deploys.
* After air bag deploys, air bag surface may contain deposits
of sodium hydroxide, which irritate skin. Always wear safety
glasses, rubber gloves and long-sleeved shirt during clean
up. Wash hands using mild soap and water. Follow correct
clean-up and disposal procedures.
* Because of critical system operating requirements, DO NOT
service any SRS components. Repairs are only made by
replacing defective part(s).
* DO NOT allow any electrical source near inflator on the back
of air bag module.
* When carrying live air bag module, trim cover should be
pointed away from body to minimize injury in case of
accidental air bag deployment.
* If SRS is not fully functional for any reason, DO NOT drive
vehicle until system is repaired and is fully functional. DO
NOT remove bulbs, modules, sensors or other components, or in
any way disable system from operating normally. If SRS is not
functional, park vehicle until repairs are made.
REMOVAL & INSTALLATION
STEERING WHEEL
WARNING: Wait at least 60 seconds after disconnecting negative
battery cable before servicing SRS. System reserve capacitor
maintains SRS voltage for about 60 seconds after battery is
disconnected. Servicing SRS before 60-second period may
cause accidental air bag deployment and possible personal
injury.
Removal
Disable air bag. See DISABLING & ACTIVATING AIR BAG SYSTEM .
Ensure steering wheel is straight ahead. Remove air bag. Place
reference mark on steering wheel and steering column shaft for
installation reference. Remove steering wheel nut and washer. Using
steering wheel puller, remove steering wheel.
CAUTION: DO NOT hammer on steering wheel during removal or
installation, as it may damage steering column.
Installation
To install, reverse removal procedure. Ensure reference marks
are aligned. Tighten fasteners to specification. See
TORQUE SPECIFICATIONS . Activate air bag. See DISABLING & ACTIVATING
AIR BAG SYSTEM.
COMBINATION SWITCH
CAUTION: When installing steering wheel, if rotating part of
clockspring is not properly centered with steering column
and front wheels, clockspring failure will result.
Removal & Installation
Remove lower instrument cover and lower heater duct. Remove
air bag and steering wheel. See STEERING WHEEL under
REMOVAL & INSTALLATION . Remove upper and lower steering column covers.
Disconnect clockspring electrical connector. Remove screws attaching
colckspring and remove clockspring. Disconnect combination switch
electrical connectors. Remove screws and combination switch. To
install, reverse removal procedure.

Fig. 7: Brakes, Steering, & Suspension
Fig. 8: Air Conditioning, Heater & Ventilation

Heater Circuit
ANTI-LOCK BRAKES

Fires With Key Flywheel runout contributes
released. Engine to the intermittent nature
Fires and Cranks
Normally









\









\









\









\









\









\









\







AIR CONDITIONING & HEAT
AIR CONDITIONING TROUBLE SHOOTING
WARNING: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
BASIC AIR CONDITIONING TROUBLE SHOOTING CHART









\









\









\









\









\









\









\







CONDITION POSSIBLE CAUSE








\









\









\









\









\









\









\







Compressor Not Working
Compressor clutch circuit open.

Compressor clutch coil inoperative.

Poor clutch ground connection.

Fan belts loose.

Thermostatic switch inoperative.

Thermostatic switch not adjusted.

Ambient temperature switch open.

Superheat fuse blown.








\









\









\









\









\









\









\







Excessive Noise or Vibration
Missing or loose mounting bolts.

Bad idler pulley bearings.

Fan belts not tightened correctly.

Compressor clutch contacting body.

Excessive system pressure.

Compressor oil level low.

Damaged clutch bearings.

Damaged reed valves.

Damaged compressor.








\









\









\









\









\









\









\







Insufficient or No Cooling;
Compressor Working
Expansion valve inoperative.

Heater control valve stuck open.

Low system pressure.

Blocked condenser fins.

Blocked evaporator fins.

Vacuum system leak.

Vacuum motors inoperative.

Control cables improperly adjusted.

Restricted air inlet.

Mode doors binding.

Blower motor inoperative.

Temperature above system capacity.








\









\









\









\









\









\









\







HEATER SYSTEM TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to

problem symptoms. For model-specific Trouble Shooting,
refer to DIAGNOSTIC, or TESTING articles available in the
section(s) you are accessing.
BASIC HEATER SYSTEM TROUBLE SHOOTING CHART









\









\









\









\









\









\









\







CONDITION POSSIBLE CAUSE








\









\









\









\









\









\









\







Insufficient, Erratic,
or No Heat
Low Coolant Level

Incorrect thermostat.

Restricted coolant flow through
heater core.


Heater hoses plugged.

Misadjusted control cable.

Sticking heater control valve.

Vacuum hose leaking.

Vacuum hose blocked.

Vacuum motors inoperative.

Blocked air inlet.

Inoperative heater blower motor.

Oil residue on heater core fins.

Dirt on heater core fins.








\









\









\









\









\









\









\







Too Much Heat
Improperly adjusted cables.

Sticking heater control valve.

No vacuum to heater control valve.

Temperature door stuck open.








\









\









\









\









\









\









\







Air Flow Changes During
Acceleration
Vacuum system leak.

Bad check valve or reservoir.








\









\









\









\









\









\









\







Air From Defroster At All
Times
Vacuum system leak.

Improperly adjusted control cables.

Inoperative vacuum motor.








\









\









\









\









\









\









\







Blower Does Not Operate
Correctly
Blown fuse.

Blower motor windings open.

Resistors burned out.

Motor ground connection loose.

Wiring harness connections loose.

Blower motor switch inoperative.

Blower relay inoperative.

Fan binding or foreign object
in housing.


Fan blades broken or bent.








\









\









\









\









\









\









\







BRAKES
BRAKE SYSTEM TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.

Water Pump Malfunction Replace Water Pump
Fan Clutch Malfunction Replace Fan Clutch
Retarded Ignition Timing Reset Ignition Timing
Cooling Fan Malfunction Test Cooling Fan/
Circuit
Cooling Fan Motor
Malfunction Test Fan Motor
Cooling Fan Relay
Malfunction Test Fan Relay
Faulty Radiator Cap Replace Radiator Cap
Broken/Slipping Fan Belt Replace Fan Belt
Restricted Exhaust Repair Exhaust System









\









\









\









\









\









\









\







Corrosion Impurities In Coolant Clean/Flush System








\









\









\









\









\









\









\







Coolant Leakage Damaged hose Replace Hose
Leaky Water Pump Replace Water Pump
Damaged Radiator Seam Replace/Repair Radiator
Leaky Thermostat Cover Replace Thermostat
Cover
Cylinder Head Problem Check Head/Head Gasket
Leaky Freeze Plugs Replace Freeze Plugs









\









\









\









\









\









\









\







Recovery System Inoperative
Loose and/or Defective
Radiator Cap Replace Radiator Cap
Overflow Tube Clogged
and/or Leaking Repair Tube
Recovery Bottle Vent
Restricted Clean Vent









\









\









\









\









\









\









\







No Heater Core Flow
Collapsed Heater Hose Replace Heater Hose
Plugged Heater Core Clean/Replace Heater
Core
Faulty Heater Valve Replace Heater Valve









\









\









\









\









\









\









\







GASOLINE ENGINE - MECHANICAL TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
