1998 INFINITI QX4 Factory Service Manual

3

1801

2

Attachment No.10
TID CID
Three way catalyst function (Bank 1) P042001H01H Max. 1/128
Three way catalyst function (Bank 2) P043003H02H Max. 1/128
P0440 05H03H Max.
1/128mm2
EVAP SYSTEM P144005H03H Max.
1/128mm2
EVAP control system purge flow monitoring P144706H83H Min. 20mV
P0133 09H04H Max. 16ms
P0131 0AH84H Min. 10mV
P0130 0BH04H Max. 10mV
P0132 0CH04H Max. 10mV
P0134 0DH04H Max. 1s
P0153 11H05H Max. 16ms
P0151 12H85H Min. 10mV
P0150 13H05H Max. 10mV
P0152 14H05H Max. 10mV
P0154 15H05H Max. 1s
P0139 19H86H Min.10mV/500ms
P0137 1AH86H Min. 10mV
P0140 1BH06H Max. 10mV
P0138 1CH06H Max. 10mV
P0159 21H87H Min.10mV/500ms
P0157 22H87H Min. 10mV
P0160 23H07H Max. 10mV
P0158 24H07H Max. 10mV
P0135 29H08H Max. 20mV
P0135 2AH88H Min. 20mV
P0155 2BH09H Max. 20mV
P0155 2CH89H Min. 20mV
P0141 2DH0AH Max. 20mV
P0141 2EH8AH Min. 20mV
P0161 2FH0BH Max. 20mV
P0161 30H8BH Min. 20mV
P0400 31H8CH Min. 1
P0400 32H8CH Min. 1
P0400 33H8CH Min. 1
P0400 34H8CH Min. 1
P1402 35H0CH Max. 1
P0402 36H0CH Max. 1count
P0402 37H8CH Min. 1count TEST VALUE AND TEST LIMIT (GST ONLY — NOT APPLICABLE TO CONSULT-II)\
Items for which these data (test value and test limit) are displayed a\
re the same as SRT code items.
These data (test value and test limit) are specified by Test ID (TID)\
and Component ID (CID) and can be dis-
played on the GST screen.The following is the information specified in Mode 6 of SAE J1979.
The test value is a parameter used to determine whether a system/circuit\
diagnostic test is “OK” or “NG” while
being monitored by the ECM during self-diagnosis. The test limit is a re\
ference value which is specified as the
maximum or minimum value and is compared with the test value being monit\
ored.
Test limit
Conversion
CATALYST SRT item
Self-diagnostic test item DTCTest value
(GST display)
EVAP control system (Small leak)
HO2S Heated oxygen sensor 1 (Bank 1)
Heated oxygen sensor 1 (Bank 2)
Heated oxygen sensor 2 (Bank 1)
Heated oxygen sensor 2 (Bank 2)
HO2S HTR Heated oxygen sensor 1 heater (Bank 1)
Heated oxygen sensor 1 heater (Bank 2)
Heated oxygen sensor 2 heater (Bank 1)
Heated oxygen sensor 2 heater (Bank 2)
EGR SYSTEM EGR function
EGRC-BPT valve function

641

642

643

644
