The compressed air is generated by means of
a single stage piston compressor with
integrated air dryer. In order to avoid oil
contamination of the U-bellows and the dryer
cartridge, the compressor is a so-called dry
running compressor.
Permanently lubricated bearings and a PTFE
(polytetraßuoroethylene) piston ring ensure a
long service life.The discharge valve N111 and the pneumatic
discharge valve are integrated into the dryer
cartridge housing.
In order to protect the compressor from
overheating, it switches off at excess
temperatures (see Overheating protection
chapter, page 61).
Discharge valve N11Pneumatic discharge valve
with pressure limiting valve
Non-return valve 3Air dryer
Non-return valve 1
PTFE piston ring
Suction Þlter
Discharge Þlter
Pressure connector
242_013
Non-return valve 2
61
Overheating protection
In order to protect the compressor from
overheating, it switches off at excess
temperatures.
A temperature module is integrated into the
control unit. This monitors the temperature
and is used to calculate the compressor
temperature.
The calculations are based on the running
and cooling times of the compressor.
The max. running time is limited to 120 sec.
(an fault entry is made in the control unit
whenever the maximum running time is
exceeded).
15 seconds running time are allowed
following every 6 minutes of cooling time.
After 48 minutes of cooling time the
maximum running time of 120 seconds is
available.
242_011
Battery protection
In order to protect the battery, the maximum
running time of the compressor is limited to
60 seconds after the ignition has been
switched ÒOFFÓ. The system switches off and
only reactivates after the ignition has been
switched ÒONÓ again.
Switching self-levelling on/off.
The system can be switched off using the
diagnostic tester, e.g. during repair work.
When the ignition is switched ÒONÓ, the
systemÕs off status is indicated by a ßashing
warning lamp (T34).
At a driving speed of >20 km/h the system is
activated automatically.
198_039242_085
