'98 Rav4U
2
Instrument panel overview
1. Side vents
2. Instrument cluster
3. Center vents
4. Electric moon roof switch and personallights
5. Glovebox
6. Power door lock switches
7. Power window switches
8. Parking brake lever
9. Automatic transmission selector lever or manual transmission gear shift lever
10. Ashtray 11. Hood lock release lever

'98 Rav4.U7
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1- 2
Keys and Doors
Keys
Side doors
Power windows
Quarter window

Back door and tail gate

Hood
Fuel tank cap
Electric moon roof
Detachable sun roof
Soft- top
Keys
Your vehicle is supplied with two kinds
of key. 1. Master keyÐThis key works in every lock.
2. SubkeyÐThis key will not work in the glovebox.
To protect things locked in the glovebox
when you have your vehicle parked, leave
the subkey with the attendant.
Since the side doors, back door (hardtop)
and tail gate (soft- top) can be locked
without a key, you should always carry a
spare master key in case you accidentally
lock your keys inside the vehicle. KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
You should also put a copy of the key
number with your important papers.

'98 Rav4U
24
2. Lock the latch handle and hook.3. Fold the soft- top. Make sure to place the soft- top between the rear
seat backs and tail gate.
CAUTION
With the soft- top opened, when the
rear seat is in the reclined position
or when reclining the rear seat, be
careful not to damage the soft- top
and not to get your head hit or in-
jured by the latch handles.
4. Take the latch handle cover out ofthe glovebox, put it over the latch
handle and fasten it securely with
Ve l c r o s .

'98 Rav4.U25
ÐRaising the soft- top
RAISING THE SOFT- TOP
1. Remove the latch handle cover.
Store the removed cover in the glove-
box.2. Raise the soft- top.
CAUTION
When raising the soft- top, keep
hands clear from any parts of the top
linkage.
3. Separate the latch handle and hook while pressing the lock release but-
ton.

'98 Rav4.U71
On the luggage compartment floor
a. Using the illustration as a guide, run
your fingers across the luggage compart-
ment floor itself to locate the position of
the bolts underneath.
b. Remove the bolt.
c. Insert a 10 mm (0.4 in.) spacer and
tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5Ð24.7 N
Vm (1.68Ð2.52
kgf Vm, 12.2Ð18.2 ft Vlbf).
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Canada
are provided with a bracket set in the
glovebox, designed for use with any of the
2 anchor locations shown in the illustra-
tion.
If your child restraint system does not
provide any of the necessary parts, ask
your Toyota dealer. (See ºÐChild restraint
systemº.)
If you remove the anchor brackets when
the child restraint system is necessary no
longer, replace the bolts in the holes to
prevent entry of exhaust emissions, water
or dirt. Tilt steering wheel
Ty p e A
Ty p e BTo change the steering wheel angle,
hold the steering wheel, push down the
lock release lever, tilt the steering
wheel to the desired angle and release
the lever.
CAUTION

Do not adjust the steering wheel
while the vehicle is moving.
After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.

'98 Rav4U
126
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1- 8
Other equipment
Clock
Cigarette lighter and ashtray
Power outlet
Glovebox
Auxiliary box
Floor mat
Clock
The digital clock indicates the time.
The key must be in the ºACCº or ºONº
position.
To reset the hour: Push the ºHº button.
To reset the minutes: Push the ºMº button.
If quick adjustment to a full hour is de-
sired, push the º:00º button.
For example, if the º:00º button is de-
pressed when the time is between
1:01Ð1:29, the time will change to 1:00.
If the time is between 1:30Ð1:59, the
time will change to 2:00.
If the electrical power source has been
disconnected from the clock, the time dis-
play will automatically be set to 1:00 (one
o'clock).
When the instrument panel lights are
turned on, the brightness of the time in-
dication will be reduced.

'98 Rav4U
128
NOTICE
To prevent the fuse from being blown, do not use the electricityover the total vehicle capacity of 12V/120W.
To prevent the battery from beingdischarged, do not use the power outlet longer than necessary when
the engine is not running.
Close the power outlet lid when thepower outlet is not in use. Insertinga foreign object other than the ap- propriate plug that fits the outlet,
or allowing any liquid into the out-let may cause electrical failure or
short circuits.
Glovebox
To use the glovebox, do this.
To open: Pull the lever.
To lock: Insert the master key and turn it
clockwise.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glovebox door closed
while driving.
Auxiliary box
2- door hardtop and soft- top (left side)
2- door hardtop and soft- top (right side),
and 4- door hardtop
