1998 Volvo S90
NOTE: Canadian model
speedometers/odometers
indicate kilometers only.

1 Ambient temperature
indicator (certain models)

Indicates the temperature
slightly above the surface of the
road. An amber warning lamp
lights up when the temperature
is in the range of 23-36° F (-5 -
+ 2° C). At low speeds or when
the car is not moving, the
temperature readings may be
slightly higher than the actual
ambient temperature due to heat
generated by the engine.

2 Fuel gauge

The total fuel tank capacity is
approx. 21.1 US gal. (80 liters).
The "usable" capacity is 20.3
US gal. (77 liters). When the
warning light comes on, there
are approximately 1.6 US gal. (6
liters) of fuel remaining in the
tank. See "Refueling" for further
information.3 Quartz crystal clock/
clock set button

Press the button and turn to set
the clock.

4 Speedometer

5 Odometer

6 Trip odometer/reset
button

Used for measuring shorter
distances. The last digit
indicates 1/10 mile/kilometer.

7 Tachometer

Reads thousands of engine rpm.
Engine should not be operated
in red range.
8 Temperature gauge

Do not drive the car with the
pointer in the red range. The
pointer should be approximately
midway on the gauge face when
driving. If the pointer approaches
the red range repeatedly, check
coolant level. See page 118.
WARNING! Allow engine to
cool before adding coolant.




Contents | Top of Page
file:///K|/ownersdocs/1998/1998_SV90/98S90_014.htm (3 of 3)12/30/2006 \
1:52:36 PM

1998 Volvo S90
cold-weather oil for hard driving or in warm
weather. See section "Engine oil" for more
information.
l The load placed on the battery is greater during
the winter since the heater, windshield wipers,
lighting etc. are used more often. Moreover, the
capacity of the battery decreases as the
temperature drops. In very cold weather, a poorly
charged battery can freeze and be damaged. It is
therefore advisable to check the state of charge
more frequently and spray an anti-rust oil on the
battery posts.
l Volvo recommends the use of snow tires on all
four wheels for winter driving - see section
"Wheels and tires".
l To prevent the washer reservoir from freezing,
add washer solvents containing antifreeze. This is
important since dirt is often splashed on the
windshield during winter driving, thus requiring
frequent use of the washers and wipers.
functions when the transmission is in reverse.
Also see "Winter/Wet" mode on page 59.

Winter/Wet mode

Enhanced Vehicle Traction
This mode may be selected for starting/moving
off on slippery roads or to lower downshift speeds
if the transmission is in "L".
Mode W
*In position D, the gearbox starts in third gear and
changes up to fourth gear.
*In position 3, second gear is locked and there is
no change up to third gear. In position L, first gear
is locked.

*These positions always offer the kick-down
feature.
Long distance trip pg. 70


Before a long distance trip

It is always worthwhile to have your car checked at a Volvo retailer
before driving long distances. Your retailer will also be able to supply\

you with bulbs, fuses, spark plugs and wiper blades for your use in the \
event that problems occur.

If you prefer to check the car yourself, please note the following:
l Check that the engine runs smoothly and that fuel consumption is
normal.
l Check engine oil, coolant levels, and for possible fuel leakage.
l Check transmission oil level and rear axle for leakage.
l Check condition of drive belts.
l Check state of charge of battery.
l Examine tires carefully (the spare tire as well), and replace those
that are worn. Check tire pressures.
l The brakes, front wheel alignment, and steering gear should be
checked by your Volvo retailer only.
l Check all lights, including high beams.

file:///K|/ownersdocs/1998/1998_SV90/98S90_067.htm (4 of 5)12/30/2006 \
1:52:43 PM

1998 Volvo S90

Check coolant level

The cooling system must be filled with
coolant and not leak to operate at maximum
efficiency. Check the coolant level regularly.
The level should be between the "Max" and
"Min" marks on the expansion tank. The
check should be made with particular
thoroughness when the engine is new or
when the cooling system has been drained.
Do not remove the filler cap other than for
topping-up with coolant. Frequent removal
may prevent coolant circulations between the
engine tank during engine warm-up and
cooling.
filling.
Add coolant until the level is up to
the MAX mark or slightly above.
Start the engine and run until hot.
Check the cooling system
connections for tightness. Also re-
check the coolant level.
Capacity: See "Specifications"
coolant: Volvo Genuine Coolant/
Antifreeze only

CAUTION
The cooling system must
always be kept filled to correct
level.
If it is not kept filled, there can
be high local temperatures in
the engine which could result
in damage.
Different types of anti-freeze/
coolant may not be mixed.
Adjusting washer nozzles, Washer fluid reservoir pg. 119


Adjusting washer nozzles

The washer jets should spray the windshield as shown. Use
the edge of a small screwdriver to adjust the nozzles, if
necessary. Please use caution to avoid damaging the
paintwork.


Washer fluid reservoir

The washer fluid reservoir is located in the engine
compartments and holds approx. 0.5 US gal. (2 liters) -
sedans and 0.8 US gal (3.2 liters) - wagons. During cold
weather, the reservoir should be filled with windshield
washer solvent containing anti-freeze.


file:///K|/ownersdocs/1998/1998_SV90/98S90_114.htm (4 of 5)12/30/2006 \
1:52:50 PM

1998 Volvo S90
Cooling System

Type: Positive pressure, closed system
Thermostat-begins to open at 186°F (87°C)

Coolant: Volvo Genuine Coolant/Anti-freeze

Capacity: 10.5 qts (10 liters)

Fuel system

The engine is equipped with a multiport fuel injection system

Distributor ignition System

Firing order / 1-5-3-6-2-4 Distributor ignition setting / Not adjustable\

Spark plugs / Bosch FR 6 DC (or equivalent)
Spark plug gap / 0.024-0.028" (0.6-0.7 mm)
Tightening torque / 17.3-20.3 ft. lbs. (23-27 Nm)
