1998 LINCOLN MARK VIII Owners Manual

REFILL CAPACITIES
Fluid Ford Part Name Capacity
Engine oil
(includes filter
change)Motorcraft 5W30 Super
Premium Motor Oil 5.7L (6.0 quarts)
Brake fluid Ford High Performance DOT
3 Brake FluidFill to line in
reservoir
Power steering
fluidMotorcraft MERCONtATF Fill to line in
reservoir
Transmission fluid Motorcraft MERCONtV ATF 12.0L (12.8 quarts)
Engine coolant Ford Premium Cooling
System Fluid15.1L (16.0 quarts)
Fuel tank N/A 68.1L (18.0
gallons)
Rear axle fluid
1Motorcraft SAE 80W90 Rear
Axle Lubricant1.4-1.5L (2.9-3.1
pints)
Windshield washer
fluidUltra-Clear Windshield
ConcentrateFill to line in
reservoir
1Service refill capacities are determined by filling the rear axle 6 mm
(1/4 inch) below the bottom of the filler hole.
Rear axles are considered lubricated for life when the vehicle is used for
normal service. See your ªService Guideº for Severe Duty requirements.
Capacities and specifications
162

LUBRICANT SPECIFICATIONS
Item Ford part name Ford part
numberFord
specification
Brake master
cylinderHigh Performance
DOT 3 Motor
Vehicle Brake FluidC6AZ-
19542-ABESA-M6C25-A,
DOT 3
Door
weatherstripsSilicone Lubricant C0AZ-19553-
AA and
D7AZ-
19553-AAESR-M13P4-A
Engine coolant Ford Premium
Cooling System
FluidE2FZ-
19549-AAESE-M97B44-A
Engine oil Motorcraft 5W-30
Super Premium
Motor OilXO-5W30-
QSPWSS-M2C153-G
with API
Certification
Mark
Hinges, latches
and striker
platesMulti-Purpose
GreaseDOAZ-
19584-AAESR-M1C159-A
and
ESB-M1C93-B
Lock cylinders Penetrating
LubricantE8AZ-
19A501-BN/A
Power steering
reservoirMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Automatic
transmission
(4R70W)Motorcraft
MERCONtVATFXT-5-QM
MERCONtV
Windshield
washer fluid
reservoirUltra-Clear
Windshield Washer
ConcentrateC9AZ-19550-
AC or BCESR-M17P5-A
Rear axle Motorcraft Premium
Rear Axle LubricantXY-80W90-QL WSL-M2C197-A
Capacities and specifications
163

ENGINE DATA
Engine 4.6L DOHC engine
Cubic inches 281
Horsepower (except LSC) 280 @ 5750 rpm
Horsepower (LSC) 290 @ 5750 rpm
Torque (except LSC) 285 lb. ft. @ 4500 rpm
Torque (LSC) 290 lb. ft. @ 4500 rpm
Recommended fuel grade 91 octane
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm (0.052-.056 inch)
Ignition system EDIS
Compression ratio 9.8:1
VEHICLE DIMENSIONS
Vehicle dimensions mm (in)
(1) Overall length 5 263 (207.2)
(2) Overall width 1 900 (74.8)
(3) Overall height 1 361 (53.6)
(4) Wheelbase 2 870 (113.0)
(5) Track - Front 1 565 (61.6)
(5) Track - Rear 1 530 (60.2)
Capacities and specifications
164

2
3
5
1
4
Capacities and specifications
165

IDENTIFYING YOUR VEHICLE
Safety compliance label
The National Highway Traffic Safety
Administration Regulations require
that a Safety Compliance
Certification Label be affixed to a
vehicle and prescribe where the
Safety Compliance Certification
Label may be located. The Safety
Compliance Certification Label is
located on the front door latch pillar
on the driver's side.
Vehicle identification number
The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel.
Engine number
The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block, transmission, frame and
transfer case (if so equipped).
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX F0000
BAR INT TR TP/PS R AXLE TR SPR T0000
X XX XXX X XX X XXXX
UTC
ÑFOHT-15294A10-GA
MAXIMUM LOAD=OCCUPANTS + LUGGAGE=XXXKG/XXXXLB
OCCUPANTS: X TOTAL X FR X 2ND X RR OCCUPANTS LUGGAGE
XX XXXKG/XXXXLB
TIRE: XXXX/XXXXX XXX X XXXKG/XXXXLB
PRESSURE (FR) XXX kPa/33 PSI COLD
PRESSURE (RR) XXX kPa/33 PSI COLD
TRAILER TOWING - SEE OWNER GUIDE
DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG
VIN: XXXXXXXXXXXXXXXXX TYPE: XXXXXXXXXXXXXXX FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE
DATE OF MANUFACTURE SHOWN ABOVE.
XXXXXXXXXXXXXXXXX
AIR BAG
Capacities and specifications
166

REPORTING SAFETY DEFECTS (U.S. ONLY)
If you believe that your vehicle has
a defect that could cause a crash, or
could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addition
to notifying Ford Motor Company.
If NHTSA receives similar complaints, it may open an investigation, and
if it finds that a safety defect exists in a group of vehicles, it may order a
recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer or Ford Motor Company.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free
at 1±800±424±9393 (202±366±0123 in the Washington D.C. area) or write
to:
NHTSA
U.S. Department of Transportation
400 Seventh Street
Washington D.C. 20590
You can also obtain other information about motor vehicle safety from
the Hotline.
Reporting safety defects
167
