1998 LINCOLN TOWN CAR Owners Manual

toCompass calibration
adjustment.
Most geographic areas (zones)
have a magnetic north compass
point that varies slightly from the
northerly direction on maps. This
variation is four degrees between
adjacent zones and will become
noticeable as the vehicle crosses
multiple zones. A correct zone
setting will eliminate this error.
Refer toCompass zone
adjustment.
Compass zone adjustment
1. Determine which magnetic zone
you are in for your geographic
location by referring to the zone
map.
2. Locate the compass module
mounted on the center rear view
mirror post.
3. Turn ignition to the ON position.
4. Press and hold the reset control
located on top of the compass
module until the message center
display changes to show the
current zone setting.
5. Release the reset control, then
slowly press down again. Press the
control repeatedly until the correct
zone setting for your geographic
location is displayed on the
message center.
6. To exit the zone setting mode,
release pressure from the switch
for greater than ten seconds.
1
2
3
4
5
6
7891011121314 15
Instrumentation
18

Compass calibration adjustment
Perform this adjustment in an
open area free from steel
structures and high voltage lines.
For optimum calibration, turn off
all electrical accessories (heater/air
conditioning, wipers, etc.) and
make sure all vehicle doors are
shut.
1. Start the vehicle.
2. Locate the compass module
mounted on the center rear view
mirror post.
3. Press and hold the reset control
for 2 to 4 seconds until CIRCLE
SLOWLY is displayed on the
message center.
4. Release pressure from the
control.
5. Slowly drive the vehicle in a
circle (less than 5 km/h [3 mph])
until the CIRCLE SLOWLY
indicator turns off. This will take
up to five circles to complete
calibration.
6. The compass is now calibrated.
Message center functions
FUEL ECON AVG
Select this function to display your
average fuel economy in liters/100
km or miles/gallon.
If you calculate your average fuel
economy by dividing liters of fuel
used by 100 kilometers traveled
(miles traveled by gallons used),
your figure may be different than
TRUNK AJAR DOOR AJAR
TRAC OFF AIR SUSPENSION
O/D OFF TRAC ACTIVE
SPEED CONTROL COMPASSkmCIRCLE
SLOWLY
FUEL ECON AVG
FUEL REMAIN
DIST TO EMPTY
AVG SPEED
TRIP A B
E/M
Instrumentation
19

displayed for the following reasons:
²your vehicle was not perfectly
level during fill-up
²differences in the automatic
shut-off points on the fuel
pumps at service stations
²variations in top-off procedure
from one fill-up to another
²rounding of the displayed values
to the nearest 0.1 liter (gallon)
Checking your highway fuel
economy using the electronic
message center display
The following procedure will allow
you to accurately monitor your
actual highway fuel economy. Since
this procedure requires the vehicle
speed control system to be set to
highway speeds, it must be run
only on suitable roadways where
long distance speed control can be
safely maintained.
You may notice gradual
improvement in fuel economy over
the course of your vehicle's
break-in period (approximately 1
600 kilometers [1 000 miles]).
1. Set the speed control. Refer to
Speed controlin theControls and
featureschapter.
2. Select FUEL ECON AVERAGE.
FUEL ECON AVG
FUEL REMAIN
DIST TO EMPTY
AVG SPEED
TRIP A B
E/M
Instrumentation
20

3. Press the RESET control to
clear the system memory.
²Actual highway fuel economy
is now displayed.This current
average measure will change as
the speed control system
changes the engine speed to
maintain a constant vehicle
speed. This is most noticeable in
hilly environments.
4. Drive the vehicle at least 8 km
(5 miles) with the speed control
system engaged to display a
stabilized average.
5. Record the highway fuel
economy for future reference.
It is important to press the RESET
control after setting the speed
control to get accurate highway
fuel economy readings.
FUEL REMAIN
This function shows how many
liters (gallons) of fuel you have left
in the fuel tank. If the fuel level is
above 71.9 liters (19 gallons), the
letter ªFº (full) will appear on the
display. If the fuel level is below 4
liters (1 gallon), the letter ªEº will
appear in the display.
DIST TO EMPTY (DTE)
This function estimates
approximately how far you can
drive with the fuel remaining in
your tank under normal driving
conditions. Remember to turn the
ignition OFF when refueling your
vehicle. Otherwise, the display will
SELECT
RESET
FUEL ECON AVG
FUEL REMAIN
DIST TO EMPTY
AVG SPEED
TRIP A B
E/M
FUEL ECON AVG
FUEL REMAIN
DIST TO EMPTY
AVG SPEED
TRIP A B
E/M
Instrumentation
21

not show the addition of fuel for a
few kilometers (miles).
The DTE function will flash for 5
seconds and sound a tone for 1
second when you have
approximately:
²80 km (50 miles) left before
you run out of fuel
²40 km (25 miles)
²16 km (10 miles)
If ªCOº or ªCSº is displayed, there
is a problem with the fuel
indication system and you should
contact your dealer for service as
soon as possible.
AVG SPEED
To use this function, select AVG
SPEED and press the RESET
control. Your average speed from
that point will be displayed until
RESET is pressed again.
TRIP A B
These two functions allow you to
see how far you have traveled
since you last reset. Trip A and
Trip B are completely independent
and must be reset individually.
To reset either trip feature to zero,
press the RESET control while the
appropriate trip distance feature
(A or B) is displayed.
FUEL ECON AVG
FUEL REMAIN
DIST TO EMPTY
AVG SPEED
TRIP A B
E/M
FUEL ECON AVG
FUEL REMAIN
DIST TO EMPTY
AVG SPEED
TRIP A B
E/M
SELECT
RESET
Instrumentation
22

E/M
When this function is displayed,
press the RESET control to change
the message center display from
metric to English units or from
English to metric units.FUEL ECON AVG
FUEL REMAIN
DIST TO EMPTY
AVG SPEED
TRIP A B
E/M
Instrumentation
23

PANEL DIMMER CONTROL
Use to adjust the brightness of the
instrument panel during headlight
and parklamp operation.
²Push up to brighten.
²Push down to dim.
AUTOLAMP CONTROL
The autolamp system provides
light sensitive automatic on-off
control of the exterior lights
normally controlled by the
headlamp control.
The autolamp system also keeps
the lights on for a preselected
period of time after the ignition
switch is turned to OFF.
²To turn autolamps on, rotate the
control counterclockwise. The
preselected time lapse is
adjustable up to approximately
three minutes by continuing to
rotate the control
counterclockwise.
²To turn autolamps off, rotate the
control clockwise to OFF.
HEADLAMP CONTROL
Rotate the headlamp control
clockwise to the first position to
turn on the parking lamps only.
Rotate to the second position to
also turn on the headlamps.
PANEL
DIM
OFF
AUTO
LAMPP
OFF
P
Controls and features
24

Daytime running light (Canadian
vehicles only)
The daytime running light system
turns the headlamps on, with a
reduced light output, when:
²the vehicle is running,
²the parking brake is released,
²the headlamp system is in the
OFF position or AUTOLAMP
position when the autolamp
function has turned on the
headlamps (daytime)
The Daytime Running
Light (DRL) system will
not illuminate the tail lamps and
parking lamps. Turn on your
headlamps at dusk. Failure to do
so may result in a collision.
High beams
Push forward to activate.
HI
LO
F
S
OFF
Controls and features
